Transition Networks PSM-8E User Manual

COMPLIANCE INFORMATION
UL Listed
C-UL Listed (Canada)
CISPR/EN55022 Class A
FCC Regulations
This equipment has been tested and found to comply with the limits for a class A digital device, pursuant
to part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful
interference when the equipment is operated in a commercial environment. This equipment generates,
uses, and can radiate radio frequency energy and, if not installed and used in accordance with the
instruction manual, may cause harmful interference to radio communications. Operation of this
equipment in a residential area is likely to cause harmful interference, in which case the user will be
required to correct the interference at the user's own expense.
Canadian Regulations
This digital apparatus does not exceed the Class A limits for radio noise for digital apparatus set out on
the radio interference regulations of the Canadian Department of Communications.
Le présent appareil numérique n'émet pas de bruits radioélectriques dépassant les limites applicables
aux appareils numériques de la class A prescrites dans le Règlement sur le brouillage radioélectrique
édicté par le ministère des Communications du Canada.
European Regulations
Warning
This is a Class A product. In a domestic environment this product may cause radio interference in which
case the user may be required to take adequate measures.
Achtung !
Dieses ist ein Gerät der Funkstörgrenzwertklasse A. In Wohnbereichen können bei Betrieb dieses Gerätes
Rundfunkstörungen auftreten, in weichen Fällen der Benutzer für entsprechende Gegenmaßnahmen
werantwortlich ist.
Attention !
Ceci est un produit de Classe A. Dans un environment domestique, ce produit risque de créer des
interférences radioélectriques, il appartiendra alors à l'utilsateur de prende les measures spécifiques
appropriées
CAUTION: RJ connectors are NOT INTENDED FOR CONNECTION TO THE
PUBLIC TELEPHONE NETWORK. Failure to observe this caution could result in
damage to the public telephone network.
Der Anschluss dieses Gerätes an ein öffentlickes Telekommunikationsnetz in den EG-Mitgliedstaaten
verstösst gegen die jeweligen einzelstaatlichen Gesetze zur Anwendung der Richtlinie 91/263/EWG zur
Angleichung der Rechtsvorschriften der Mitgliedstaaten über Telekommunikationsendeinrichtungen
einschliesslich der gegenseitigen Anerkennung ihrer Konformität.
Trademark Notice
All registered trademarks and trademarks are the property of their respective owners.
Copyright Restrictions
© 2000, 2001 TRANSITION Networks.
All rights reserved. No part of this work may be reproduced or used in any form or by any means –
graphic, electronic, or mechanical – without written permission from TRANSITION Networks.
Printed in the U.S.A.
Designed to be networked with TRANSITION Networks PowerStar
hubs, the TRANSITION Networks PowerStar Express Multiplexer
(PSM-8E) is a site-configurable multiplexer used for extending IBM 5250*
protocol network distances over fiber.
PowerStar Express Multiplexer
Link
2X
Status
TX
RX
*IBM 5250 protocol products include the IBM
AS/400, remote controllers, and many supporting devices manufactured
by IBM and other companies.
The PSM-8E allows multiple AS/400, System 3x, or remote controller
polling groups to be transmitted over a single fiber-optic pair, providing
maximum throughput in either 1 Mb/s Optimized mode or in 2 Mb/s
Express mode by transparently multiplexing the 5250 "split-polling"
feature. (All new IBM controllers support "split-polling" as a means of
achieving higher throughput rates, even when connected to standard
legacy devices. The PSM-8E uses "split-polling" to increase performance
up to four times over the standard legacy 1 Mb/s 5250 protocol.)
NOTE: Refer to IBM 5250 Express reference material available from
network vendors when installing the PowerStar Express Multiplexer or
PowerStar
33184.B
IBM 5250 Protocol
™
Multiplexer with Fiber Link
PSM-8E
USER'S GUIDE
0 1 2 3 4 5 6 7
2X 2X 2X 2X 2X 2X 2X
GROUP A GROUP B GROUP C GROUP D
™ in a 5250 Express network.
PSM-8E in the Network . . . . . . . . . .2
Installation . . . . . . . . . . . . . . . . . . . .4
Operation . . . . . . . . . . . . . . . . . . . .11
Fault Isolation and Correction . . . .12
Cable Specifications . . . . . . . . . . . .14
Technical Specifications . . . . . . . . .15
Compliance Information . . . . . . . . .16
Minneapolis, MN 55344 USA
™
PSM-8E
® System 34, 36, 38, and
