ArduCAM 8MP IMX179 Quick Start Manual

Auto Focus USB
Camera Module
8MP IMX179
(SKU: UB0240)
QUICK START GUIDE
SPECS
Sensor 1/3.2" IMX179
Resolution 8MP 3264H x 2448V
Pixel Size 1.4 µm x 1.4 µm
Data Format MJPG/YUY2
MJPG: 30fps@640 x 480/600 x 800/1024x
768/1280 x 720 /1280 x 960/1600 x
1200/1920 x 1080/2048 x 1536/2592 x
1944/3264 x 2448
Frame Rate
YUY2: 1fps@3264 x 2448; 2fps@2592 x
1944/2048 x 1536; 5fps@1920 x 1080/1600
x 1200; 7.5fps@1280 x 960; 10fps@1280 x
720; 15fps@1024 x768; 25fps@800 x 600;
30fps@640 x 480.
Field of View 62°(H)
Lens Mount M6.5*P0.25 mm
IR Sensitivity Integral IR filter, visible light only
Functionality and Compatibility
Auto Controlled Contrast/ Saturation/ Exposure / White
Features balance /Sharpness
Audio Single Microphone
Win7/8/10, Android, Linux, and Mac OS
Compatibility
Power Supply DC 5V
Working Current MAX 300mA
Operating Temp. -4°F~158°F (-20°C~+70°C)
62x9x6mm
Dimension
Connector No. SM05B-SRSS-TB
Cable Length 3.3ft (1M)
Camera
Lens
Power
Physical
INTRODUCTION
•
About Arducam
Arducam has been a professional designer and
manufacturer of SPI, MIPI, DVP and USB cameras
since 2012. We also offer customized turnkey
design and manufacturing solution services for
customers who want their products to be unique.
•
About this USB Camera
The UB0240 is a new member of the Arducam's
USB camera family. It's a 8MP, UVC compliant, USB
2.0 camera. This USB camera is based on the
1/3.2" Sony IMX179 image sensor, and you can
read more about its specs in the next chapter.
Arducam also provides the sample application that
demonstrates some of the features of this camera.
•
About UVC
The UB0240 is a UVC-compliant camera. The native
UVC drivers of Windows, Linux and Mac shall be
compatible with this camera so that it does not
require extra drivers to be installed.
•
About Customer Service
If you need our help or want to customize other
models of USB cameras, feel free to contact us at
support@arducam.com
LENS DIAGRAM
QUICK START
•
How to download the program
Download the APP AMCap from the following link
https://www.arducam.com/downloads/app/
AMCap.exe
NOTE:
1. If used with the Andriod device, USB Camera
APP and connect adapter are needed.
2. For Mac OS, please open the native software
facetime and select the video camera "USB
.
Camera"
•
How to connect the camera
Connect the one end of the USB 2.0 cable to the
USB 2.0 connector provided on the back of
UB0240, and connect the other end to the USB 2.0
host controller on the computer.
