  • Page 1 DS Agile H38x Global Documentation H38x/EN GL/D11...
  • Page 3 DS Agile H38x Global Documentation CONTENTS INTRODUCTION SAFETY AND HANDLING FUNCTIONAL DESCRIPTION TECHNICAL DATA INSTALLATION MAKING CONNECTIONS TO THIS PRODUCT MAINTENANCE CONFIGURATION & SETTINGS APPLICATIONS GLOSSARY...
  • Page 4 Please, contact the appropriate Alstom technical sales office and request the necessary information. Refer to the System Release Notes for new features. Any agreements, commitments, and legal relationships and any obligations on the part of Alstom, including settlement of warranties, result solely from the applicable purchase contract, which is not...

  • Page 5: Table Of Contents

    Packing and Unpacking Guarantees Copyrights & Trademarks 2.9.1 Copyrights 2.9.2 Trademarks 2.9.3 Warnings regarding use of Alstom products FUNCTIONAL DESCRIPTION Parallel Redundancy Protocol (PRP) Base-Tx Ethernet Switch function SNMP Management 3.3.1 H38x System MIB Structure 3.3.2 H38x Interface MIB Structure 3.3.3...
  • Page 6 H38x/EN GL/D11 Global Documentation Page 2/53 DS Agile H38x 3.5.1 LED Indications 3.5.2 Alarm contacts 3.5.3 TELNET Port TECHNICAL DATA DS Agile H38x Range Conformity Ethernet Port Characteristics 4.3.1 10/100Base-Tx Port 4.3.2 100Base=Fx Multimode Port 4.3.3 100Base-Fx Single Mode Port General Characteristics 4.4.1 Mechanical...
  • Page 7 Global Documentation H38x/EN GL/D11 DS Agile H38x Page 3/53 CONFIGURATION AND SETTINGS Login Passwords and Access Levels 8.2.1 Setting the root (administrator) password 8.2.2 Setting the user password 8.2.3 Setting the SNMP V3 Administrator Password 8.2.4 Setting the SNMP V3 Operator Password Configuration commands Management commands 8.4.1...
  • Page 8 H38x/EN GL/D11 Global Documentation Page 4/53 DS Agile H38x FIGURES FIGURE 1: DS AGILE H38X FUNCTIONAL DIAGRAM FIGURE 2: EXAMPLE PRP REDUNDANT NETWORK FIGURE 3: SNMP MANAGEMENT FIGURE 4: H38X FRONTPLATE SHOWING LED ALLOCATION FIGURE 5: H38X CONNECTION INTERFACES SHOWING LED POSITION FIGURE 6: TYPICAL TELNET CONNECTION FIGURE 7: H38X DIN RAIL MOUNTING DETAILS FIGURE 8: H38X CONNECTION POINTS...

  • Page 9: Introduction

    These features mean that DS Agile products can be used in applications, from the most basic to the most demanding. They also ensure interoperability with existing components. Alstom provides a range of Ethernet products such as switches, which take into account the compulsory requirements of electrical substations, including power supply and immunity to environmental constraints.

  • Page 10: Ds Agile H38X

    H38x/EN GL/D11 Global Documentation Page 6/53 DS Agile H38x DS Agile H38x The DS Agile H38x is a range of standalone Ethernet Switches embedded with the Parallel Redundancy Protocol (PRP according to IEC 62439-3) to provide redundancy of communications. The product also supports the Precision Time Protocol (PTP) according to IEEE 1588 v2 to provide highly accurate time synchronisation.

  • Page 11: Safety And Handling

    However, the manuals cannot cover all conceivable circumstances or include detailed information on all topics. In the event of questions or specific problems, do not take any action without proper authorization. Contact the appropriate Alstom technical sales office and request the necessary information.

  • Page 12: Symbols

    H38x/EN GL/D11 Global Documentation Page 8/53 DS Agile H38x Symbols For safety reasons the following symbols which may be used on the equipment or referred to in the equipment documentation, should be understood before it is installed or commissioned. Caution: refer to equipment documentation Caution: risk of electric shock Protective Conductor (*Earth) terminal Functional/Protective Conductor...

  • Page 13: De-Commissioning And Disposal

    Global Documentation H38x/EN GL/D11 DS Agile H38x Page 9/53 of the equipment documentation, or otherwise required by local or country wiring regulations. The protective conductor (earth) connection must be low-inductance and as short as possible. Before energizing the equipment, the following should be checked: Voltage rating/polarity (rating label/equipment documentation);...

