- Page 1 Pentium 4 Full-Size CPU Card With VGA & Dual GIGA LAN User`s Manual Version 1.0...
- Page 2 IBM, PS/2 are trademarks of International Business Machines Corporation. Intel, Pentium4 are registered trademarks of Intel Corporation. Microsoft Windows is a registered trademark of Microsoft Corporation. All other product names or trademarks are properties of their respective owners. P/I-P5SVLL User`s Manual...
-
Page 3: Table Of Contents
CPU Installation ..............10 Memory Installation ............. 11 Jumpers on the P/I-P5SVLL ..........12 Jumper Locations on the P/I-P5SVLL ........13 JP1 ~ 2: CPU Frequency Selector .......... 14 JP3: CMOS RAM Data ............14 ... - Page 4 Standard CMOS Setup ............42 Channel 0 HDDs / Channel 1 HDDs ........44 Drive A / Drive B ..............46 Video ..................46 Halt On ................... 46 Advanced BIOS Features ............ 47 P/I-P5SVLL User`s Manual...
- Page 5 AGP Aperture Size (MB) ............55 Init Display First ..............55 On-Chip VGA Setting ............56 On-Chip VGA ................56 On-Chip Frame Buffer Size............56 Boot Display ................56 Panel Number ................56 OnChip IDE Device ............... 57 P/I-P5SVLL User`s Manual...
- Page 6 ACPI Suspend Type ............... 65 Power Management ..............65 Video Off Method ..............65 Video Off In Suspend ............66 MODEM Use IRQ ..............66 Suspend Mode ................ 66 HDD Power Down ..............66 P/I-P5SVLL User`s Manual...
- Page 7 Frequency/Voltage Control ..........74 Auto Detect DIMM/PCI Clk ..........74 Spread Spectrum ..............74 Load Fail-Safe Defaults ............75 Load Optimized Defaults ............. 75 Set Supervisor/User Password Setting ....... 76 P/I-P5SVLL User`s Manual...
- Page 8 Exit Without Saving ............... 77 4 ................79 Appendix ............79 A. I/O Port Address Map ............ 80 B. Interrupt Request Lines (IRQ) ........81 C. POST Beep ............... 82 viii P/I-P5SVLL User`s Manual...
-
Page 9: Introduction
Chapter 1 Introduction Introduction This manual is designed to give you information on the P/I-P5SVLL SBC card. The topics covered in this chapter are as follows: ♦ Checklist ♦ Description ♦ Features ♦ Specifications P/I-P5SVLL User`s Manual... -
Page 10: Checklist
PS/2 Keyboard and Mouse 1-to-2 Y-cable PS/2 to AT Keyboard Cable Description The P/I-P5SVLL is a Pentium 4 Industrial single board computer (SBC) card based on Intel 865G chipset and is designed for harsh industrial environment. It features one 478-pins Socket, which is compatible with Intel uFC-PGA package Pentium 4 processor. - Page 11 800MHz FSB. The P/I-P5SVLL comes with integrated hardware monitoring device that monitors system and CPU temperature, voltages of all system power rails, and CPU fan speeds to prevent system crashes by warning the user of adverted conditions.
-
Page 12: Features
Intel 865G integrated IEG2 supports excellent 2D/3D performance. Dual Gigabits LAN support Load-Balancing and Fault-Tolerance. Supports LVDS LCD up to Dual Channels 24-bits LCD Panel. Multiple I/O support, up to 6 x USB ports and 2 x COM ports. COM2 is RS232/422/485 selectable. P/I-P5SVLL User`s Manual... -
Page 13: Specifications
6 USB 2.0 ports in 2 x 5-pins pin-header for internal connections. 2 COM ports in 2 x 5-pins box-header support standard RS-232 protocols. COM2 is RS232/422/485 selectable by jumpers. 1 x Parallel port supports SPP/ECP/EPP mode. 1 x IrDA port. 1 x standard 34-pins FDD connector. P/I-P5SVLL User`s Manual... - Page 14 CPU socket. • USB Interface: • Three USB pin-header connectors, compliant with USB Specification Rev. 2.0 and support USB Hot-Plug function. • Support Legacy USB devices and Boot from USB devices like USB-HDD, USB-Floppy and USB-CDROM. P/I-P5SVLL User`s Manual...
