Summary of Contents for Pytes ECOX 3
- Page 1 PORTABLE POWER STATION USER MANUAL...
-
Page 3: Safety Instructions
SAFETY INSTRUCTIONS IMPORTANT SAFETY INFORMATION Please read and understand all safety instructions carefully to ensure safe operation and application of the power station. Severe injury or property damage may be caused by failure to follow instructions. The loss caused by misuse of POWER STATION is not covered by our Warranty CHARGE NOW Please FULLY charge the POWER STATION as soon as possible once you receive it. -
Page 4: Feature Details
FEATURE DETAILS 1. LCD Screen Display 2. AC Outlet 3. USB-QC3.0 4. USB-TYPE-C 60W 5. DC Input 6. Cigarette Lighter Output 7. Flashlight 8. Handle 9. Protective Cover 10. Power ON/OFF Button 11. Flashlight ON/OFF Button 12. AC Output ON/OFF Button... -
Page 5: Function Buttons
OPERATION GUIDE FUNCTION BUTTONS Power ON/OFF Button AC ON/OFF Button Flashlight ON/OFF Button 11: POWER ON/OFF Button POWER ON/OFF BUTTON is the Master Switch. Press POWER ON/OFF BUTTON to activate the AC BUTTONS. 12: Flashlight ON/OFF Button Press FLASHLIGHT BUTTON once to turn on the flashlight, press it again to turn off the flashlight. -
Page 6: Lcd Features
OPERATION GUIDE LCD FEATURES A: Battery Level B: Input Power C: Remaining Charging Time D: Output Power E: Remaining Usage Time F: Low Voltage Warning G: Temperature Warning DETAILS DISPLAYED ON LCD Battery Level: The percentage figures and the number of battery bars represent remaining capacity. -
Page 7: General Specifications
GENERAL SPECIFICATIONS Model ECOX 3 Battery Lithium Battery Capacity 231Wh (22.2V, 10.4Ah) Dimensions L7.6*W5.6*H5.8 in Weight 6.08 lbs (2.76 kg) Charging Temperature 32 to 104°F (0 to 40°C) Discharging Temperature 14 to 104°F (-10 to 40°C) DC Input 12-28V, 48W Max... - Page 8 GENERAL SPECIFICATIONS NOTICE: Available in multiple AC outlet types. Country Voltage/Frequency Country Voltage/Frequency Universal Israel 220V, 50Hz China 220V, 50Hz Australia 240V, 50Hz Japan 100V, 50Hz/60Hz 230V, 50Hz Philippines 220V, 60Hz Germany 230V, 50Hz Korea 220V, 50Hz France 230V, 50Hz South 120V, 60Hz 220V, 50Hz...
-
Page 9: How To Charge
OPERATION GUIDE HOW TO CHARGE From Solar Charger depends on the solar conditions From Car Port 12V From Wall Charger 100 - 240V RECOMMEND TO UNPLUG THE POWER STATION WHEN IT’S FULLY CHARGED. POWERING / CHARGING DEVICES Select the required outlet by pressing the corresponding switch button. The Outlet will be activated when the indicator on the button lights up green. - Page 10 OPERATION GUIDE APPLICANCE WATTS REFERENCE Laptops 32" TV CPAP without heated (41.4Wh) (60W) humidifier (15W) Mini Fridge Smartphone DJ Drone (40W) (10Wh) (89.2Wh) Gopro Floodlight Switch (5.9Wh) (4W) (16Wh) Please power/charge the appliances within the rated power of power station. The Watts/Watt Hours listed above are just for reference and not suitable for all cases.
-
Page 11: Troubleshooting
TROUBLESHOOTING Recharge as you need. There are no pre-designated intervals at which to recharge as long as the POWER STATION is used regularly. Avoid fully depleting the battery to 0%, it will impact the quality and lifespan of the battery. Periodically inspect all ports and wall chargers for any debris, dirt, damage, and corrosion. - Page 12 TROUBLESHOOTING Indicator Phenomenon Solutions Please charge/power the devices within the rated AC Output power. Otherwise, the POWER STATION will Overload Warning automatically turn off. Please charge/power the devices within the rated AC Output Off power. And then push the AC button to restart. Please charge/power the devices within the rated DC Output Voltage of DC and then press the ON/OFF...
- Page 13 TROUBLESHOOTING Problem Solutions Remark Check if the AC adapter plug is fully Confirm whether it is a connecting plugged into the DC Input and Wall issue. Outlet. Unable to Charge If the connection is good, check that If the light is still off, please contact the AC adapter light is on.
- Page 14 WARNINGS The warnings in this manual cannot cover all possible conditions or situations that may occur. Please use the POWER STATION with common sense and caution. Always be aware of the environment around you while using the device and ensure safe and responsible use of POWER STATION.
-
Page 15: Warranty
Avoid extreme temperature. items according to local regulations. WARRANTY PYTES (USA) Energy, INC provides a limited warranty for the original consumer’s purchase, which covers the products due to defective workmanship and materials for 12 months from the date of purchase. - Page 16 920 S Holgate St STE 107,Seattle,WA 98134 pytesusa@pytesgroup.com (+206) 407 4974 www.pytesusa.com Scan to follow us...
