Endurance EFP1.5H User Manual

Please see the full and complete owner's manual booklet
that has been included with your fire fighting system for
complete instructions, care and maintenance.
EFP1.5H FIREFIGHTING SYSTEM USER MANUAL
Congratulations on your purchase of an Endurance Equipment
Fire Pump. This is a great investment in your family's safety.
We at Endurance Equipment hope these instructions will help
you set up your new fire pump easily and quickly.
1. Pump unit
2. Fire hose with forestry quick connect
3. Fire Nozzle with forestry quick connect
4. Forestry quick connect by female NPT
5. Intake hose with strainer & female cam lock
6. Male cam lock by female NPT for intake port
May not be exactly as shown

SPECIFICATIONS

Type:
Suction & Discharge port. Dia. (mm/in):
Max. Head (m/ft):
Max. Suction (m/ft):
Max. Flow (m3/h, ft3/h)
Self-priming Time (s/4m)
Engine Type:
Max. Output(HP/rpm):
Fuel Tank Capacity(L/US Gal):
Recommended Fuel:
Starting System:
N.W. (kg/lbs):
Overall Dimensions (mm/in.)
Included with Pump:

INTAKE HOSE ASSEMBLY

Move pump to level surface near water source.
1. Attach male cam lock by female NPT (National Pipe Thread) to the intake (lower) port on pump. Thread the cam lock onto the intake port and
tighten with a wrench.
2. Attach intake hose to pump. Take female cam lock on end of intake hose and clamp onto male cam lock that is now attached to the pump.
3. Attach the foot valve strainer to opposite end of intake hose.
4. Drop strainer end of intake hose into water source.

DISCHARGE HOSE ASSEMBLY

1. Attach forestry quick connect by female NPT to pump discharge (upper) port. Thread the forestry quick connect onto the discharge port and
tighten with a wrench.
2. Attach either end of the fire hose with a 1/4 turn to the discharge port.
3. Attach the nozzle to the other end of the fire hose in the same manner as in 2.

PUMP PRIMING

1. When starting the pump for the first time, unscrew cap on top of discharge port and add water until it overflows.
2. Tighten cap and start pump according to the instructions below, pump will self-prime. Never run the pump for more than a few seconds
without water or damage to the pump will occur.
Gasoline Fire Pump
40/1.5
70/230 (100psi)
8/26
13.5/477
65
Forced Air cooled, 4-stroke OHV
6.5/3600
3.6/1
Unleaded gasoline
Recoil
25/55
520x385x470 / 20.5x15x18.5
50' Fire Hose, Fog/Stream Nozzle, 8' Intake
Hose with Strainer & Camlock Couplers
