Summary of Contents for Gold Metal 4001
- Page 1 Instruction Manual Candy Apple Stoves Caramel Corn Stove Models: 4001 and 4002 Model: 2083 Model 2083 shown for general image reference only (kettle not included). 10700 Medallion Drive, Cincinnati, Ohio 45241-4807 USA © 2022 Gold Medal Products Co. Part No. 110016...
-
Page 2: Safety Precautions
Caramel Apple Stoves Models: 4001 and 4002 Caramel Corn Stove Model 2083 SAFETY PRECAUTIONS DANGER Machine must be properly grounded to prevent electrical shock to personnel. Failure to do so could result in serious injury, or death. Make sure all machine switches are in the OFF position before plugging the equipment into the receptacle. - Page 3 Caramel Apple Stoves Models: 4001 and 4002 Caramel Corn Stove Model 2083 WARNING DO NOT allow direct contact of this equipment by the public when used in food service locations. Only personnel trained and experienced in the equipment operation may operate this equipment.
-
Page 4: Installation Instructions
To order copies of the operator’s manual go to gmpopcorn.com or write to Gold Medal Products Co., 10700 Medallion Drive, Cincinnati, OH 45241 USA 1-(800)-543-0862. Model Description 4001 and 4002: Electric Candy Apple Stoves 2083: Electric Caramel Corn Stove For smaller operations, the counter-top 120-volt model 4008 Reddy-Apple candy apple cooker is available for purchase (unit allows you to make candy apples with a minimum of space). - Page 5 Caramel Apple Stoves Models: 4001 and 4002 Caramel Corn Stove Model 2083 Setup 1. Remove all packaging and tape prior to operation. 2. Place unit in a level position on a surface strong enough to support it when in use.
-
Page 6: Electrical Requirements
Caramel Corn Stove Model 2083 Electrical Requirements The following power supply must be provided (reference unit Data Plate for Wattage requirement): 4001: 208 V~, 60 Hz 4002: 240 V~, 60 Hz 2083: 208/240 V~, 60 Hz DANGER Machine must be properly grounded to prevent electrical shock to personnel. - Page 7 Caramel Apple Stoves Models: 4001 and 4002 Caramel Corn Stove Model 2083 OPERATING INSTRUCTIONS Making Candy Apples Candy Apple Coating Candy apple coating is a mix of various sugars: sucrose, glucose, and dextrose. Hard candies have traditionally given chefs trouble. However, using fully prepared mixes such as our APPL-EZ eliminates most chances of a bad batch.
- Page 8 Caramel Apple Stoves Models: 4001 and 4002 Caramel Corn Stove Model 2083 Dipping the Apples Make sure apples are cleaned, dry, and sticks are inserted. When temperature is 275°F, turn the heat OFF. 1. Pick up apple by stick, with thumb and index finger, insert into candy apple coating (immersing entire apple).
-
Page 9: Care And Cleaning
Caramel Apple Stoves Models: 4001 and 4002 Caramel Corn Stove Model 2083 Care and Cleaning DANGER Machine must be properly grounded to prevent electrical shock to personnel. DO NOT immerse in water. DO NOT clean appliance with a water jet or steam cleaner. -
Page 10: Maintenance Instructions
Caramel Apple Stoves Models: 4001 and 4002 Caramel Corn Stove Model 2083 THE FOLLOWING SECTIONS ARE FOR QUALIFIED SERVICE PERSONNEL ONLY MAINTENANCE INSTRUCTIONS DANGER Machine must be properly grounded to prevent electrical shock to personnel. Failure to do so could result in serious injury, or death. -
Page 11: Ordering Spare Parts
Caramel Apple Stoves Models: 4001 and 4002 Caramel Corn Stove Model 2083 ORDERING SPARE PARTS 1. Identify the needed part by checking it against the photos, illustrations, and/or parts list. (General images may be used in manual for reference only.) 2. - Page 12 Caramel Apple Stoves Models: 4001 and 4002 Caramel Corn Stove Model 2083 Stove Unit - Parts Breakdown 14 15 3, 4, 5 6, 7 Leg Assembly (mounting brackets are preinstalled) To replace an old-style leg, replace all three as a set to make sure unit sits correctly.
- Page 13 Caramel Apple Stoves Models: 4001 and 4002 Caramel Corn Stove Model 2083 Stove Unit - Parts List Part Number Item Part Description 4001 4002 2083 WOOD SPOON 46207 46207 46207 WRAP AROUND, ELECT 32111 32111 33015 SWITCH BOX 27049 27049...
-
Page 14: Wiring Diagram
Caramel Apple Stoves Models: 4001 and 4002 Caramel Corn Stove Model 2083 Wiring Diagram Model 4001 and 4002 gmpopcorn.com Page 14... - Page 15 Caramel Apple Stoves Models: 4001 and 4002 Caramel Corn Stove Model 2083 Model 2083 gmpopcorn.com Page 15...
-
Page 16: Warranty
Caramel Apple Stoves Models: 4001 and 4002 Caramel Corn Stove Model 2083 WARRANTY WARRANTY Gold Medal Products Co. warrants to the original purchaser each item of its manufacture to be free of defects in workmanship and material under normal use and service. Gold Medal Products Co.’s obligation under this warranty is limited solely to repairing or replacing parts,...
