User Manual
Rescue System
ALFAcross*100
EP 218.2018
LTF / EN 100 kg
The contents of this manual were written with due diligence and by Fluggeräte G.m.b.H best knowledge. The
Fluggeräte G.m.b.H reserves the right to change or delete contents of this manual. Al content of this manual,
text and photos are subjekt to copyright laws.
Text by Josef Gasteiger, Layout /Graphik by Frank Gasteiger and Tobias Albert
Version : Mai 2018 office@gleitschirm-retter.at *** www.gleitschirm-retter.at
Advertisement
Table of Contents
Related Manuals for Fluggeräte ALFAcross 100
Summary of Contents for Fluggeräte ALFAcross 100
- Page 1 User Manual Rescue System ALFAcross*100 EP 218.2018 LTF / EN 100 kg The contents of this manual were written with due diligence and by Fluggeräte G.m.b.H best knowledge. The Fluggeräte G.m.b.H reserves the right to change or delete contents of this manual. Al content of this manual, text and photos are subjekt to copyright laws.
-
Page 2: Table Of Contents
Table of Contents Table of Contents ..............1 Foreword ................2 Get to know your ALFAcross*100 ......... 2 What to do when it happens? ..........4 Technical Data / Material List ..........5 Packing Instructions .............. 6 Remove the line from the fixing loops! ........8 Connection the ALFAcross*100 with the harness .... -
Page 3: Foreword
Foreword Congratulations on buying your ALFAcross*100 rescue system Before you get to know your system please read the manual which includes important information. This manual gives you information on the entire specific and general characteristics of the rescue ALFAcross*100. All technical data and instructions in this manual were drawn up with great care. FLUGGERÄTE GmbH cannot be made responsible for any possible errors in this manual. - Page 4 Get to know your ALFAcross*100 Technical data Area (m²) 32,20 Number of cells Weight including container 0,985kg Weight without container ) 0,939kg Maximum Volume packed (cm³) 3500 Maximum load weight (kg) 100kg Middle line Sinkrate with max. weight (m/sec) 5,20m/sec TEST AND HOMOLOGATE : EP 218 2018 LTF/EN AIR TOURQUOISE SA CH-1844 VILLENUEVE The ALFAcross*100 is a manually deployable rescue system it is for suitable paragliding...
-
Page 5: What To Do When It Happens
What to do when it happens? If you find yourself in an uncontrollable situation in the air, pull hard on the deployment handle. This will open the outer reserve container and release the reserve parachute. Then throw the reserve package forcefully away from you. As the suspension lines become tight, the container will fall away and the reserve will open. -
Page 6: Technical Data / Material List
Technical Data / Material List MATERIAL LIST: FABRIC UTT USKY212 LINE LIROS DC-PRO 505-225 CENTER LINE AURA R 400 AURA R 270 MAIN RAISER LIROS 1505-500-205 WEBBING GÜTH & WOLF 12,50mm + 9,50mm PRODUCING: CONDOR SA BUKAREST ROMANIA Page 5... -
Page 7: Packing Instructions
Packing Instructions Packing preparations Before you pack the rescue system it is important that the canopy is spread out on the ground for about six hours. If possible, it would be even better to air it one night long by hanging it up by the top lines. Before the rescue system gets packed, a release control must be carried out. - Page 8 Sorting the panels Take the lines in your hand as shown on the photo and fold over each panel from the left side on to right side like turning the pages in a book and pull the top of the opening outward. Start with panel 1, the last one is panel 20.
-
Page 9: Remove The Line From The Fixing Loops
Remove the line from the fixing loops! Folding the canopy into thirds The left third is folded onto the middle and then the right third is folded under the middle. Do the same on top of the canopy. Fold the protruded triangles and pay attention to the size of the container! S-folding canopy to fit into inner container Fold the canopy in “S”... - Page 10 Now is the last time to remove the helping line from the fixing loops! Now put the canopy into the inner container. Close both sides of the inner container with the white rubber band and pull the suspension lines through the rubber band for closing. Fold the suspension lines using two fingers in “S”...
-
Page 11: Connection The Alfacross*100 With The Harness
With the rest of the suspension lines you finalize the closing of the inner container by pulling the suspension lines through the black rubber loop. Now the packing is finished. Make a note of the date of packing in the pack control booklet. Installing your rescue handle Most harnesses have a handle for the harness containers. -
Page 12: Parts And Items
Parts and items The elastic bands (gummi) you can get them free from the Fluggeräte G.m.b.H Compatibility- check A control of every new combination of rescue system and harness/outer container has to be carried out by either the producer of the harness or the rescue system or an authorized person (dealer or flight instructor). -
Page 13: Use Limitations, Packing- And Check Intervals
Repairs The seal of approval can only be preserved if original parts are used. If you discover any damaged parts to the rescue system which might impede deployment, please end it back to the manufacturer to get repaired. Repairs can only be carried out by the manufacturer or from the manufacturer authorized persons. -
Page 14: Verification Of Checks And Repairs
Verification of Checks and Repairs ALFAcross*100 Serial number: ……………………….…………… …………………………. Name/ Stamp First check Fluggeräte GmbH date: ….………………… Check (C) Which repair/ Check? Performed by/ date Repair (R) Check valid until? Check (C) Which repair/ Check? Performed by/ date Repair (R) Check valid until? Check (C) Which repair/ Check? -
Page 15: Description Of The Rescue System
Description of the rescue system Middle lines Suspension lines basic Main belt Top (pulled down apex) Page 14... -
Page 16: Maintaince And Pack-Interval Overview
Maintaince and Pack-Interval Overview DATE WORK USED OPEN RESULTS Signation by It is compelling advised to check and repack the rescue ALFAcross*100 every 6 months. In the case of ignoring this, there might be problems with opening time of the rescue. Name and address of the manufacturer Fluggeräte G.m.b.H.
