nVent SCHROFF RackPower EP23016-0020 Assembly Diagram

TECHNICAL SPECIFICATIONS

MONITORED SWITCHED
UNIT TYPE:
ORIENTATION:
VERTICAL, 0U HALF
OUTLET QTY & TYPE:
INPUT VOLTAGE:
INPUT CURRENT: 20A (16A DERATED)
BREAKER QTY & TYPE:
SINGLE-PHASE
INPUT PHASE:
RATED POWER:
INPUT PLUG:
INPUT POWER CORD: SEE IDENTIFICATION TABLE

FEATURES

+-1% TO ISO/ IEC 62052-21

METERING ATTRIBUTES

VOLTAGE(V), CURRENT(A), APPARENT
METERING
POWER(kVA), REAL POWER(kW),
ACCURACY
POWER FACTOR, ENERGY(kWh)
INPUT(PHASE), CIRCUIT BREAKERS

METERED COMPONENTS

REMOTE OUTLET SWITCHING

ENVIRONMENTAL CONDITIONS

-5 TO 60 C (23 TO 140 F)

OPERATING TEMPERATURE

STORAGE TEMPERATURE

-20 TO 60 C (-4 TO 140 F)
HUMIDITY
5-90% RH / 5-95% RH;
(OPERATING/STORAGE)
NON-CONDENSING
MAX OPERATING
ELEVATION, ABOVE MSL
COMPLIANCE
RoHS COMPLIANT
SAFETY&ENVIRONMENTAL
SIDE VIEW
[LIGHT GRAY]
FRONT VIEW

IDENTIFICATION TABLE

MODEL IS SHOWN IN DEFAULT CONFIGURATION. FOR
OPTIONAL CONFIGURATIONS, USE ITEM IDENTIFIER
CODE IN PLACE OF EACH ASTERISK. ORDERABLE
(12)5-20R
BASED ON FORMAT: RP2310* * * *
100-120VAC
DO NOT INCLUDE TRAILING ZEROS IN * * * * SUFFIX
OPTIONS LISTED ON THIS ROW ARE NON STANDARD,
N/A
CONTACT SALES FOR ADDITIONAL INFORMATION
1.9kVA

NOTES

:
1. INSTALLATION SHALL COMPLY WITH ALL APPLICABLE
SEE NOTE 7
AND LOCAL CODES.
2. PRIMARY DIMENSIONS ARE IN MILLIMETERS. SECONDARY DIMENSIONS
ARE IN [INCHES]
3. UNIVERSAL MOUNTING BRACKET IS AN ALTERNATIVE MOUNTING
METHOD TO THE TOOLLESS MOUNT FOR 3RD PARTY ENCLOSURES.
BRACKET IS PROVIDED WITH THE UNIT.
4. DETAILED INSTALLATION INSTRUCTIONS CAN BE FOUND IN THE QUICK
START GUIDE
5.
CONNECT EXTERNAL EARTH GROUND TO THE 10-32 SIZE THREADED NUT
6.
SEE PRODUCT DOCUMENTATION FOR FURTHER INFORMATION
7.
INPUT PLUG CONFIGURATION (SEE IDENTIFICATION TABLE) FOR DUAL-
YES
RATED UNITS, NEMA PLUGS ARE NAM RATED ONLY AND CAPTIVE AUS/NZ
PLUGS ARE EMEA RATED ONLY
3000M(9840FT)
THIS DRAWING AND SPECIFICATIONS HEREIN ARE THE PROPERTY OF CIS
GLOBAL AND SHALL NOT BE COPIED, REPRODUCED OR USED IN WHOLE OR IN
PART, AS THE BASIS FOR THE MANUFACTURE OR SALE OF ITEMS WITHOUT
WRITTEN PERMISSION FROM CIS GLOBAL. THIS DRAWING IS BASED UPON
LATEST AVAILABLE INFORMATION AND IS SUBJECT TO CHANGE WITHOUT NOTICE
[LIGHT GRAY]
*
RP 2310
INPUT PLUG
(DEFAULT) L5-20P=0
NATIONAL, STATE
ECN/ECO
TITLE:
PROJECT:
RackPower
INPUT CORD
LENGTH SEE
IDENTIFICATION
TABLE
BOTTOM VIEW
* *
CORD OPTION
CHASSIS COLOR
(DEFAULT) 3m [10'] = 0
(DEFAULT) BLACK = 0 BLUE = B
1m [3.2'] = 1
RED = R WHITE = W
2m [6.6'] = 2
GREEN = G YELLOW = Y
1.2m [4'] = G
0.5m [1.6'] = A
ORANGE = A
1.5m [4.9'] = B 1.8m [6'] = F
2.5m [8.2'] = C
E1 INITIAL DRAFT REVIEW
REV. DESCRIPTION
REVISIONS
UNLESS NOTED, DIMENSIONS ARE IN
MILLIMETERS & TOLERANCES ARE:
Advantage Series
X. 1 MM
X.X 0.5 MM
Metered Switched
X.XX 0.20 MM
X.X 0.3 MM
X.XX 0.10 MM
BRACKETED DIMENSIONS ARE IN
INCHES FOR REFERENCE ONLY
THRID ANGLE PROJECTION
INTERPRET PER ASME Y14.5M-1994
*
ORIEN TATION
(DEFAULT) TOP FRONT FEED = 0
BOTTOM FEED = 2
2022/05/13 LRF
DATE APPROVED
PART NO: REV.
E1
RP2310****_DA
X 1
DRAWN BY: LRF 2022/05/13
X.X 0.5
ENGINEER:
APPROVED BY:
SIZE:
SCALE:N/A
SHEET
A3
1 OF 3
