1/6-Inch VGA CMOS Digital Image Sensor

PART NUMBER: MT9V012

Features

™

• DigitalClarity

CMOS Imaging Technology

• High frame rate

• Superior low-light performance

• Low dark current

• Simple two-wire serial interface

• Auto black level calibration

• Operating Modes: Snapshot and flash control, high

frame rate preview, electronic panning

• Programmable Controls: Gain, frame size/rate,

exposure, left–right and top–bottom image reversal,

window size, and panning

• Data Interfaces: parallel and low-voltage differential

signaling (LVDS)

• Applications

• Cellular Phones

• PC Cameras

• PDAs

• Toys and other battery-powered products

General Description

The Micron

Imaging MT9V012 is an oversize VGA-

format CMOS active-pixel digital image sensor with a

pixel array of 649H x 489V. It incorporates sophisti-

cated on-chip camera functions such as windowing,

mirroring, column and row skip modes, and snapshot

mode. It is programmable through a simple two-wire

serial interface and has very low power consumption.

The VGA CMOS image sensor features DigitalClarity—

Micron's breakthrough low-noise CMOS imaging tech-

nology that achieves CCD image quality (based on sig-

nal-to-noise ratio and low-light sensitivity) while

maintaining the inherent size, cost, and integration

advantages of CMOS.

PDF: 814eb99f/Source: 8175e929

MT9V012_1.fm - Rev. B 2/05 EN

‡

Products and specifications discussed herein are for evaluation and reference purposes only and are subject to change by Micron without notice. Products are only warranted by Micron

MT9V012 - 1/6-Inch VGA CMOS Digital Image Sensor

Table 1:

Optical Format

Active Imager Size

Active Pixels

Pixel Size

Color Filter Array

Shutter Type

Maximum Data Rate/

Master Clock

Frame

Rate

ADC Resolution

Responsivity

Dynamic Range

SNR

MAX

Supply

Voltage

Power Consumption

Operating

Temperature

When operated in its default mode, the sensor gener-

ates a VGA image at 30 frames per second (fps). An on-

chip analog-to-digital converter (ADC) generates a 10-

bit value for each pixel. The pixel data is output on a

10-bit output bus and qualified by an output data

clock (PIXCLK), together with LINE_VALID and

FRAME_VALID signals. A FLASH output strobe is pro-

vided to allow an external Xenon or LED light source to

synchronize with the sensor exposure time. The sensor

can be programmed by the user to control the frame

size, exposure, gain setting and other parameters.

Micron Technology, Inc., reserves the right to change products or specifications without notice.

to meet Micron's production data sheet specifications.

Key Performance Parameters

Parameter

1/6-inch VGA (4:3)

2.30mm(H) x 1.77mm(V),

2.88mm Diagonal

640H x 480V

3.6µm x 3.6µm

RGB Bayer Pattern

Electronic Rolling Shutter (ERS)

13.5 MPS/27 MHz

VGA

Programmable up to 30 fps

(640 x 480)

CIF

Programmable up to 60 fps

(352 x 288)

10-bit, on-chip

1.0 V/lux-sec (550nm)

>71dB

44dB

Analog

2.50V–3.10V (2.80V nominal)

I/O and

1.70V–1.90V (1.80V nominal) or

Digital

2.50V–3.10V (2.80V nominal)

<55mW at 2.8V, 27 MHz,

30 fps and VGA resolution

-30°C to +70°C

‡

Preliminary

Features

Typical Value