  • Page 14: Technical Specifications For Safety

    The electronic circuits of Alstom products are immune to the relevant levels of electrostatic discharge when housed in their cases. Do not expose them to the risk of damage by withdrawing modules unnecessarily.

  • Page 15: Packing And Unpacking

    The reader should consult Alstom if errors are suspected. In no event shall Alstom be liable for any damages arising from or related to this document or the information contained in it.

  • Page 16: Copyrights & Trademarks

    Alstom. 2.9.2 Trademarks DS Agile, DS Agile SCE, DS Agile ES, DS Agile OI, DS Agile SMT, Alstom - are trademarks of Alstom. Product and company names mentioned herein are trademarks or trade names of their respective companies. 2.9.3...

  • Page 17: Functional Description

    Global Documentation H38x/EN GL/D11 DS Agile H38x Page 13/53 FUNCTIONAL DESCRIPTION The H38x enables Ethernet equipped devices to connect via a Parallel Redundancy Protocol (PRP in accordance with IEC 62439-3). Devices connect to the switch by electrical connections using RJ45 connectors. These connections comply with 10/100Base-Tx. Three ports are provided.

  • Page 18: Base-Tx Ethernet Switch Function

    H38x/EN GL/D11 Global Documentation Page 14/53 DS Agile H38x The figure below shows an example of a PRP network. The doubly attached nodes DANP 1 and DANP 2 have full node redundancy, while the singly attached nodes SAN 1 and SAN 4 do not have any redundancy.

  • Page 19: Snmp Management

    The MIB then serves as a data dictionary or codebook that is used to assemble and interpret SNMP messages. For this product, the Alstom management information bases (MIB) use the following types of object identifiers (OID): −...

  • Page 20: H38X System Mib Structure

    H38x/EN GL/D11 Global Documentation Page 16/53 DS Agile H38x 3.3.1 H38x System MIB Structure Address Name Ccitt Internet mgmt Mib-2 sysDescr Redundant switch PRP sysObjectID sysUpTime Time (in hundredths of a second) since the switch was last reinitialised sysContact user-configurable sysName SRP2xx (user-configurable) sysLocation...

  • Page 21: H38X Rmon Mib Structure

    Global Documentation H38x/EN GL/D11 DS Agile H38x Page 17/53 3.3.3 H38x RMON MIB Structure Address Name Ccitt Internet mgmt Mib-2 RMON stat etherstatsTable etherStatsIndex etherStatsBroadcastPkts etherStatsMulticastPkts etherStatsCRCAlignErrors etherStatsUndersizePkts etherStatsOversizePkts etherStatsFragments etherStatsJabbers etherStatsCollision etherStatsPkts64Octets etherStatsPkts65to127Octets etherStatsPkts128to255Octets etherStatsPkts256to511Octets etherStatsPkts512to1023Octets etherStatsPkts1024to1518Octets 3.3.4 H38x PRP MIB Structure Address Name Ccitt...

  • Page 22: Snmp Client Software

    H38x/EN GL/D11 Global Documentation Page 18/53 DS Agile H38x Address Name nodeType nodeName versionName macAddressA macAddressB linkStatusA linkStatusB 3.3.5 SNMP Client Software Readily available Management Information Bases (MIB) browser software enables you to perform all the basic Simple Network Management Protocol (SNMP) operations, such as GET, GETNEXT, and RESPONSE, by connecting to the switch.

  • Page 23: Time Synchronisation

    Global Documentation H38x/EN GL/D11 DS Agile H38x Page 19/53 Time Synchronisation This product supports real-time clock synchronisation using Precision Time Protocol (PTP in accordance with IEEE1588) to provide IRIG-B time, and Network Time Protocol (NTP) for the timestamp of logs or events. A one pulse-per-second (PPS) signal is generated and is displayed on an LED labelled as “Heartbeat”...

  • Page 24: Figure 4: H38X Frontplate Showing Led Allocation

    H38x/EN GL/D11 Global Documentation Page 20/53 DS Agile H38x FIGURE 4: H38X FRONTPLATE SHOWING LED ALLOCATION Eight LEDs are located with the connectors as shown in the figure below. FIGURE 5: H38X CONNECTION INTERFACES SHOWING LED POSITION The table below explains the allocation and meaning of these LEDs. Allocation Meaning Port 3 Activity...

