Summary of Contents for Celestica Athena Erp lot9 EcoDesign
- Page 1 P2522 Athena Erp lot9 EcoDesign V0.2...
- Page 2 Annex II of t he Commission Regulation 2019/424. 3(1)(a): Product type: Dual node Flash Storage Controller. 3(1)(b): manufacturer’s address: Celestica (Thailand) Co.,Ltd 49/18 Laem Chabang Industrial Estate, Moo 5, Tungsukhla Siracha, Chonburi 20230, Thailand. 3(1)(c): product model number: P2522.
- Page 3 3(1)(n): FW and Secure data Deletion tool To delete data safely need the OS level software to be handled by Celestica's customer. Celestica will support firmware per Erp requirements at "free of charge or at a fair, transparent and non-discriminatory cost.”...
- Page 4 Website including to download the FW: https://hardware-support.azurewebsites.net/ 3(3)(a): BBU Cobalt: above 25G Neodymium in the PM1733 HDDs: between 5g-25g...
- Page 5 System Disassembly Instructions 3(3)(b): CAUTION: Always power off the system and unplug the power cord(s) first before disassembling the system! Type and number of fastenings: Four (4) T30 screws on heatsink. Tools required: Screwdriver with T30 Torx bit. The screw torque should be 13 KGF.CM.
- Page 6 WARNING: For Sharp edges and corners, please avoid injure when do assembling and dis-assembling operation.
-
Page 7: Hard Drive
Hard Drive Type and number of fastenings: Pan Head screw M3 x L4.5. One (1) latch and four (4) Torque 4 ± 0.5 KGF.CM Tools required: Screwdriver with PH2 bit. Procedure: 1) Click the button ① 2) The handle will open automatically ②... - Page 8 Type and number of fastenings: One (1) latch and one (1) handle per module. Tools required: None. Procedure: 1) Rotate the handle to a suitable angle ① 2) Keep pressing the pick and holding the handle ② 3) Pull the PSU out of the chassis ③...
- Page 9 Controller Canister Type and number of fastenings: Two (2) latches per controller canister. Tools required: None. Procedure: Rotate the handle then hold the handle to pull the canister out of the chassis.
- Page 10 Controller canister cover NOTE: The system should be operated by a skilled man after training. Type and number of fastenings: Two (2) locks on the controller canister cover. Tools required: None. Procedure: Press the two locks and pull the controller canister cover out in the direction as shown below.
- Page 11 The PCIE module NOTE: The others which located on the rear of the enclosure assembly are similar to the section shows below. Users could refer to the installation method as shown in the following chapters. Type and number of fastenings: Tools required: None.
-
Page 12: Fan Module
FAN Module WARNING: Moving fan blades accessible only during user servicing, any other time, users should keep away from moving fan blades. Type and number of fastenings: Tools required: None. Procedure: 1) Remove the controller canister cover, see Controller canister cover removal. 2) Unplug the connector, and then remove the single fan. - Page 13 M.2 Card Type and number of fastenings: plastic holder. Tools required: None. Procedure: 1) Push the M.2 card plastic holder outward ① 2) The card will open automatically ② 3) Pull the card out of the plastic holder ③ Figure 3- 2: M.2 card Removal...
- Page 14 Trusted Platform Module (TPM) card Type and number of fastenings: Tools required: None. Procedure: Pull the TPM card out of the slot.
-
Page 15: Battery Backup Units
Battery Backup Units Type and number of fastenings: One (1) BBU handle. Tools required: None. Procedure: Pull the TPM card out of the slot. 1) Rotate the BBU handle. Pull the BBU out of the canister. - Page 16 ─── END OF DOCUMENT ───...
