LabSen electrochemical sensors are premium pH electrode with manufacturing technology and key
components imported from Switzerland. LabSen761 places the tapered glass membrane in a
stainless steel shaft with blade. This probe is suitable for pH measuring of fish, meat and meat
products.
This Electrode has following features:
•
LabSen
®
S-type spear sensor tip featured with high firmness and fast response, designed for
direct measurement of solid samples
Food-grade titanium blade sheath, easily piercing into hard samples while providing strong
•
protection to the sensor
Open&Ceramic double-junction with Polymer electrolyte. No more junction clogs.
•
•
Long life reference system improves the stability of the reference system and extends the
electrode's service life.
Blue gel inner solution - does not flow and will not generate air bubbles
•
Technical Data
1
Measuring Range
Temperature Range
Membrane Type
Shaft Material
Reference
Junction
How to use
2
1. Insert the blue BNC connector of the electrode to the BNC socket of your pH meter
while twisting clockwise until it's locked.
2. Before measuring, twist off the storage bottle cap (see graph on the right),
pull out the electrode and rinse it off with distilled or deionized water.
3. Perform at least a two-point calibration before measuring after connecting
the new electrode to your pH meter.
4. After using, put the electrode back into the storage bottle and twist on the
bottle cap.
Maintenance
3
1. When not in use, the electrode should be soaked in the storage bottle containing 3M KCL soaking
solution to keep the glass membrane and junction in a healthy condition. Clean the bottle and
replace the soaking solution if it gets contaminated. The electrode should never be stored in pure
LabSen761 Blade Spear pH Electrode
User Manual
(0 ~ 14) pH
(0 ~ 80) °C
S
Food-Grade Titanium
Long Life
Ceramic+Single Pore
Electrolyte
Soaking Solution
Membrane Resistance
Electrode Dimension
Connector
Cable
Polymer
3M KCl
<250MΩ
(Ø12×115) mm
BNC
Ø3×1m