  • Page 25: Alarm Contacts

    Global Documentation H38x/EN GL/D11 DS Agile H38x Page 21/53 3.5.2 Alarm contacts Alarm contacts are provided to give indication of power supply problems, and problems with the parallel redundancy protocol (PRP) ports. Power supply problems are annunciated on terminals C and 1 on the connector located towards the power supply connections as labelled on the front panel.

  • Page 26: Technical Data

    H38x/EN GL/D11 Global Documentation Page 22/53 DS Agile H38x TECHNICAL DATA DS Agile H38x Range 10/100Base-Tx 100 Base-Fx 100 Base-Fx Single Ports Copper Multimode (PRP) Mode (PRP) DS Agile H382 2 (LC) DS Agile H384 2 (LC) Conformity (As per Article 10 of EC Directive 2006/95/EC). The products designated “DS Agile H382”, and “DS Agile H384”...

  • Page 27: General Characteristics

    Global Documentation H38x/EN GL/D11 DS Agile H38x Page 23/53 General Characteristics 4.4.1 Mechanical Dimensions 270mm x 171mm x 45mm W x H x D = Weight 1.3 kg Mounting DIN Rail EN50022 4.4.2 Auxiliary Power Supply Supply voltage range 24 to 48 Vdc 110 to 220 Vdc &...
  • Page 28 H38x/EN GL/D11 Global Documentation Page 24/53 DS Agile H38x 4.6.1.1 Dielectric withstand Standard: IEEE 1613 / IEC 60255-5 / ANSI/IEEE C37.90 Application mode Group under test Test level Housing Not applicable Power supply 2kVrms ; 50 Hz ; 1min Alarm contact 2kVrms ;...

  • Page 29: Electromagnetic Compatibility

    Global Documentation H38x/EN GL/D11 DS Agile H38x Page 25/53 Earth connector Copper Ethernet port IRIG-B connector Housing Power supply Alarm contact Earth connector Copper Ethernet port IRIG-B connector 4.6.1.4 Earthing continuity Standard: IEC 61131-2 Application mode Group under test Test level Housing Resistance <...
  • Page 30 H38x/EN GL/D11 Global Documentation Page 26/53 DS Agile H38x 800MHz to 960MHz & 30 V/m @ 1kHz 80% am ; 1.4GHz to 6GHz Power supply Alarm contact Earth connector Copper Ethernet port IRIG-B connector Standard: IEC 61850-3/ IEEE 1613/ ANSI/IEEE C37.90.2 Application mode Group under test Test level...
  • Page 31 Global Documentation H38x/EN GL/D11 DS Agile H38x Page 27/53 4.6.2.4 Surge Immunity Standard: IEC 61850-3 / EN 61000-4-5 Application Group under test Test level mode Housing Power supply Class 4 : ± 4kV ; 12Ω Alarm contact Class 4 : ± 4kV ; 42Ω Earth connector Copper Ethernet port Class 4 : ±...
  • Page 32 H38x/EN GL/D11 Global Documentation Page 28/53 DS Agile H38x IRIG-B connector 4.6.2.7 Pulse magnetic field immunity Standard: EN 61000-4-9 Application mode Group under test Test level Housing Class 5 : 1000A/m Power supply Alarm contact Earth connector Copper Ethernet port IRIG-B connector 4.6.2.8 Damped oscillatory magnetic field immunity...
  • Page 33 Global Documentation H38x/EN GL/D11 DS Agile H38x Page 29/53 100kHz & ±2,5kV ; 1MHz Fast damped oscillatory wave, Class 4 : ± 4kV ; 3MHz & ± 4kV ; 10MHz & ± 4kV ; 30MHz Alarm contact Slow damped oscillatory wave, Class 3 : ± 2,5kV ; 100kHz &...

  • Page 34: Dc Auxiliary Power Supply

    H38x/EN GL/D11 Global Documentation Page 30/53 DS Agile H38x Alarm contact Earth connector Copper Ethernet port IRIG-B connector 4.6.3 DC auxiliary power supply 4.6.3.1 Voltage variations immunity Standard: IEC 61850-3/ IEEE 1613 / IEC 60870-2-1 / IEC 61131-2 / IEC 60255-6 Application mode Group under test Test level...

  • Page 35: Ac Auxiliary Power Supply

    Global Documentation H38x/EN GL/D11 DS Agile H38x Page 31/53 4.6.3.6 Fast shut-down/start-up immunity Standard: IEC 61131-2 Application mode Group under test Test level Power supply 3 cycles : 5s shut-down ramp ; 5s start- up ramp ; 1 to 5s @ Un 4.6.3.7 Reversal of DC power supply polarity immunity Standard: IEC 60255-11...

