Summary of Contents for Winston MNHO-073

  • Page 1 Intel® E3845 4 LAN 1 COM AES-NI 4G Fanless Firewall Router MNHO-073 MNHO-073 User Manual © Copyright Winston Marriot Ltd. All Rights Reserved. www.pondesk.com...
  • Page 2 Intel® E3845 4 LAN 1 COM AES-NI 4G Fanless Firewall Router MNHO-073 Intel® E3845 4 LAN 1 COM AES-NI 4G Fanless Firewall Router © Copyright Winston Marriot Ltd. All Rights Reserved. © Copyright Winston Marriot Ltd. All Rights Reserved. www.pondesk.com...
  • Page 3 Winston Marriot Ltd takes no liability and responsibility for any in error that may appear in this manual. Winston Marriot Ltd will not be responsible and liable for the errors that may contained in this manual and for incidental or consequential damages (including lost profits) in connection with the furnishing, performance or use of this material.

  • Page 4: Table Of Contents

    4.2.2.1 – ACPI Settings ..........© Copyright Winston Marriot Ltd. All Rights Reserved.
  • Page 5 ............51 © Copyright Winston Marriot Ltd. All Rights Reserved.

  • Page 6: Introduction

    Intel® E3845 4 LAN 1 COM AES-NI 4G Fanless Firewall Router MNHO-073 Chapter Introduction © Copyright Winston Marriot Ltd. All Rights Reserved. www.pondesk.com...
  • Page 7 Completely fanless aluminium alloy compact size durable dustproof structure provides universal performance for small and medium sized business networks, offices, Internet service providers, MSP/MSSP etc. For details: https://www.pondesk.com/product/MNHO-073 © Copyright Winston Marriot Ltd. All Rights Reserved. www.pondesk.com...

  • Page 8: Specifications

    4 x Intel® I211-AT Gigabit LAN Structure: Aluminum Alloy Dustproof 1 x HDMI Size: 126mm x 134mm x 40.6mm (L*W*H) 1 x RJ45 COM Weight: approx. 0.5 KG 1 x USB 3.0 © Copyright Winston Marriot Ltd. All Rights Reserved. www.pondesk.com...

  • Page 9: Front & Back Side View

    Intel® E3845 4 LAN 1 COM AES-NI 4G Fanless Firewall Router MNHO-073 FRONT & BACK SIDE VIEW PACKAGE 1 x Firewall Router 1 x Power Adapter 1 x Power Cord 2 x WiFi Antenna (optional with WiFi) © Copyright Winston Marriot Ltd. All Rights Reserved. www.pondesk.com...
  • Page 10 Intel® E3845 4 LAN 1 COM AES-NI 4G Fanless Firewall Router MNHO-073 Chapter Structure © Copyright Winston Marriot Ltd. All Rights Reserved. www.pondesk.com...

  • Page 11: Interfaces

    1 x HDD & Power Indicator 1 x USB3.0 & 1 x USB2.0 1 x 12V Power Connector 1 x HDMI 1 x I/O Switch 1 x RJ45 COM 1 x Restart Switch © Copyright Winston Marriot Ltd. All Rights Reserved. www.pondesk.com...
  • Page 12 Intel® E3845 4 LAN 1 COM AES-NI 4G Fanless Firewall Router MNHO-073 © Copyright Winston Marriot Ltd. All Rights Reserved. www.pondesk.com...

  • Page 13: Opening The Case

    There are 4 screws (two screws on each sides) for holding the case cover. Remove the case. By unscrewing these screws, to add or remove SSD, memory etc. Don’t over-tighten the screws, it causes damage the screw holes. © Copyright Winston Marriot Ltd. All Rights Reserved. www.pondesk.com...

