Happy Nerding FX AID PRO Manual

Hide thumbs

Advertisement

Quick Links

Download this manual
Introduction: page 1
Front Panel: page 4
Settings: page 5
Internal LFOs: page 5
User Presets: page 6
The FX Aid Pro is an 14HP euro module based on the spin chip. The user can load
200 sound e ects in any order from a growing list of high quality e ects.
Each FX program has 3 clearly labeled parameters as seen on the display each with
a knob and CV input, 10 user presets are con gurable with 3 user de ned LFOs.
FX Sample rate and Dry/Wet balance are voltage controllable.
Sample Rate Reduction: page 6
Online Editor: page 6
Firmware Update: page 6
Oscilloscope: page 6
