U S E R ' S
G U I D E
Dear Customer,
While warmly welcoming you to the big Laika family, we congratulate you on the
preference you have given to our brand. You have chosen elegance, prestige and
quality. Laika vehicles are technologically advanced and extremely reliable
products: a sure investment over the years.
This handbook, which you should read in your own interest and keep for future
reference, is intended to give you all the information you may need for the best use
of your new recreational vehicle and for correct maintenance. We strongly advise
you to always have any maintenance or repair operations carried out by Laika
dealers who can guarantee perfect service thanks to skilled personnel and
continuing technical up-dating. In all events, please do not hesitate to call our
Customer Service Dept. for any information you may need.
We would be very happy to receive your opinions and suggestions which, coming
from the 'field', are highly precious to us in perfectioning our product and fully
meeting every kind of requirement.
We take this opportunity to wish you and your family happy holidays with your
Laika and...
Enjoy your trip!
LAIKA CARAVANS S.p.A. Customer Service Department
