SALT WATER CHLORINATORS
Self Cleaning
Mineral / Salt Chlorinator
Installation and Operation Manual for
EVOCHLOR SELF-CLEANING CHLORINATOR
EV15 | EV25 | EV35
This equipment must be installed and serviced by a qualified technician. Improper installation can create electrical
hazards which could result in property damage, serious injury or death. Improper installation will void the warranty.
This manual contains important information about the installation, operation and safe use of this product. Once
the product has been installed this manual must be given to the owner/operator of this equipment.
Advertisement
Table of Contents
Summary of Contents for Reltech EVOCHLOR EV15
- Page 1 ® SALT WATER CHLORINATORS Self Cleaning Mineral / Salt Chlorinator Installation and Operation Manual for EVOCHLOR SELF-CLEANING CHLORINATOR EV15 | EV25 | EV35 This equipment must be installed and serviced by a qualified technician. Improper installation can create electrical hazards which could result in property damage, serious injury or death. Improper installation will void the warranty. This manual contains important information about the installation, operation and safe use of this product.
-
Page 2: Table Of Contents
Self Cleaning Mineral / Salt Chlorinator TABLE OF CONTENTS 1.0 FOREWORD 2.0 POOL CHEMISTRY . 3.0 CELL INSTALLATION 4.0 POWER PACK INSTALLATION 5.0 OPERATION 6.0 MAINTENANCE 7.0 TROUBLESHOOTING 8.0 WARRANTY . 9.0 NOTES... -
Page 3: Foreword
FOREWORD Congratulations on purchasing a Reltech EvoChlor Saltwater Chlorinator for your swimming pool. This system is designed for robust reliability and easy operation to provide many years of trouble-free service. Please read the instructions thoroughly before operating the unit. If you have any concerns or require further assistance, please do not hesitate to contact our friendly staff or any of our Reltech distributors. -
Page 4: Cell Installation
CELL INSTALLATION The electrolytic cell housing must be plumbed into the return line after the filter. Please refer to the installation diagram, Fig.1, below for the preferred method. The cell housing has allocations for either 40mm PVC pipe or 50mm PVC pipe with the use of the supplied PVC reducing bushes. -
Page 5: Power Pack Installation
POWER PACK INSTALLATION The EvoChlor Chlorinator power pack is wall mounted by either using the supplied mounting bracket or directly hanging on the wall with screws (300mm centres). The power pack is to be mounted at least 1 metre above the ground and 3 metres or more from the pool edge. It is strongly recommended that the power pack be installed where it is protected from the elements. -
Page 6: Operation
OPERATION The control interface on the power pack consists of the following. Fig. 3 1. Chlorine Output LEDs If the correct salinity level is maintained in the water, then all ten lights will illuminate at full output (100%). Each light represents 10% chlorine output. If all lights are not illuminated, then a higher salinity level will be required. - Page 7 NB: Turn off the chlorinator at the power point before attempting to reset the circuit breaker. Should the circuit breaker continue to trip, then a local Reltech distributor should be contacted. 7. Switch This switch allows you to choose the timer operation mode for the chlorinator and pool pump.
-
Page 8: Maintenance
Replace the cell into housing in a reverse manner to the steps above. Only qualified electrical technicians should service the power pack. For the nearest Reltech recommended service technician, please contact us: Phone: +61 3 9459 3838 Email: office@reltech.com.au... -
Page 9: Troubleshooting
TROUBLESHOOTING Fault/Problem Possible Cause Remedy Pump turned off. Ensure the pump is on. Closed valve. Open valve. Air in the system. Check all o-rings and grease. NO FLOW All chlorine output Dirty filter. Clean or Backwash filter. LED’s flashing Low water level. Fill up the pool. -
Page 10: Warranty
Reltech EvoChlor Chlorinators are covered by a 3-year full warranty from the date of purchase. Reltech also offer a 12 month in field warranty for Melbourne, Sydney and Perth metro areas. The power pack and electrolytic cell are covered against defects in materials and assembly from the date of purchase in a domestic application. -
Page 11: Notes
NOTES... - Page 12 43-45 Kylta Rd, Heidelberg West, VIC 3081 Australia +61 3 9459 3838 Unless otherwise indicated, copyright in the content of this document is the property of Reltech Australia under Australian copyright law. Unless otherwise indicated, content may not be reproduced or transmitted without our prior written permission.