  • Page 14: Motherboard

    Intel® E3845 4 LAN 1 COM AES-NI 4G Fanless Firewall Router MNHO-073 Chapter Motherboard © Copyright Winston Marriot Ltd. All Rights Reserved. www.pondesk.com...
  • Page 15 03. HDMI 10. Power Input 12V 04. USB 2.0 & 3.0 11. LED Indicator 05. Power Switch 12. RJ45 NICs 06. SODIMM Memory Slot 13. SATAII (2.5” SSD/HDD) 07. 3G/4G SIM Socket © Copyright Winston Marriot Ltd. All Rights Reserved. www.pondesk.com...

  • Page 16: Layout

    Intel® E3845 4 LAN 1 COM AES-NI 4G Fanless Firewall Router MNHO-073 LAYOUT © Copyright Winston Marriot Ltd. All Rights Reserved. www.pondesk.com...

  • Page 17: Processor

    Step 2: Align the notch and insert the memory module into the socket at a slight 30-40° angle relative to the memory slot. Step 3: Push down the memory until it slips down and properly seated into the socket. © Copyright Winston Marriot Ltd. All Rights Reserved. www.pondesk.com...

  • Page 18: Storage

    Locate mSATA socket (refer to the image on page 14) on the motherboard and align the notches of the SSD with mSATA socket and insert it. After that screw it according to the below illustrations. © Copyright Winston Marriot Ltd. All Rights Reserved. www.pondesk.com...

  • Page 19: 2.5" Sata Ssd/Hdd

    (please refer to page # 12 & 13) First attach SSD/HDD with the case cover by the 4 screws and then connect the SATA data & power cable with the machine. As shown in below image. © Copyright Winston Marriot Ltd. All Rights Reserved. www.pondesk.com...

  • Page 20: Wi-Fi & 3G/4G

    Please follow below the useful links to find the list of 3G (UMTS) and 4G (LTE) networks around the world, grouped by their frequency bands. Helps to find the right module as per your country/Territory. 3G (UMTS): https://en.wikipedia.org/wiki/List_of_UMTS_networks 4G (LTE): https://en.wikipedia.org/wiki/List_of_LTE_networks © Copyright Winston Marriot Ltd. All Rights Reserved. www.pondesk.com...

  • Page 21: Interfaces

    The system equipped with 4x Intel® I211AT gigabit Ethernet controller. 3.6.4 SYSTEM FAN 3-pin connectors (SYS_FAN) to connect the system fan. (the system is fanless) PINS SIGNAL TMDS Data2+ TMDS Data2- TMDS Data1 Shield © Copyright Winston Marriot Ltd. All Rights Reserved. www.pondesk.com...

  • Page 22: Sata2

    Hard disk LED (+ and – signals) 2, 4 Main power indicator (+ and -) 5, 7 Motherboard reset (+ and -) 6, 8 Motherboard ON/OFF (+ and -) 9, 10 Buzzer connector © Copyright Winston Marriot Ltd. All Rights Reserved. www.pondesk.com...

  • Page 23: Bios

    Intel® E3845 4 LAN 1 COM AES-NI 4G Fanless Firewall Router MNHO-073 Chapter BIOS © Copyright Winston Marriot Ltd. All Rights Reserved. www.pondesk.com...

  • Page 24: Functions & Interface

    <F4> Save & Exit. SETTINGS Main Menu General information Advanced Main Configurations Chipset Chipset Configurations Boot Boot Configurations & Settings Security Passwords Settings Save & Exit Default, Discard & Save Settings © Copyright Winston Marriot Ltd. All Rights Reserved. www.pondesk.com...

  • Page 25: Main Menu

    The main menu contains the BIOS information, OS selection, system date & time setup and user access level selection. Use arrow keys to select the items and press <Enter> to accept or enter Sub-menu. © Copyright Winston Marriot Ltd. All Rights Reserved. www.pondesk.com...

  • Page 26: Advanced Menu

    Advanced menu specifies the detailed system functions. The following options are available. ACPI Settings System Power Management CPU Configuration PPM Configuration SATA Configuration LPSS & SCC Configuration CSM Configuration USB Configuration © Copyright Winston Marriot Ltd. All Rights Reserved. www.pondesk.com...