- Page 15 338mm (W) x 122mm (L). PICMG 1.0 Full-Size CPU Card Form Factor. • Power Requirement: 6A @ +5V (typical); 8A @ +12V (typical); 100mA @ -12V. • Operating Temperature: 0 to 60°C operating temperature. Relative Humility: 5~95%, non-condensing. P/I-P5SVLL User`s Manual...
- Page 16 Chapter 1 Introduction This page is intentionally left blank. P/I-P5SVLL User`s Manual...
-
Page 17: Installations
Installations This chapter provides information on how to use the jumpers and connectors on the P/I-P5SVLL in order to set up a workable system. The topics covered are: ♦ CPU Installation ♦ Memory Installation ♦ Jumpers on the P/I-P5SVLL ♦ Connectors on the P/I-P5SVLL ♦... -
Page 18: Cpu Installation
Chapter 2 Installations CPU Installation The P/I-P5SVLL Industrial SBC Card provides a 775-pins ZIF socket for Pentium 4 processors with FC-PAG2 package. To Install a CPU, first turn off your system and remove its cover. Locate the ZIP socket and open it by first pulling the lever sideways away from the socket then upwards to a 90-degree right angle. -
Page 19: Memory Installation
Chapter 2 Installations Memory Installation The P/I-P5SVLL Industrial CPU Card provides two 184-pin DIMM sockets for a maximum total memory of 2GB SDRAM. The memory modules can come in sizes of 128MB, 256MB, 512MB and 1GB SDRAM. The P/I-P5SVLL Industrial CPU Card supports two 184-pin DIMM (Dual In-line Memory Module) sockets. -
Page 20: Jumpers On The P/I-P5Svll
Chapter 2 Installations Jumpers on the P/I-P5SVLL The jumpers on the P/I-P5SVLL allow you to configure your SBC card according to the needs of your applications. If you have doubts about the best jumper configuration for your needs, contact your dealer or sales representative. -
Page 21: Jumper Locations On The P/I-P5Svll
Chapter 2 Installations Jumper Locations on the P/I-P5SVLL COM2MODE1 JP10 P/I-P5SVLL User`s Manual... -
Page 22: Jp1 ~ 2: Cpu Frequency Selector
Jumper cap back to pin1& 2. (5) Turn on your computer, (6) Hold Down <Delete> during bootup and enter BIOS setup to enter your preferences. Setting Function Pin 1-2 Normal Operation Short/Closed (default) Pin 2-3 Clear CMOS Short/Closed Content P/I-P5SVLL User`s Manual... -
Page 23: Jp4~ 5: On-Board Lan Enable/Disable Selection
JP7 can be used to select the Panel LCD supple power: +3.3V or +5V. The default setting is on +3.3V.User need to check the LCD panel spec and adjust this jumper and make Panel work in specified power rail. +3.3V JP7: Panel Brightness Selection OFF: Min Brightness. Max Brightness (Default). P/I-P5SVLL User`s Manual... -
Page 24: Jp8: Panel Channel Selection
OFF: For rising edge latch data (Default). ON: For falling edge latch data. JP10: Panel Input Data Format Type Selection OFF: For Non-conventional color mapping 24bits LCD. ON: For 18bits and Conventional color mapping 24bits LCD (Default). P/I-P5SVLL User`s Manual... -
Page 25: Com2Mode1: Com2 Rs232/Rs422/Rs485 Selection
Chapter 2 Installations COM2MODE1: COM2 RS232/RS422/RS485 Selection COM2MODE1 I/F TYPE RS-232 RS-422 RS-485 P/I-P5SVLL User`s Manual... -
Page 26: Connectors On The P/I-P5Svll
The connectors on the P/I-P5SVLL allows you to connect external devices such as keyboard, floppy disk drives, hard disk drives, printers, etc. The following table lists the connectors on P/I-P5SVLL and their respective page number. Connecter Locations on the P/I-P5SVLL ....... 19 Front Panel Connector ............ -
Page 27: Connector Locations On The P/I-P5Svll
Chapter 2 Installations Connector Locations on the P/I-P5SVLL IDE1 LAN-LED1 LAN1 IDE2 LAN2 CD-IN LAN-LED2 PS2KB+MS AUDIO AT-KB COM1 SMBUS PRINTER COM2 SATA1 IRDA SATA2 USB56 USB34 USB12 ATX-PWR DDR2 LVDS LCD DDR1 AT-PWR SYS-FAN FLOPPY CPU-FAN ATX-12V FRONT-PANEL P/I-P5SVLL User`s Manual... -
Page 28: Front Panel Connector
Off and then On. Orientation is not required when making a connection to this header. RESET Signal Name Pin # Reset Reset Ground Power-On LED This connector allows users to connect to Front Panl Power indicator. IDE LED Signal Name Pin # Ground P/I-P5SVLL User`s Manual... - Page 29 This 2-pin connector acts as the “Power Supply On/Off Switch” on the SBC card. When pressed, the switch will force the SBC card to power on. When pressed again, it will force the SBC card to power off. PWR BTN Signal Name Pin # Power PWR-BTN Button P/I-P5SVLL User`s Manual...
