DT Research 524T Basic Operation Manual

I/O Ports

The Medical-Grade Integrated LCD System has a comprehensive set of I/O ports. The following
ports are located along the bottom side of the unit.
Front
Bo�om
A B C D E F
A F
Power button USB 3.0 ports
B Programmable buttons G Ethernet ports (RJ45)
C Speakers H Audio jack
DC-in USB 2.0 ports
D I
HDMI output COM ports
E J
Potential equalization conductor
K
(optional)
As an ENERGY STAR® Partner, DT Research Inc. follows the EPA's product qualification and certification process to
ensure the products marked with the ENERGY STAR® logo are ENERGY STAR® qualified for energy efficiency.
The ENERGY STAR® program specifications for computers were to promote energy efficiency and reduce air
pollution through more energy-efficient equipment in homes, offices, and factories. One way products achieve
this goal is by using the Microsoft Windows power management feature to reduce power consumption when the
product is not in use. The power management feature enables the computer to initiate a low-power or "sleep"
mode after a period of user inactivity.
To take advantage of these potential energy savings, users should use the default power management settings
that are provided with ENERGY STAR qualified computers. The default power management settings on ENERGY
STAR® qualified computers are preset to behave in the following ways :
• Turn off display after 10 minutes of user inactivity.
• Initiate a low power sleep mode for the computer after 30 minutes of user inactivity.
• Briefly press the power button will bring the computer out of sleep mode.
Additional information on the ENERGY STAR® program, its environmental benefits and the potential energy and
financial savings of the power management feature can be found on the EPA ENERGY STAR® Power Management
Web site at http://www.energystar.gov/powermanagement.
DT Research, Inc.
2000 Concourse Drive, San Jose, CA 95131
Copyright © 2022, DT Research, Inc. All Rights Reserved.
signage dtri com
Back
K
G H I J C
BOG092722 524T/ 524K ENG
Medical-Grade Integrated LCD System
524T/524K

INTRODUCTION

Thank you for acquiring DT Research's Medical-Grade Integrated LCD System. With a 24-inch TFT
display and powered by the Intel® Core™ i processor, the Medical-Grade Integrated LCD System
offers optimal combinations of performance and power savings. With fully-integrated point-of-
care modules within an elegant, space-saving design, the Medical-Grade Integrated LCD System
is the optimum solution to enhance workflow and service.
Please take a few moments to review the contents of this document to ensure that the setup
and startup proceed smoothly. The Medical-Grade Integrated LCD System is ready for use, out of
the box, in its default configuration when powered by the power source provided. The following
documentation offers guidance on the hardware elements and features of the computer. Please
refer to your device provider for information pertaining to the software operating system or
software applications.

PACKAGE CONTENTS

• 524T/524K
• AC-DC power adapter with power cord
• Basic operation guide
MEDICAL – GENERAL MEDICAL EQUIPMENT
AS TO ELECTRICAL SHOCK, FIRE AND MECHANICAL
HAZARDS ONLY IN ACCORDANCE WITH ANSI/AAMI
ES60601-1 (2005) + AMD (2012) & "CAN/CSA-C22.2
No. 6060-1 (2008) + (2014)
