ATRAL Logisty L3264X Manual

Contents
Recommendations
When this product is opened its internal compo-
nents may be damaged by electrostatic discharge.
The following precautions must therefore be taken
during maintenance or repair operations:
do not touch the electronic components or metal
parts of their connections either directly or with a
metal tool,
G
use non-magnetic tools,
B
touch a bare metallic surface such as a water pipe
or earthed electrical devices before accessing the
internal components,
avoid moving around when accessing the internal
components several times during the same opera-
tion to avoid electrostatic charge build-up.
Otherwise, apply the precautions above every time
you need to access the components.
Presentation..........................................................33
Preparation............................................................33
Opening .................................................................................33
Guarantee sticker ..................................................................33
Power supply .........................................................................33
Programming ........................................................34
Programming the customized radio code into the detector ....34
For a control panel other than L3310 :
allocate a detector to a group ...............................................35
For an L3310 control panel:
allocate an identification number to the contact detector ....37
Installing ................................................................40
Choosing the best place .......................................................40
Wiring and fixing the universal transmitter ...........................40
Wiring and fixing the external contacts ................................43
Testing the universal transmitter and contacts
(built-in and/or external) ........................................................44
Fault indication.......................................................................45
Changing the battery.............................................................45
Technical data.......................................................46
32
