Summary of Contents for Entryphone PinNet 4
- Page 1 ® Entryphone PinNet 4 Product manual www.entryphone.co.uk 23 Granville Road, London SW18 5SD This document covers the installation and use of the Entryphone on-line PinNet door control system November 2018 – R6 © The Entryphone Company Limited...
-
Page 2: Table Of Contents
Request to exit ......................... 15 Time profiles ........................16 Log ............................17 Activity log – action column ....................18 Date/Time ..........................19 Day light saving ........................ 19 Change password ........................ 19 Setup............................ 20 IP Setup..........................20 © The Entryphone Company Limited... -
Page 3: Important
Important Training courses for the installation and use of all Entryphone products are available. For further information on course availability, or to discuss specific requirements, contact sales on 020 8870 8635 or visit entryphone.co.uk. HEALTH AND SAFETY Installation must comply with National Wiring Regulations (BS7671) If the secured door is part of an escape route the locks must also comply with any local fire, health and safety regulations. -
Page 4: General Description
General Description The Entryphone PinNet 4 is an access control system (using 125Khz RFID technology) that will control up to four doors. Its choice of keypad, GSM modem and IP control makes it ideal for properties where local administration is difficult to manage. The system incorporates an on-board web interface for setting up the device, users and viewing activity logs. -
Page 5: Capacity
The initial set-up is carried out by Entryphone and further adding or deleting of keys is achieved by entering an activation code on the unit’s keypad or via SMS text message. -
Page 6: Apparatus
PN4GSM – PinNet GSM Modem The PN4GSM when fitted to the system allows tokens to be added and deleted by Entryphone. Also the system can be set-up so that a door can be operated by ringing the unit from a validated telephone. -
Page 7: Pn4Rf - Pinnet Reader - Flush
H 216 W 89 D 38 PN4UR – PinNet USB reader The PN4UR is a USB reader that allows key fobs to be read directly to a PN4T – PinNet key fob Standard Entryphone 125Khz EM4100 key fob © The Entryphone Company Limited... -
Page 8: Connection Diagrams
The diagram shows each device powered by its own power supply (PSU). If required the locks can be powered through the unit via the “LOCKS” terminals (please note there are jumper links on the board so individual lock outputs can be isolated). © The Entryphone Company Limited... -
Page 9: Connections
+COM +N/O Reader 1 From Entryphone -N/C release pair if door served -COM -N/O RTE Button +N/C RELAY +COM +N/O Reader 1 -N/C Mag Lock -COM -N/O Break Glass BATT LOCKS 12vDC Lock Pre-wired Connections © The Entryphone Company Limited... -
Page 10: Programming
• Entryphone provide a service for adding users. • Via text (SMS) messages - for units with a built-in modem. Please contact Entryphone for more • information about the structure of the text messages. Keys may be added/deleted via a programming keypad (PN4R5KP), see page Error! Bookmark •... -
Page 11: Integrated Web Site
DHCP (Dynamic Host Control Protocol) is the process whereby the unit will glean an IP address as well as other details from a DHCP server. Broadband routers often provide DHCP services. Every network (TCP/IP) enabled device has a unique Mac address which identifies that device. © The Entryphone Company Limited... -
Page 12: Logging On
• the current administrator. A unique one-day maintenance password. The one-day passwords are available from Entryphone • on +0044 20 8870 8635 or requested via the contact us section of www.entryphone.co.uk. Login notes: Passwords are case sensitive. • Passwords can only be made up of letters and numbers. -
Page 13: Users
By default this screen show the first 50 users. Change this number to increase the number of • users to view, and click Users to display. PinNet will accommodate up to 1500 users. • For a detailed description of the headings and their meanings please see Add user on page 13 © The Entryphone Company Limited... -
Page 14: Add User
The phone number must be between 11 and 16 digits. The system only checks the last 10 digits so that calls coming in from abroad with other leading digits will be understood. This facility © The Entryphone Company Limited... - Page 15 Only switched on when a user has to present a fob and type a PIN to activate the lock. Confusingly this is not used for PIN only users. Active Turn on/off this user. R1-R4 Turn on/off which readers that this user can use. © The Entryphone Company Limited...
-
Page 16: Readers/Locks
Number of seconds the lock is released for. Set to 0 to turn off the lock. Request to exit Number of seconds the lock is released for on Request to exit. Set to 0 to switch off the Request to exit facility. © The Entryphone Company Limited... -
Page 17: Time Profiles
Start , Finish – 3 sets Can set three sets of Start/Finish times. For example a time profile could be used to operate only in working hours. Set both the start and finish time to 00:00 for no time restriction. © The Entryphone Company Limited... -
Page 18: Log
Should the name or description of the user be changed it will not back date those changes in the log, thus preserving how the key was set up at the point at which it is presented to the reader. © The Entryphone Company Limited... -
Page 19: Activity Log - Action Column
Phoning the system from a Modem telephone not registered as a user, or the telephone set to disable caller id. Phone not active Phoning the system from a Modem legitimate phone but the user set to inactive. © The Entryphone Company Limited... -
Page 20: Date/Time
1 hour on the last Sunday of March at midnight (GMT), and back 1 hour on the last Sunday of October at midnight (GMT). Change password Type the new password into the two boxes shown above. You do not need to know the old password to use this screen. © The Entryphone Company Limited... -
Page 21: Setup
Hardware Reset: Performs a reboot of the PinNet board. Suspends normal operation for approximately 2 seconds. The Contents of the communication buffer and the Contents of the ring buffer both record the communication between the PinNet and the GSM modem. © The Entryphone Company Limited...
