Max Music 173.223 Quick Start Manual

Guitar Tuner
CLIP-ON DIGITAL TUNER
Clip-on digital tuner
1 Power / Mode button
2 Display
a Note name
b String number
Chromatic / Guitar / Bass
c
/ Violin / Ukulele
d Measuring range
3 Clip
4 Battery compartment
Inserting the battery
Unscrew the battery lid safety screw. Press on the battery compartment cover as marked on the back of the device. Open the compartment and
insert a fresh CR2032 battery, paying close attention to the polarity. The life of the battery depends on the conditions of use.
Note: If the device does not work as described in this manual, and you do not solve the problem by switching it off and on again, remove the
battery and reinstall it to possibly solve the problem.
Operating
1. Attach the device to your instrument via the clip.
2. Press and hold the button for 2 seconds to turn the unit on.
3. Select the tuning. Press the button repeatedly to select 'Chromatic', 'Guitar', 'Bass', 'Violin' or 'Ukulele' as the tuning.
▪ If you select 'Chromatic', the display will show the note name.
▪ If you select 'Guitar', 'Bass', 'Violin' or 'Ukulele', the display will show the string number and the note name.
4. Play a single note on your instrument, the note name or string number is displayed. The backlight changes and the measuring range is
displayed.
▪ If the backlight turns green and the gauge is centered, the note is in tune correctly.
▪ If the backlight stays white and the indicator is pointing to the left, the tuning is too low.
▪ If the backlight stays white and the display is pointing to the right, the tuning is too high.
5. If the unit does not detect any signal for 3 minutes after switching it on, it will switch off automatically.
Clip-on DIGITALER STIMMGERÄT
Ein/Aus-Taste / Modus, Power / Mode button
Display
Musiknote
Nummer der Saite
Chromatisch / Gitarre / Bass / Violine / Ukulele
Meßbereich
Clip
Batteriefach
Afinador digital de Clip-on
Botón de encendido / modo
Display
Nombre de la nota
Número de cuerda
Cromática / Guitarra / Bajo /
Violín / Ukelele
Rango de medición
Clip
Compartimiento de la batería
Tuner digital clipsable
Bouton "Power / Mode
Afficher
Nom de la note
Numéro de la chaîne
Chromatique / Guitare / Basse
/ Violon / Ukulélé
Plage de mesure
Clip
Compartiment des piles