  • Page 27: Acpi Settings

    ACPI (advanced configuration and power interface) settings gives the BIOS and operating system control over various devices power and modes of operation. The available settings are, Enable ACPI Auto Configuration Enable Hibernation ACPI Sleep State Lock Legency Resources © Copyright Winston Marriot Ltd. All Rights Reserved. www.pondesk.com...

  • Page 28: System Power Management

    [Power off] leaves the system off until pressing the power button. [Last State] reboots the system automatically if it was active before power loss. [Follow AC Power] will start up anytime power is available. © Copyright Winston Marriot Ltd. All Rights Reserved. www.pondesk.com...

  • Page 29: Cpu Configuration

    Options are [Enabled] and [Disabled] Intel Virtualization Technology: Allow system to run multiple operating systems and applications in independent partitions. Options are [Disabled] and [Enabled] © Copyright Winston Marriot Ltd. All Rights Reserved. www.pondesk.com...

  • Page 30: Ppm Configuration

    C1: Stops CPU main internal clocks via software; bus interface unit and APIC are kept running at full speed. S0ix: Shut off part of the SoC when they are not in use. The options are [Disabled] and [Enabled]. © Copyright Winston Marriot Ltd. All Rights Reserved. www.pondesk.com...

  • Page 31: Sata Configuration

    SATA Port (0, 1) HotPlug: Allows you to add and remove SATA drive to a computer system while the computer is running and have the operating system automatically recognize the change. © Copyright Winston Marriot Ltd. All Rights Reserved. www.pondesk.com...

  • Page 32: Lpss & Scc Configuration

    Intel® E3845 4 LAN 1 COM AES-NI 4G Fanless Firewall Router MNHO-073 4.2.2.6 LPSS & SCC CONFIGURATION LPSS & SCC Devices Mode: To configure the various Low-speed pin connections. SCC Configuration LPSS Configuration © Copyright Winston Marriot Ltd. All Rights Reserved. www.pondesk.com...

  • Page 33: Csm Configuration

    GUID Partition Table (GPT). The firmware itself scans the GPTs to find an EFI Service Partition to boot from. If no EFI bootable partition is found, the firmware can fall back on the Legacy Boot method. © Copyright Winston Marriot Ltd. All Rights Reserved. www.pondesk.com...

  • Page 34: Usb Configuration

    USB drive. Disable option will keep USB devices available only for EFI applications. The options are [Enabled] and [Disabled]. USB Mass Storage Driver Support: This feature enables to support the USB mass storage devices. The options are [Enabled] and [Disabled]. © Copyright Winston Marriot Ltd. All Rights Reserved. www.pondesk.com...

  • Page 35: Chipset

    The Chipset section provide the settings of North Bridge for internal graphics parameters, memory information, LCD control and power management settings; and South Bridge for USB configuration and PCI Express configuration etc. © Copyright Winston Marriot Ltd. All Rights Reserved. www.pondesk.com...

  • Page 36: North Bridge

    The options are [Enabled] and [Disabled]. LCD Control: Having settings of Primary IGFX Boot Display that allow users to select the video device which will be activated during post. © Copyright Winston Marriot Ltd. All Rights Reserved. www.pondesk.com...

  • Page 37: South Bridge

    USB Configuration: USB (Universal Serial Bus) configuration and settings. PCI Express Configuration: PCI express settings and config. High Precision Timer [Enabled] Serial IRQ Mode [Quiet] Global SMI Lock [Enabled] BIOS Read/Write Protection [Disabled] © Copyright Winston Marriot Ltd. All Rights Reserved. www.pondesk.com...

  • Page 38: Security

    Secure Boot Mode: This is the secure mode selector. The 'Custom' mode enables user to change the Image Execution policy and mange Secure Boot Keys Configuration. options are [Standard] and [Custom] © Copyright Winston Marriot Ltd. All Rights Reserved. www.pondesk.com...

