Inorax Al Cabinet
Installation Guide

Advertisement

loading
Need help?

Need help?

Do you have a question about the CPN Series and is the answer not in the manual?

Questions and answers

Summary of Contents for Canovate CPN Series

  • Page 1 Inorax Al Cabinet Installation Guide...
  • Page 2 Models may have different accessory items such as Perforated Front Door, Glass Door, Adapter etc. Please read through this entire manual before beginning assembly or maintenance Tools Needed inorax AL Cabinets Installation Manual www.canovate.com info@canovate.com P. +90 216 484 2222...
  • Page 3 CPN SERIES CPS SERIES INSTALLATION LIST DIN 912 M10X25 INBUS SCREW DIN 912 M6X12 INBUS SCREW DIN 125 M6 FLAT WASHER M5 X12 TORX BOLT M12X85 ADJUSTABLE FEET M12*20 PLASTIC SCREW BOTTOM FRAME ASSEMBLY TOP FRAME ASSEMBLY VERTICAL PROFILE SIDE SUPPORT RAILS SIDE SUPPORT ADAPTER 19"...
  • Page 4 Assemble Adjustable feet at the Bottom Cover inorax AL Cabinets Installation Manual www.canovate.com info@canovate.com P. +90 216 484 2222...
  • Page 5 Vertical Profiles Fix the Vertical Profiles from both inner sides by using M10x20 Bolt Insert each Vertical Profile as shown below Do not over-tighten. This will damage the bolt www.canovate.com info@canovate.com P. +90 216 484 2222 inorax AL Cabinets Installation Manual...
  • Page 6 Assemble Top Frame Fix the Top Frame from outside by using M10x20 Bolt Do not over-tighten. This will damage the bolt inorax AL Cabinets Installation Manual www.canovate.com info@canovate.com P. +90 216 484 2222...
  • Page 7 Assemble Top Cover Fix the Top Cover from outside by using M12x20 Plastic Bolt Do not over-tighten. This will damage the bolt www.canovate.com info@canovate.com P. +90 216 484 2222 inorax AL Cabinets Installation Manual...
  • Page 8 Side Support Rails Assemble Fix Left and Right Supporting Rails with 4x M6 X12 Bolt inorax AL Cabinets Installation Manual www.canovate.com info@canovate.com P. +90 216 484 2222...
  • Page 9 Assembling 19” Mounting Rails for 800 width Fix Adapters on Side Support Rails for left and right side each Adapter has to be fixed with M5 X12 Torx www.canovate.com info@canovate.com P. +90 216 484 2222 inorax AL Cabinets Installation Manual...
  • Page 10 Mounting rails have to be fixed from 3 point on the cabinet Use the measuring tape and choose a safe distance (from the front door to the 19” mounting rails inorax AL Cabinets Installation Manual www.canovate.com info@canovate.com P. +90 216 484 2222...
  • Page 11 Mounting rails have to be fixed from 3 point on the cabinet Use the measuring tape and choose a safe distance (from the front door to the 19” mounting rails www.canovate.com info@canovate.com P. +90 216 484 2222 inorax AL Cabinets Installation Manual...
  • Page 12 Assemble Double Side Panel When you install Side Panel make sure locks are unlocked. inorax AL Cabinets Installation Manual www.canovate.com info@canovate.com P. +90 216 484 2222...
  • Page 13 Screw Side Panel Profile by Using M6x12 Bolt Drive the lugs in the holes first. The holes are positioned on the bottom cover www.canovate.com info@canovate.com P. +90 216 484 2222 inorax AL Cabinets Installation Manual...
  • Page 14 Lock side panel back inorax AL Cabinets Installation Manual www.canovate.com info@canovate.com P. +90 216 484 2222...
  • Page 15 P. +90 216 484 2222 inorax AL Cabinets Installation Manual...
  • Page 16 Single Side Panel When you install Rear Panel make sure locks are unlocked. Drive the lugs in the holes first. The holes are positioned on the bottom cover inorax AL Cabinets Installation Manual www.canovate.com info@canovate.com P. +90 216 484 2222...
  • Page 17 Rear Panel Fix the Rear Door Locking Point by using M6 X12 Bolt Drive the lugs in the holes first. The holes are positioned on the bottom cover www.canovate.com info@canovate.com P. +90 216 484 2222 inorax AL Cabinets Installation Manual...
  • Page 18 AL Cabinets Installation Manual www.canovate.com info@canovate.com P. +90 216 484 2222...
  • Page 19 Assembling Front Door Insert Pin www.canovate.com info@canovate.com P. +90 216 484 2222 inorax AL Cabinets Installation Manual...
  • Page 20 :www.canovate.com/getconnected © Copyright 2014 Canovate Group, The information contained herein is subject to change without notice. The only warranties for Canovate products and services are set forth in the express warranty statements accompanying such products and services. Nothing herein should be construed as constituting an additional warranty. Canovate shall not be liable for technical or editorial errors or omissions contained herein.

This manual is also suitable for:

Cps series
