Cargo Hold
™
28 Pannier
Volume
Weight Capacity
• 28 L (1,709 cu in) carrying capacity.
• 9 kg (20 lb) max load.
What's Included
• Cargo Hold 28 Pannier x 1
• Self-fastening Strap 25.4 x 215 mm (1" x 8.5") x 1
• Self-fastening Strap 25.4 x 105 mm (1" x 4.1") x 1
• Self-fastening Strap 25.4 x 110 mm (1" x 4.3") x 2
Installation on HSD, Quick Haul or Short Haul (standard position)
Installation on HSD, Quick Haul or Short Haul (passenger seating position)
With passenger seating, the bike cannot be parked or rolled vertically.
1
t ernbicycles.com
Installation on NBD
Installing a child seat will block access to the frame lock. To use the frame lock,
remove it from the rear wheel area and reinstall it behind the front fork of the NBD.
Rolling into Vertical Parking Position
Please take care when moving the bike into the vertical parking position because the
pannier may come into contact with the ground. Scratching and damage may occur.
Advertisement
Table of Contents
Related Manuals for Tern Bicycles Cargo Hold 28 Pannier
Summary of Contents for Tern Bicycles Cargo Hold 28 Pannier
- Page 1 Installing a child seat will block access to the frame lock. To use the frame lock, • Cargo Hold 28 Pannier x 1 remove it from the rear wheel area and reinstall it behind the front fork of the NBD.
- Page 2 Flat Fold CAUTION Do not exceed the maximum load of your rear rack and the maximum gross vehicle weight of your bike. If you are unsure of the load limits, please check your bike manual. Follow the instructions in the child seat user manual to install a seat properly. Check to ensure accessories have been correctly installed and securely fastened before riding.