-
Page 30: Eide Connectors
Host data 0 Host data 15 Ground DRQ0 Ground Host IOW Ground Host IOR Ground IOCHRDY Host ALE DACK0 Ground IRQ14 No connect Address 1 No connect Address 0 Address 2 Chip select 0 Chip select 1 Activity Ground P/I-P5SVLL User`s Manual... - Page 31 Host data 0 Host data 15 Ground DRQ1 Ground Host IOW Ground Host IOR Ground IOCHRDY Host ALE DACK1 Ground IRQ15 No connect Address 1 No connect Address 0 Address 2 Chip select 0 Chip select 1 Activity Ground P/I-P5SVLL User`s Manual...
-
Page 32: Floppy Drive Connector
Drive select 1 Ground Drive select 0 Ground Motor enable 1 Ground Direction Ground Step Ground Write data Ground Write gate Ground Track 00 Ground Write protect Ground Read data Ground Side 1 select Ground Diskette change P/I-P5SVLL User`s Manual... -
Page 33: Parallel Port Connector
PD2, parallel data 2 Select PD3, parallel data 3 Ground PD4, parallel data 4 Ground PD5, parallel data 5 Ground PD6, parallel data 6 Ground PD7, parallel data 7 Ground ACK, acknowledge Ground Busy Ground Paper empty Ground Select Ground P/I-P5SVLL User`s Manual... -
Page 34: Com1 Serial Port
RI, Ring indicator N.C. COM2 Serial Port COM2, a 10-pin header connector, is the onboard COM2 serial port of the P/I-P5SVLL. The following table shows its pin assignments while it is configured as RS-232, RS-422 or RS-485 interface. RS232 Mode RS422/RS485 Mode... -
Page 35: External Keyboard Connector
Y-cable and plug into this Mini-Din connector. All the P3BVLL SBC boards come with a Y-cable. Contact with your dealer if the Y-cable is missing. Pin # Signal Name Keyboard data Mouse data Keyboard clock Mouse clock P/I-P5SVLL User`s Manual... -
Page 36: Vga Connector
This is a 3-pin header for the CPU fan. The fan must be a 12V fan. Pin # Signal Name Ground +12V Rotation USB Connectors The following table shows the pin outs of the USB connectors. USB2 USB1 Signal Name USB4 USB3 Pin# Pin # N.C. Ground USB- USB+ P/I-P5SVLL User`s Manual... -
Page 37: Irda Connector
5V_SB (standby +5V) PS-ON (soft on/off) ATX-PWR Chassis Fan Power Connector This is a 3-pin header for the chassis fan. The fan must be a 12V fan. Pin # Signal Name 3 2 1 Ground +12V Rotation P/I-P5SVLL User`s Manual... -
Page 38: Lan- Rj45 Connector
TX/RX activity. The Yellow/Green Dual color LED on the left-hand side indicates the operation mode, i.e. 10Base-T, 100Base-T or 1000Base-T. LNK/ACT STATUS Link Disconnected FLASH Packets TX/RX SPEED MODE Orange 1000 Mbps Green 100 Mbps 10 Mbps P/I-P5SVLL User`s Manual... -
Page 39: Lanled Connectors
The Power good signal will be generated by the circuit on the SBC card. Pin 1 is replace with +5V power to increase supply current. Pin # Signal Name +12V -12V P/I-P5SVLL User`s Manual... -
Page 40: Cd_In Connectors
CD_INconnector is designed for wire the CD_ROM audio signals to the on-board Audio CODEC. LAN LED Signal Name Pin # 4 3 2 1 CD_Left CD_AGND CD_AGND CD_Right Audio Connectors LAN LED Signal Name Pin # Jack Detect Vreference MIC-IN AGND AGND LINE-OUT-L LINE-IN-L LINE-OUT-R LINE-IN-R P/I-P5SVLL User`s Manual... -
Page 41: Lcd Lvds Connector
TXC+ TXC- LCD_VCC LCD_VCC Note: Contact your dealer for LCD Cable kit and Video BIOS customization. WOL Connectors Pin # Signal Name 5VSB 3 2 1 PME- SATA Connectors Pin # Signal Name SATARX+ SATARX- SATATX- SATATX+ P/I-P5SVLL User`s Manual... -
Page 42: Watchdog Timer Configuration