  • Page 36: Atmospheric

    H38x/EN GL/D11 Global Documentation Page 32/53 DS Agile H38x 4.6.4.4 Voltage dip immunity Standard: EN 60255-11 / IEC 61000-4-11 Application mode Group under test Test level Power supply 40% Un @200ms (dip 60%) & 70% Un @ 500ms (dip 30%) & 20% Un @ 5s (dip 20%) 4.6.4.5 Voltage interruptions immunity...

  • Page 37: Mechanical

    Global Documentation H38x/EN GL/D11 DS Agile H38x Page 33/53 Application mode Group under test Test level Energised Housing 70 kPa ≤ air pressure ≤ 106 kPa 4.6.6 Mechanical 4.6.6.1 Stationnary vibration sinusoidal immunity Standard: IEC 61850-3/ IEEE 1613 / IEC 60870-2-2 / IEC 60068-2-6 Application mode Group under test Test level...

  • Page 38: Low Voltage Directive

    H38x/EN GL/D11 Global Documentation Page 34/53 DS Agile H38x Application mode Group under test Test level Not energised Housing Class 2 : 2g horizontal axis ; 7,5mm & 1g vertical axis ; 3,5mm 4.6.7 Low Voltage Directive Standard: EN 60950-1 Application mode Group under test Test level...

  • Page 39: Installation

    Global Documentation H38x/EN GL/D11 DS Agile H38x Page 35/53 INSTALLATION This product is designed for mounting on a standard DIN Rail only. The mounting brackets are shown in the figure below FIGURE 7: H38X DIN RAIL MOUNTING DETAILS...

  • Page 40: Making Connections To This Product

    H38x/EN GL/D11 Global Documentation Page 36/53 DS Agile H38x MAKING CONNECTIONS TO THIS PRODUCT As well as connections to the Ethernet networks, this product requires auxiliary power supply connection and safety earth connection. Alarm outputs are provided and these should be connected for system supervision.

  • Page 41: Cable Fitting

    Global Documentation H38x/EN GL/D11 DS Agile H38x Page 37/53 Good conductor surface Cable crimp Copper cable minimum section: 2.5mm² C0047ENb FIGURE 9: EARTHING CABLE EXAMPLE Cable fitting Use of the following cables is recommended: − Screened multi-strand cable must be used for digital input-output signals. For cables within the cubicle, the cable screen can be connected to the earth at both ends of the cable.

  • Page 42: Figure 11: Power Supply Wiring

    H38x/EN GL/D11 Global Documentation Page 38/53 DS Agile H38x WARNING: THE MAIN POWER SUPPLY INPUT REQUIRES A PROTECTIVE SAFETY EARTH TO BE CONNECTED AS SHOWN IN THE FIGURE BELOW. FIGURE 11: POWER SUPPLY WIRING The complete plastic cover must be fitted to the power supply connector as shown in the figure below.

  • Page 43: Alarm Contacts

    Global Documentation H38x/EN GL/D11 DS Agile H38x Page 39/53 Alarm contacts Two sets of alarm contacts are provided. One reflects the state of the power supply. The other reflects the state of the optical PRP ports. A closed contact means an alarm or a fault. The connectors are similar to those used for the power supply, and the same instructions regarding securing the covers apply.

  • Page 44: Maintenance

    BEFORE CARRYING OUT ANY WORK ON THIS PRODUCT YOU SHOULD STUDY THE CONTENTS OF THE SAFETY AND TECHNICAL DATA OF THE ALSTOM SAFETY GUIDE SFTY/4L M/H11 (OR LATER ISSUE) AND THE RATINGS ON THE EQUIPMENT RATING LABEL. YOU SHOULD ALSO READ THE “SAFETY AND HANDLING” SECTION OF THIS DOCUMENT BEFORE CARRYING OUT WORK ON THIS PRODUCT.
  • Page 45 Global Documentation H38x/EN GL/D11 DS Agile H38x Page 41/53 7.3.1.2 Installing a replacement product To reinstall a replacement product: Fit the product to the DIN rail Connect the protective earth connection Connect the power supply connection(s) Make a TELNET connection and set the IP Address, etc. Restore the other connections...

