Summary of Contents for VITACON VitaScan PD
- Page 1 VitaScan PD Ultrasound Bladder Scanner User and Service Manual Version 1.0.3 | Date: 11th of December 2017.
- Page 2 11-Dec-17 The Information contained in this user and service manual is proprietary to Vitacon. It is only used for convenience of our customers. It may be changed in whole or in part without written notice. Any service work performed by persons who are not authorized by Vitacon may void your warranty.
- Page 3 VitaScan PD, even if advised of the www.vitacon.com...
-
Page 4: Table Of Contents
VitaScan PD User and Service Manual Table of Contents Tables of Contents ............................1 Introduction..............................2 Important Information ..........................2 Indications for Use ............................3 Product Features ............................3 Unpacking and Inspection.........................3 Content of the packaging ..........................4 Storage .................................4 Technical Specifications ..........................4 AC/DC Adaptor ............................5 Battery ................................5... -
Page 5: Introduction
However, medical professionals should use ultrasound only when clinically indicated. Warning: There is the hazard of possible explosion if the VitaScan PD instrument is used in the presence of flammable anesthetics. First time users We advise new operators to use the VitaScan PD on patients with moderately full bladders, rather than initially attempting to locate nearly empty bladders. -
Page 6: Indications For Use
Storage of ultrasound images • Simple, intuitive software with Touch- Screen support Note: This box contains specifically designed inserts to ensure safe shipment of the VitaScan PD. Save these for future shipment of the unit for service or calibration. www.vitacon.com PAGE... -
Page 7: Content Of The Packaging
VitaScan PD User and Service Manual The content of the packaging: This box contains specifically designed inserts to ensure safe shipment of the VitaScan PD. Save these for future shipment of the unit for service or calibration. • VitaScan PD, VitaScan LT ultrasound probe and probe holder. -
Page 8: Ac/Dc Adaptor
Table 0-0 Battery Specifications Product Upgrades and Updates Vitacon may offer software upgrades and new features that may improve system performance. User and Service Manual updates, explaining the effects of upgrades and new features on system performance, will accompany the upgrades. -
Page 9: System Familiarization
User and Service Manual VitaScan PD System Familiarization Introduction The VitaScan PD is an Ultrasound Urinary Bladder Scanner System. The VitaScan PD consists of an inbuilt LCD Display with Touch Screen input and utilizes a VitaScan LT Ultrasound Probe. Front View... - Page 10 VitaScan PD User and Service Manual Back View The back view of the VitaScan PD is as shown in the figure below: 1 VESA mount - 75 x 75 mm 2 Probe holder mount 3 Thermal printer 4 DC Power Inlet – 15V www.vitacon.com...
- Page 11 VitaScan PD User and Service Manual Left Side View The left side view of the VitaScan PD is as shown in the figure below: 1 Power On/Off switch 2 Thermal printer www.vitacon.com PAGE...
- Page 12 VitaScan PD User and Service Manual Right Side View The right side view of the VitaScan PD is as shown in the figure below: 1 USB port for external USB memory stick 2 USB port for VitaScan LT probe 3 Probe holder www.vitacon.com...
-
Page 13: About The System Software
VitaScan PD User and Service Manual About the System Software Vitacon will provide software updates on micro SD card. Typically, the new software provides new capabilities. Electrical Safety This system meets EN60601-1, Class I and Type BF isolated patient-applied parts safety requirements. -
Page 14: Equipment Safety
• Do not use the VitaScan PD if there is evidence of leakage of internal liquids. • Do not short the USB or Ethernet Wash hands immediately in warm, terminals. -
Page 15: Labeling Symbols
VitaScan PD User and Service Manual Warning There is a possible hazard of explosion if the VitaScan PD is used in the presence of flammable anesthetics. Labeling Symbols Warning, consult CE mark – Notified body no.2274 accompanying documents Read the documentation Test Agency Certification Mark –... -
Page 16: Applying The Ultrasound Gel
VitaScan PD User and Service Manual Applying the Ultrasound Gel Palpate the patient’s symphysis pubis (pubic bone) and apply the Gel immediately superior to the patient’s symphysis pubis, as shown in images below. Or apply the Gel around the dome of the Probe. -
Page 17: Measuring Bladder Volume
Regular Inspections and Maintenance VitaScan PD is a Medical Electric Equipment and therefore needs special precautions regarding EMC. VitaScan PD needs to be installed and put into service according to the EMC information provided in the accompanying documents. Vitacon recommends that the VitaScan PD be certified by an authorized VitaScan PD Service Center once a year. -
Page 18: Scan Operation
VitaScan PD User and Service Manual Figure 0-1 Home Screen • Tap on the screen, to navigate through the screen. • Tap Woman or Man option • For Woman tap Hysterectomy if needed • Tap Scan Depth option • Tap Start to start Prescan and locate the bladder. - Page 19 VitaScan PD User and Service Manual Scan Operation To make a measurement, press the Start button in the Home Screen. The Prescan displayed as shown below. Figure 0-2 PreScan • Tap SCAN to start scanning of the whole bladder. •...
- Page 20 VitaScan PD User and Service Manual Scan Operation To make a measurement, press the Start button in the Home Screen. The Prescan displayed as shown below. Figure 0-3 Result • Tap Start to do a new scan • Tap Clear/Restart to clear screen •...
-
Page 21: Adjust Result
VitaScan PD User and Service Manual Adjust result Figure 0-3 Result • to Adjust transversal plane. (Move blue marker points to bladder edge) • to Adjust sagittal plane. (Move blue marker points to bladder edge) • Tap Done to end adjustment www.vitacon.com... -
Page 22: Setup
Tap “6”, “12”, or “24” to Set a number of slices in a scan. • Easy-Mode (toggle between Yes or No) to set only one slices in a scan. • Tap Live-Update to set continuous reading • Phantom (toggle between Yes or No) to measure on Vitacon bladder phantom www.vitacon.com PAGE... -
Page 23: Manufacturer
VitaScan PD User and Service Manual Vitacon will upon request make available other technical documentation, which will assist qualified technical personnel to repair the equipment. Repair should be performed only by Vitacon authorized service organization. Manufacturer: U AB Vitacon LT Naujoji g.