I/O port 043H for the system to stop the watchdog function. The timer has a tolerance of 20% for its intervals. The following describes how the timer should be programmed. Enabling Watchdog DX, 0843H DX, AX Disabling Watchdog DX, 043H DX, AX P/I-P5SVLL User`s Manual... -
Page 43: Bios Configuration
BIOS Configuration This chapter describes the different settings available in the Award BIOS that comes with the P/I-P5SVLL CPU card. The topics covered in this chapter are as follows: ♦ BIOS Introduction ♦ Main Menu ♦ Standard CMOS Setup ♦ Advanced BIOS Features ♦... -
Page 44: Bios Introduction
1. By pressing <Del> immediately after switching the system on, or 2. by pressing the <Del> key when the following message appears briefly at the bottom of the screen during the POST (Power On Self-Test). Press DEL to enter SETUP. P/I-P5SVLL User`s Manual... -
Page 45: Using Setup
General help on Setup navigation keys F5 key Load previous values from CMOS F6 key Load the fail-safe defaults from BIOS default table F7 key Load the optimized defaults F10 key Save all the CMOS changes and exit P/I-P5SVLL User`s Manual... - Page 46 Use the left and right arrow keys to choose the menu you want to be in. To display a sub menu Use the arrow keys to move the cursor to the sub menu you want. Then press <Enter>. A “ ” pointer marks all sub menus. P/I-P5SVLL User`s Manual...
-
Page 47: Getting Help
These defaults have been carefully chosen by both Award and P5SVLL manufacturer to provide the absolute maximum performance and reliability. Even a seemingly small change to the chipset setup has the potential for causing you to use the override. P/I-P5SVLL User`s Manual... -
Page 48: Main Menu
Setup Items The main menu includes the following main setup categories. Standard CMOS Features Use this menu for basic system configuration. Advanced BIOS Features Use this menu to set the Advanced Features available on your system. P/I-P5SVLL User`s Manual... -
Page 49: Advanced Chipset Features
Supervisor / User Password Use this menu to set User and Supervisor Passwords. Save & Exit Setup Save CMOS value changes to CMOS and exit setup. Exit Without Save Abandon all CMOS value changes and exit setup. P/I-P5SVLL User`s Manual... -
Page 50: Standard Cmos Setup
[None] Drive A [1.44M, 3.5 in.] Drive B [None] Video [EGA/VGA] Halt On [No Errors] Base Memory 640K Extended Memory 1038336K Total Memory 1039360K ↑↓←→Move Enter:Select +/-/PU/PD:Value F10:Save ESC:Exit F1:General Help F5:Previous Values F6:Fail-Safe Defaults F7:Optimized Defaults P/I-P5SVLL User`s Manual... - Page 51 All, but Disk/Key Base Memory Displays the amount of conventional memory detected during boot up Extended Memory Displays the amount of extended memory detected during boot up Total Memory Displays the total memory available in the system P/I-P5SVLL User`s Manual...
-
Page 52: Channel 0 Hdds / Channel 1 Hdds
↑↓←→Move Enter:Select +/-/PU/PD:Value F10:Save ESC:Exit F1:General Help F5:Previous Values F6:Fail-Safe Defaults F7:Optimized Defaults master sub menu. Use the legend keys to navigate through this menu and exit to the main menu. Use the Table listed below to configure the hard disk. P/I-P5SVLL User`s Manual... - Page 53 Min = 0 **** Warning: Setting a value of Max = 65535 65535 means no hard disk Landing zone Min = 0 **** Max = 65535 Sector Min = 0 Number of sectors per track Max = 255 P/I-P5SVLL User`s Manual...
