- Page 1 INSTALLATION, OPERATION & MAINTENANCE MANUAL QUARTER TURN RACK & PINION ACTUATORS PNEUMATIC RP SERIES AS 4629 www.australianpipelinevalve.com.au...
- Page 2 Valves - Cast Steel Valves - Forged Steel Sleeved & Lined Valves & Wellheads APV valves and pipeline products form the most APV FAMILY OF BRANDS RANGE - CATALOGUES competitive portfolio in the market.” Diamond Gear Flowturn Ball Valves Flowturn Gate, Globe...
- Page 3 ACTUATORS - RP SERIES I N D E X Overview Safety Information 1.0 Warning 2.0 Working Conditions and Technical Data 3.0 Storage and Handling 4.0 Installation 7-12 Installation, tube & fittings Operation Manual over-ride operation Actuator sizing 9-11 Actuator installation instructions 11-12 5.0 Commissioning 6.0 Maintenance...
-
Page 4: Operating Media
ACTUATORS - RP SERIES O V E R V I E W This instruction manual is for rack & pinion pneumatic actuators. The RP Series rack & pinion pneumatic actuator has been designed, developed and tested incorporating the latest technology and materials available, with some innovative design features. As a AS 4629 result of this product research we have obtained a high grade product with the following characteristics:... -
Page 5: Operating Time
The User is responsible for ordering the correct valves & actuators. The user is responsible for ensuring APV Valves & Actuators are selected and installed in conformance with the current pressure rating and design temperature requirements. Prior to installation, the nameplates and drawings should be checked for proper identification to ensure the valve &... -
Page 6: Receiving Inspection And Handling
This manual provides instructions for storing, general servicing, installation and removal of actuators. APV and it’s resellers refuses any liability for damage to people, property or plant as well as loss of production and loss of income under any circumstances but especially if caused by: Incorrect installation... - Page 7 ACTUATORS - RP SERIES or utilisation of the actuator or if the actuator installed is not fit for intended purpose. It is the sole responsibility of the user to ensure the valve type and materials are correctly specified. 1 . 0 W A R N I N G •...
- Page 8 ACTUATORS - RP SERIES For low and high temperature service, special grease and special components are required. Please contact us. Working at high or low temperature can affect the life and the output torque of the actuator. The operating time depends on several factors such as supply pressure, supply system capacity (pipe diameter, flow capacity of pneumatic accessories), valve type, valve torque and figure, applied safety factor, cycle frequency, temperature, etc.
-
Page 9: Storage And Handling
ACTUATORS - RP SERIES 3 . 0 S T O R A G E & H A N D L I N G To ensure the seals remain flexible, and the actuator itself free moving during times of storage or intermediate services, air or nitrogen pressure should be cycled through the actuator at a minimum of three (3) times a month. -
Page 10: Manual Over-Ride Operation
ACTUATORS - RP SERIES b. Different pneumatic actuators have different air inlet sizes from 3/8” to 2” NPT. Using a smaller size Table 1 - Air Inlet sizes piping (or reduce orifice valves, solenoids, etc.) will reduce opening speeds. c. To ensure quick operation of the actuator, do not use a smaller tube or fitting size than the inlet size provided. - Page 11 4.4.1 General Sizing Rules for Soft Seated Ball Valves Valve and actuator torque values published are theoretical, however where required APV will perform a torque test prior to despatch. The real valve torque value can be higher depending upon the following listed factors as these factors can drastically increase (or decrease) the torque of soft seated ball valves.
- Page 12 ACTUATORS - RP SERIES stated BTO torque*. ETC - Closing torque: the torque required to reseat a closing valve. 85% of stated BTO torque*. RTC - Running torque: the torque needed to keep the ball moving through it’s travel. 50% of stated BTO torque*.
-
Page 13: Actuator Installation Instructions
ACTUATORS - RP SERIES Temperature Effect: For operating temperature from 80°C to 130°C, use the torque multiplier given. For 0°C to 80°C no temperature multiplier is required. For operating temperatures less then 0°C and above 140°C consult Australian Pipeline Valve. Temperature Multiplier = T emp °C ÷... - Page 14 ACTUATORS - RP SERIES Solenoid valve mounting Assembly of accessories: solenoid valves and switchboxes Before mounting a solenoid valve, ensure that the actuator is in it’s normal position (closed position) with pistons inwards. For standard rotation type “ST” (clockwise to close) assembly: the groove on the drive shaft or on the position indicator (2) must be horizontal to the longitudinal axis of the actuator in the closed position.
-
Page 15: Maintenance Instructions
ACTUATORS - RP SERIES 5 . 0 C O M M I S S I O N I N G If the unit has been left in the same position for long periods, the packings and seals may have set. This means that when the actuator is again operated, possible leakage may come from the piston seals or rod packings. - Page 16 ACTUATORS - RP SERIES 6.1 DISASSEMBLY When disassembly of actuator is required for maintenance, firstly remove the actuator from the valve before performing any disassembly operations. It is important to verify that the actuator is not pressurised. Always use caution and double check that the ports 2 and 4 are vented and are free from any accessory and/or device.