  • Page 39: Boot

    Boot Option Priorities: This option provides the boot priority configuration to specify which one is boot device and the order of device priority which the systems boots during startup. Option # 1 is the highest priority boot device. © Copyright Winston Marriot Ltd. All Rights Reserved. www.pondesk.com...

  • Page 40: Save & Exit

    Boot Override: This feature allows the temporary booting from a connected device without having to reassert your quick boot order for future boots. The bootable devices will be displayed below of this option. © Copyright Winston Marriot Ltd. All Rights Reserved. www.pondesk.com...

  • Page 41: Warranty & Rma

    Intel® E3845 4 LAN 1 COM AES-NI 4G Fanless Firewall Router MNHO-073 Chapter Warranty & RMA © Copyright Winston Marriot Ltd. All Rights Reserved. www.pondesk.com...

  • Page 42: Terms And Conditions

    RMA process. 12. Please keep the original package for shipping back in case of return. Please note: Winston Marriot Ltd reserves the right to change the terms and conditions without prior notice. Please check back regularly for updates...

  • Page 43: Product Registration

    RMA by just providing your product serial number and purchase information. https://www.pondesk.com/support/productregistration Contact If you would like to contact to our Customer Support team directly, please contact them at, support@pondesk.com Monday – Friday 9:00AM - 5:00PM (GMT+1) © Copyright Winston Marriot Ltd. All Rights Reserved. www.pondesk.com...
  • Page 44 Intel® E3845 4 LAN 1 COM AES-NI 4G Fanless Firewall Router MNHO-073 Appendix Glossary © Copyright Winston Marriot Ltd. All Rights Reserved. www.pondesk.com...
  • Page 45 Dynamic random access memory is a common type of general-purpose computer memory that stores each bit of data in a separate capacitor. DIMM Dual in-line memory modules. Is a small circuit board with memory chipset. © Copyright Winston Marriot Ltd. All Rights Reserved. www.pondesk.com...
  • Page 46 PS/2 A keyboard & mouse connective 6-pin mini-DIN connector interface. FIREWALL Firewall is monitoring and controlling system of network security. It controls the incoming and outgoing network traffic. © Copyright Winston Marriot Ltd. All Rights Reserved. www.pondesk.com...
  • Page 47 Intel® E3845 4 LAN 1 COM AES-NI 4G Fanless Firewall Router MNHO-073 Appendix Troubleshooting © Copyright Winston Marriot Ltd. All Rights Reserved. www.pondesk.com...
  • Page 48 4. Reconnect the storage drive and refresh CMOS by re-inserting the CMOS battery. 1. Use third-party software to check the hard disk for bad sectors. Running slow? 2. Low Disk Space. © Copyright Winston Marriot Ltd. All Rights Reserved. www.pondesk.com...
  • Page 49 2. Confirm that the USB is working fine. Can't detect USB? 3. Make sure the USB controller in the BIOS Setup is on. You can also reset the BIOS settings. 4. Virus infected USB also cause the issue. © Copyright Winston Marriot Ltd. All Rights Reserved. www.pondesk.com...
  • Page 50 Intel® E3845 4 LAN 1 COM AES-NI 4G Fanless Firewall Router MNHO-073 Appendix Abbreviations © Copyright Winston Marriot Ltd. All Rights Reserved. www.pondesk.com...
  • Page 51 Rapid Deployment Pack Wide Area Network Error checking & correcting RBSU ROM-Based Setup Utility Wireless Access Point File Transfer Protocol WLAN HTTP Routing Information Wireless Local Area Hypertext Transfer Protocol Protocol Network © Copyright Winston Marriot Ltd. All Rights Reserved. www.pondesk.com...
  • Page 52 Intel® E3845 4 LAN 1 COM AES-NI 4G Fanless Firewall Router MNHO-073 Barking, Essex IG118BB, United Kingdom info@winstonmarriot.co.uk www.winstonmarriot.co.uk © Copyright Winston Marriot Ltd. All Rights Reserved. www.pondesk.com...