-
Page 54: Drive A / Drive B
The system boot will not be halted for a disk error; it will stop for all other errors. All, But Disk/Key The system boot will not be halted for a key- board or disk error; it will stop for all others. P/I-P5SVLL User`s Manual... -
Page 55: Advanced Bios Features
Security Option [Setup] APIC Mode [Enabled] MPS Version Control For OS [1.4] OS Select For DRAM > 64MB [Non-OS2] Report No FDD for Win95 [No] ↑↓←→Move Enter:Select +/-/PU/PD:Value F10:Save ESC:Exit F1:General Help F5:Previous Values F6:Fail-Safe Defaults F7:Optimized Defaults P/I-P5SVLL User`s Manual... -
Page 56: Cpu Feature
↑↓←→Move Enter:Select +/-/PU/PD:Value F10:Save ESC:Exit F1:General Help F5:Previous Values F6:Fail-Safe Defaults F7:Optimized Defaults Delay Prior Thermal The choice: 4Min, 8Min, 16Min, 32Min. Thermal Management Limit CPU MaxVal Set Limit CPUID MaxVal to 3, Should Be “Disabled” for WinXp. The choice: Enabled, Disabled P/I-P5SVLL User`s Manual... -
Page 57: Hard Disk Boot Priority
No warning message will appear when anything attempts to access the boot sector or hard disk partition table. CPU L1 & L2 Cache These two categories speed up memory access. However, it depends on CPU/chipset design. Enabled Enable cache Disabled Disable cache P/I-P5SVLL User`s Manual... -
Page 58: Quick Power On Self Test
Boot Up NumLock Status Select power on state for NumLock. The choice: On/Off. Gate A20 Option Select if chipset or keyboard controller should control GateA20. Normal A pin in the keyboard controller controls GateA20 Fast Lets chipset control GateA20 P/I-P5SVLL User`s Manual... -
Page 59: Typematic Rate Setting
MPS Version Control For OS The choice: 1.1, 1.4. OS Select For DRAM > 64MB Select the OS2 only if you are running OS/2 operating system with greater than 64MB of RAM on the system. The choice: Non-OS2, OS2. P/I-P5SVLL User`s Manual... -
Page 60: Report No Fdd For Win 95
Report No FDD For WIN 95 This option allows Windows 95 to share with other peripherals IRQ6 which is assigned to a floppy disk drive if the drive is not existing. The default setting is No. The choice: Yes, No. P/I-P5SVLL User`s Manual... -
Page 61: Advanced Chipset Features
Such a scenario might well occur if your system had mixed speed DRAM chips installed so that greater delays may be required to preserve the integrity of the data held in the slower memory chips. P/I-P5SVLL User`s Manual... -
Page 62: Dram Timing Selectable
The precharge time is the number of cycles it takes for the RAS to accumulate its charge before DRAM refresh. If insufficient time is allowed, refresh may be incomplete and the DRAM may fail to retain data. The choice: 4, 3, 2. P/I-P5SVLL User`s Manual... -
Page 63: System Bios Cacheable
PCI memory address range dedicated for graphics memory address space. Host cycles that hit the aperture range are forwarded to the AGP without any translation. The choice: 4M, 8M, 16M, 32M, 64M, 128M, 256M. Init Display First The choice: PCI Slot, Onboard/AGP P/I-P5SVLL User`s Manual... -
Page 64: On-Chip Vga Setting
The choice: 1MB, 8MB, 16MB. Boot Display The choice: Auto, CRT, LFP, CRT+LFP, EFP, TV, CRT+EFP, CRT+TV. Panel Number The choice: 1, 2, 3, 4, 5, 6, 7, 8, 9, 10, 11, 12, 13, 14, 15, 16. P/I-P5SVLL User`s Manual... -
Page 65: Onchip Ide Device
***On-Chip Serial ATA Setting*** X SATA Mode On-Chip Serial ATA [Auto] X Serial ATA Port0 Mode SATA0 Master Serial ATA Port1 Mode SATA1 Master ↑↓←→Move Enter:Select +/-/PU/PD:Value F10:Save ESC:Exit F1:General Help F5:Previous Values F6:Fail-Safe Defaults F7:Optimized Defaults P/I-P5SVLL User`s Manual... -
Page 66: Ide Hdd Block Mode