- Page 17 ACTUATORS - RP SERIES Air pressure should not be used to remove the pistons from the body • Remove piston o-rings (16) using a small screwdriver, remove the piston back (05) and piston head (15) bearings. Discard bearings when replacing all soft components. 6.1.5 Pinion shaft disassembling (Part No.
- Page 18 ACTUATORS - RP SERIES energised and install internal thrust bearing (08). Insert Figure 12 completely the drive shaft in the body. • Fit external thrust bearing (08), thrust washer (10) and then external circlip (18) using snap ring pliers. 6.2.2 Pistons assembly (Part No. 40), Figures 13, 14, 15 and 16 •...
- Page 19 ACTUATORS - RP SERIES • Fit end caps onto the body (50), verifying that the o-ring remains in the groove. • Insert all the cap screws (13) and tighten each only partially. Complete tightening by following the sequence indicated in Figure 19. 6.2.4 Assembly of stop cap screws (Part No.
-
Page 20: Lifting And Handling
Typical operation of the actuator involves applying pressure to the appropriate pressure inlet(s) of a double acting or spring return cylinder by means of a suitable control valve. APV-Torqturn actuators are sized to ensure the required valve torque is produced at the supply pressure selected by the customer. -
Page 21: Operating Specifications
ACTUATORS - RP SERIES The standard rotation (when port 4 is pressurized or for spring action) is clockwise to close. When port 2 is pressurized, counter-clockwise rotation is obtained. Torqturn actuators can be supplied with different types of assembly/rotation direction depending on the type of required operation and/or installation, see technical data sheets. - Page 22 3/2 SOLENOID VALVE OPERATION VALVE OPERATION APV can also supply Namur solenoid valves: 5/2 and 3/2 way in all standard voltages, D.C or A.C. 1. Ancillaries installation without multi-function indicator. The actuator can be supplied upon request with a NAMUR...
- Page 23 ACTUATORS - RP SERIES 2. External stroke adjustment A great saving of time is achieved, when mounting the actuator on the valve, through the service friendly adjustment of both end positions with precise cam system. The rotation angle is easily changeable with a special cam system.
- Page 24 ACTUATORS - RP SERIES Three Position Torqturn Actuator Three position Torqturn actuator provides an operation of 0°, 45°, 90° or 0°, 90°, 120° and 180°. The midway position is achieved by a mechanical stop of movement of the 2 auxiliary pistons.
- Page 25 Other parts are generally not required as spares. Do not attempt to repair this actuator, send to an authorised APV repair facility. When ordering replacement parts, it is important to include the complete actuator model number and serial number along with the part numbers required.
-
Page 26: Design Features
ACTUATORS - RP SERIES 9 . 0 D E S I G N F E A T U R E S Indicator Pistons Position indicator with NAMUR The twin rack pistons are made is convenient for mounting from Die-casting aluminium accessories such as Limit Switch treated with hard anodised or box, Positioner and so on. - Page 27 ACTUATORS - RP SERIES A P P E N D I X A Parts & Materials RP50 ~ RP400 Corrosion Optional Part No. Spare Parts Unit Qty. Part Material Protection Material Body Extruded Aluminium Alloy Anodised Drive Shaft Steel Alloy Oxidation Adjust Cam Bottom Bearing...
- Page 28 ACTUATORS - RP SERIES A P P E N D I X B Dimensions (DA/SR) RP50 RP63 RP75 RP88 RP100 RP125 RP145 RP160 RP180 RP200 RP240 RP265 RP300 RP350 RP400 RP500 RP600 ISO5211 F05/07 F05/07 F07/10 F07/10 F10/12 F10/12 F10/14 F10/14 F12/16 1062...
- Page 29 ACTUATORS - RP SERIES Dimensions RP500 1032 Ø125 2-G1 Ø356 8 XM20 4xM5 Ø298 8 XM30 105x105 Dimensions RP600 1262 Ø125 Ø356±0.5 8 XM36 4xM5 Ø406±0.5 8 XM30 Australian Pipeline Valve - Installation, Operation and Maintenance Manual...
- Page 30 NOTES Australian Pipeline Valve - Installation, Operation and Maintenance Manual...
- Page 31 NOTES © Copyright Australian Pipeline Valve 1990 - 2018 Edition Catalogues, photos, brochures and technical publications are the exclusive property of Australian Pipeline Valve. Any unauthorised reproduction in total or in part, shall result in prosecution. Products and data sheets in this publication are subject to change at anytime without notice.
- Page 32 A D E L A I D E B R I S B A N E P E R T H • • AUSTRALIAN PIPELINE VALVE® HEAD OFFICE 70-78 Stanbel Road Salisbury Plain South Australia 5109 Telephone +61 (0)8 8285 0033 Fax +61 (0)8 8285 0044 email: admin@australianpipelinevalve.com.au www.australianpipelinevalve.com.au LOCAL DISTRIBUTOR/AGENT...
