TERMINAL CONNECTIONS

Connect the unit as in the diagram below.
■ EXTERNAL DIMENSIONS unit: mm [inch]
■ CONNECTION DIAGRAM
Detecting
Input X0
circuit
・
・
・
・
・
Detecting
Input XF
circuit
Exc. supply (IN)
Exc. supply (OUT)
Configurator jack
■ 2–Wire Sensor
138 [5.43]
123 [4.84]
115 [4.53]
2 V+
+24V
3 CAN_H
GND
1 Drain
X0
CAN_L
V–
2
+24V
3
GND
1
XF
1
SNSR.EXC+
2
SNSR.EXC–
1
SNSR.EXC+
2
SNSR.EXC–
JACK
2
Detecting
+24V
Circuit
3
GND
1
Xn
5-2-55, Minamitsumori, Nishinari-ku, Osaka 557-0063 JAPAN
Phone: +81(6)6659-8201 Fax: +81(6)6659-8510 E-mail: info@m-system.co.jp
2-4.3 [.17] dia. 4 [.16] deep
To other
DeviceNet
device
R7F4DD-DA16A-C
53 [2.09]
DIN rail
(35mm wide)
(4 [.16])
EM-8007-A P. 5 / 7