(0-4) for each of the four IDE devices that the onboard IDE interface supports. Modes 0 through 4 provide successively increased performance. In Auto mode, the system automatically determines the best mode for each device. The choice: Auto, Mode 0, Mode 1, Mode 2, Mode 3, Mode 4. P/I-P5SVLL User`s Manual... -
Page 67: Primary/Secondary Master/Slave Udma
The choice: Primary Master, Primary Slave, Secondary Master, Secondary Slave, Primary Master, Secondary Master, SATA0 master, SATA1 master. Serial ATA Port1 Mode The choice: Primary Master, Primary Slave, Secondary Master, Secondary Slave, Primary Master, Secondary Master, SATA0 master, SATA1 master. P/I-P5SVLL User`s Manual... -
Page 68: Onboard Device
USB support built in, the support will be automatically turn on when high speed device were attached. The choice: Enabled, Disabled. USB Keyboard Support Select Enabled if your system contains a Universal Serial Bus (USB) controller and you have a USB keyboard. The choice: Enabled, Disabled. P/I-P5SVLL User`s Manual... -
Page 69: Usb Mouse Support
Select Enabled if your system has a floppy disk controller (FDC) installed on the system board and you wish to use it. If you install and-in FDC or the system has no floppy drive, select Disabled in this field. The choice: Enabled, Disabled. P/I-P5SVLL User`s Manual... -
Page 70: Onboard Serial Port 1/Port 2
Select an operating mode for the onboard parallel (printer) port. Select Normal, Compatible, or SPP unless you are certain your hardware and software both support one of the other available modes. The choice: SPP, EPP, ECP, ECP+EPP, Normal. P/I-P5SVLL User`s Manual... -
Page 71: Epp Mode Select
Select EPP port type 1.7 or 1.9. The choice: EPP1.7, 1.9. ECP Mode Use DMA Select a DMA channel for the parallel port for use during ECP mode. The choice: 3, 1. PWRON After PWR-Fail The choice: Off, On, Former-Sts. P/I-P5SVLL User`s Manual... -
Page 72: Power Management Setup
This should be AT if you use AT power supply or ATX power supply but force to AT mode. This selection help BIOS provide the information to OS what kind power-supply the system use. The correct information provide to OS can avoid the Windows Shutdown issue. The choice: AT, ATX. P/I-P5SVLL User`s Manual... -
Page 73: Acpi Function
Blank Screen This option only writes blanks to the video buffer. DPMS Initial display power management signaling. Allows the BIOS to control video display card if it supports the DPMS feature. P/I-P5SVLL User`s Manual... -
Page 74: Video Off In Suspend
The choice: Disabled, 1 min, 2 min, 4 min, ….. 15 min. Soft-Off by PWR-BTTN The choice: Instant-Off, Delay 4 Sec. CPU THRM-Throttling The choice: 75.0%, 50.0%, 25.0% Wake-Up by PCI card The choice: Enabled, Disabled. P/I-P5SVLL User`s Manual... -
Page 75: Power On By Ring
When Enabled, any activity from one of the listed system peripheral devices or IRQs wakes up the system. The choice: Enabled, Disabled. PCI PIRQ[A-D]# When Enabled, any activity from one of the listed PCI IRQ signals wakes up the system. The choice: Enabled, Disabled. P/I-P5SVLL User`s Manual... -
Page 76: Pnp/Pci Configuration Setup
F6:Fail-Safe Defaults F7:Optimized Defaults PNP OS Installed This item allows you to determine install PnP OS or not. If you are using a Plug and Play capable operating system. If you need the BIOS to configure non-boot devices. P/I-P5SVLL User`s Manual... -
Page 77: Reset Configuration Data
PC AT bus specification, PCI/ISA PnP for devices compliant with the Plug and Play standard whether designed for PCI or ISA bus architecture. The Choice: Legacy ISA and PCI/ISA PnP. Memory Resources PCI/VGA Palette Snoop Leave this field at Disabled. Choices are Enabled, Disabled. P/I-P5SVLL User`s Manual... -
