Instructions for installing and activating FlexScan3D using an installation ID or dongle can be found in the User Manual SETTING UP THE VISION V1 • Connect the 3d sensor to the computer via a USB 3.0 A to B cable. Plug in and fasten the 12V DC power connector.
Page 3
Open FlexScan3D 3.5 and go to the Scanners Panel tab. Select the New button to connect to a new scanner. The software will f ind all connected scanners, select the corresponding serial number. Click OK to f inish adding the device. Change to the Project tab on FS3D.
CONFIGURE SCANNER Select Handheld Mode to set the scanner to continuous capture. Place the object being scanned within 400 to 600 mm from the front plate of the sensor. Change the projector pattern to PHASE/ FOCUS for live view with the scanning parameters.
Page 5
Toggle the projector brightness making sure the object of interest is not under-exposed (blue) nor over-exposed (red). Underexposed live view Overexposed live view The object of interest should have a light-grey/white appearance on the live view. Correct live view...
Page 6
CAPTURE DATA 3.1 Live Point Cloud Visualization Check the Capture Only option on the left pane. Click on SCAN to see the live view captured point cloud. 3.2 Object Reconstruction Make sure the Capture Only option is unchecked.
Page 7
Once you are done capturing, click on the STOP button and select YES to save the resulting point-cloud. To convert the point-cloud to a mesh, use the Finalize button on the mesh editor to generate the faces and f inalize the raw data. Select the mesh generation parameters and click OK.
QUICK START GUIDE VISION V1 3D SENSOR POLYGA SB SDK After f inish getting started with the V1, take the next step using Polyga’s SBSDK 3.0 to integrate your new 3D Sensor with your application. For SBSDK information visit : www.polyga.com/sbsdk/...