  • Page 46: Figure 14: Remote Connection Prompt

    H38x/EN GL/D11 Global Documentation Page 42/53 DS Agile H38x CONFIGURATION AND SETTINGS The H38x is configured using a series of dialogues between the board and a terminal emulator on a personal computer (PC) or similar device. Connection is made via a TELNET connection over the Ethernet.
  • Page 47 Global Documentation H38x/EN GL/D11 DS Agile H38x Page 43/53 After you have opened a port and logged in, four sets of commands become available. Access will be defined according to root or user level status. The sets of commands are: −...
  • Page 48 H38x/EN GL/D11 Global Documentation Page 44/53 DS Agile H38x Configuration commands Configuration command Syntax Example set IP address setip <ip_addr> setip 192.168.100.12 Set IP netmask setnetmask <ip_addr> setnetmask 255.255.255.0 set gateway IP address setgateway <ip_addr> setgateway 192.168.100.1 Set IP address NTP server setNtpServer <ip_addr>...
  • Page 49 Global Documentation H38x/EN GL/D11 DS Agile H38x Page 45/53 Management commands Management command Syntax Example Hard Reboot reboot reboot Reboot in factory mode rebootFailSafe rebootFailSafe Get all statistics of the switch getSwitchStats getSwitchStats Reset all statistics of the switch switchResetStats switchResetStats Turn a switch port On or Off switchPortOnOff N°...
  • Page 50 H38x/EN GL/D11 Global Documentation Page 46/53 DS Agile H38x You can view switch statistics using the “getSwitchStats” command. The figure below shows the statistics available for each port. InUnicasts 00000000 InBroadcasts 00000000 InPause 00000000 InMulticasts 00000000 InFCSErr 00000000 Undersize 00000000 Fragments 00000000 Jabber...

  • Page 51: Figure 14: H38X Prp Control

    Global Documentation H38x/EN GL/D11 DS Agile H38x Page 47/53 There are three commands associated with controlling the PRP ports. They are outlined in the diagram below: PRP Core prpPortOnOff PRP Port A Port B prpPhyOnOff PrptransceiverADisable FIGURE 15: H38X PRP CONTROL The command “prpPortOnOff”, turns the core port on or off.

  • Page 52: Figure 15: H38X Software Upgrade

    H38x/EN GL/D11 Global Documentation Page 48/53 DS Agile H38x 8.4.1 Upgrading Software From time-to-time you might need to upgrade the switch’s software. This might be to take advantage of new features, or to fix problems. To do this you need the software upgrade files, together with a correctly configured FTP server on a computer with a connection to the board, and the IP address of the host as demonstrated in the figure below.
  • Page 53 Global Documentation H38x/EN GL/D11 DS Agile H38x Page 49/53 You then enter the command “update <IP server address>”. An example is shown in the figure below. Example: ~ # update 192.168.0.1 Command line Received TERM or STOP signal... shutting down... Erasing 128 Kibyte @ 0 - 0% complete.
  • Page 54 Typing in the “getConfig” command will return the switch configuration, an example of which is shown in the figure below: Command line ~ # getConfig Alstom PRP4 version : --------------------- - Board type : BCU - PRP core version : Version 4.111 - HDL version : Version 2.0...
  • Page 55 Global Documentation H38x/EN GL/D11 DS Agile H38x Page 51/53 Typing in the “getSwitchATU” command will return the switch Address Translation (ATU) table: The Address Translation Unit (ATU) performs MAC address searching, learning, and ageing functions for all ports of the switch. By default, the ATU table allows a total of 1024 entries and an ageing time is 300 seconds for each entry.

  • Page 56: Figure 16: Fibre Budget

    H38x/EN GL/D11 Global Documentation Page 52/53 DS Agile H38x APPLICATIONS Fibre Optic budget calculations Optical power is expressed in Watts. However, the common unit of power measurement is the dBm, defined by the following equation: Power (dBm) = 10 log Power (mW) / 1 mW. The fibre optic budget is the difference between the power emitted into the fibre and the sensitivity (minimum amount of power required) of the receiver connected through the fibre optic cable.
  • Page 57 Global Documentation H38x/EN GL/D11 DS Agile H38x Page 53/53 GLOSSARY The fibre optic ports are full/half duplex at 100 Mbps only. 100Base-Fx The copper ports are full/half duplex and auto-sense the 10Base-Tx and transmission speed. They will auto-negotiate with the connected 100Base-TX device to determine the optimal speed.
  • Page 59 Alstom Grid © - ALSTOM 2012. All rights reserved. Information contained in this document is indicative only. No representation or warranty is given or should be relied on that it is complete or correct or will apply to any particular project. This will depend on the technical and commercial circumstances.