Page 78: Int Pin 1 Assignment
Choices are Auto, 3, 4, 5, 7, 9, 10, 11, 12, 14, 15. Assignment Pin 5 Choices are Auto, 3, 4, 5, 7, 9, 10, 11, 12, 14, 15. Assignment Pin 6 Device(s) using this INT: Choices are Auto, 3, 4, 5, 7, 9, 10, 11, 12, 14, 15. P/I-P5SVLL User`s Manual... -
Page 79: Int Pin 7 Assignment
Choices are Auto, 3, 4, 5, 7, 9, 10, 11, 12, 14, 15. Assignment Pin 8 Device(s) using this INT: USB 2.0 EHCI Cntrlr- Bus 0 Dev29 Func7 Choices are Auto, 3, 4, 5, 7, 9, 10, 11, 12, 14, 15. P/I-P5SVLL User`s Manual... -
Page 80: Pc Health Status
CPU Warning Temperature Select the CPU over-heated warning temperature. The choice: Disabled, 50 °C/122°F, 53°C/127°F, 56°C/133°F, 60°C/140°F, 63°C/145°F, 66°C/151°F, 70°C/158°F. Current System Temperature Shows CPU Temperatue. Current CPUDIE Temperature Shows CPU Die Temperatue. Current Board Temperature Show System Temperature. P/I-P5SVLL User`s Manual... -
Page 81: Cpu Fan Speed
Chapter3 BIOS Configuration CPU Fan Speed Shows CPU FAN speed. System Fan Speed Shows System FAN speed. Vcore/1.5V/3.3V/5V/12V/-12V/-5V/VBAT(V)/5VSB(V) Voltages Shows Power rails voltage. Shutdown Temperature Select the CPU over-heated shutdown temperature. The choice: Disabled, 60 °C/140°F, 65°C/149°F, 70°C/158°F, 75°C/167°F. P/I-P5SVLL User`s Manual... -
Page 82: Frequency/Voltage Control
PCI card detect issue. In that case, please disable this item. The choice: Enabled, Disabled. Spread Spectrum This item allows you to enable/disable the spread spectrum modulation. The spread spectrum technology also helps to alleviate the EMI. The choice: Enabled, Disabled. P/I-P5SVLL User`s Manual... -
Page 83: Load Fail-Safe Defaults
When you press <Enter> on this item you get a confirmation dialog box with a message similar to: Load Optimized Defaults (Y/N) ? N Pressing ‘Y’ loads the default values that are factory settings for optimal performance system operations. P/I-P5SVLL User`s Manual... -
Page 84: Set Supervisor/User Password Setting
Features Setup Menu and its Security option. If the Security option is set to “System”, the password will be required both at boot and at entry to Setup. If set to “Setup”, prompting only occurs when trying to enter Setup. P/I-P5SVLL User`s Manual... -
Page 85: Exit Selecting
Pressing <Enter> on this item asks for confirmation: Quit without saving (Y/N)? N This allows you to exit Setup without storing in CMOS any change. The previous selections remain in effect. This exits the Setup utility and restarts your computer. P/I-P5SVLL User`s Manual... - Page 86 Chapter 3 BIOS Configuration This page is intentionally left blank. P/I-P5SVLL User`s Manual...
-
Page 87: Appendix
Appendix ♦ I/O Port Address Map ♦ Interrupt Request Lines (IRQ) ♦ POST Beep P/I-P5SVLL User`s Manual... -
Page 88: I/O Port Address Map
Parallel Port #1(LPT1) 360 - 36F Network Ports 3B0 - 3BF Monochrome & Printer adapter 3C0 - 3CF EGA adapter 3D0 - 3DF CGA adapter 3F0h - 3F7h Floppy Disk Controller 3F8h - 3FFh Serial Port #1(COM1) P/I-P5SVLL User`s Manual... -
Page 89: Interrupt Request Lines (Irq)
Serial Port #1 IRQ5 Reserved IRQ6 Floppy Disk Controller IRQ7 Parallel Port #1 IRQ8 Real Time Clock IRQ9 Software Redirected to Int 0Ah IRQ10 Reserved IRQ11 Reserved IRQ12 PS/2 Mouse IRQ13 80287 IRQ14 Primary IDE IRQ15 Secondary IDE P/I-P5SVLL User`s Manual... -
Page 90: Post Beep
This beep code consists of a single long beep followed by two short beeps. The other code indicates that your DRAM error has occurred. This beep code consists of a single long beep repeatedly. P/I-P5SVLL User`s Manual...
