INSTALLATION AND MAINTENANCE INSTRUCTIONS
PIBV2A Post Indicator and
Butterfly Valve Supervisory Switch
Specifications
Contact Ratings:
Cover Tamper Switch Ratings:
Dimensions:
Maximum Stem Extension:
Operating Temperature Range:
Shipping Weight
Enclosure Rating:
Important
Please Read Carefully and Save
This instruction manual contains important information on the
installation and operation of supervisory switches. Purchasers
who install supervisory switches for use by others must leave
this manual or a copy of it with the user. These instructions
apply to Safe Signal switches for post indicator and butterfly
type valves. Read all instructions carefully before beginning
installation.
Do NOT use this switch in explosive or potentially explosive
atmospheres. Do NOT leave unused wires exposed.
All supervisory switch installations must comply with local
codes and ordinances and the requirements of the author-
ity having jurisdiction. Additional information is avail-
able in National Fire Protection Association standards NFPA
13, 13D, 13R, 71, and 72. The connection of supervisory
switches to alarm control units is governed by CAN/ULC-
S524-M91, standard for the Installation of Fire Alarm Systems.
General Installation Considerations
1. Model PIBV2A is designed for installation in a
tapped hole and located so that the actuating lever of the
switch engages the target or flag of the valve . The switch
actuating lever is spring loaded against the flag or target of the
valve and is released when the valve moves toward the closed
position from the fully open position. The switch is factory set
to indicate an alarm condition when the target and lever move
in the direction toward the conduit entry hole when the valve
closes, but can be reversed if the installation demands (refer
to Section 4).
10A @ 125/250 VAC
2.5 A @ 24 VDC
5 A @ 125/250 VAC; 2.5 A @ 24 VDC
8
1
⁄
˝ H X 3
1
⁄
˝ W X 3
4
2
3
5
⁄
˝
3 2
0°C - 49°C (32°F - 120°F)
2 lbs.
NEMA Type 3R when mounted with the actuator vertical (cover on top) as tested by
Underwriters Laboratories, Inc. (PIBV2A is ULC approved)
CAUTION
1
1
⁄
˝ D
4
Figure 1:
COVER
TAMPER
SCREWS
TAMPER
PROOF
WRENCH
(P/N WFDW)
ACTUATING
CAM
ACTUATING
LEVER SCREW
NIPPLE SET SCREW
THREADED
3
/
˝ D
1
NIPPLE
4
⁄
˝ NPT
2
2. Model PIBV2A is equipped with a removable
nipple which is locked in place with two set screws. A hex
wrench is provided for this feature. The PIBV2 also includes
an adjustable length actuating lever.
3. The cover is secured with two tamper resistant screws which
require a special key to remove. One key is included with
each supervisory switch. Replacement and additional keys are
available (Part No. WFDW).
1
SPRING
MOUNTING SCREWS
SWITCH ENCLOSURE
ACTUATING
LEVER
HEX
RETAINING NUT
WRENCH
(P/N HEXW)
4
1
/
˝ H
4
(ASSEMBLED)
BASE HOUSING
3
/
˝ W
1
2
W0224-00
1
⁄
˝ NPT pipe
2
I56-2481-C
4/21
Advertisement
Summary of Contents for Safe Signal PIBV2A
- Page 1 TAMPER SCREWS this manual or a copy of it with the user. These instructions ˝ H apply to Safe Signal switches for post indicator and butterfly (ASSEMBLED) type valves. Read all instructions carefully before beginning TAMPER SPRING installation.
- Page 2 ⁄ ˝ NPT plug from the gear housing. upper surface of the target that will contact the actuating 2. Loosen 2 set screws that hold the nipple on the PIBV2A and lever of the PIBV2A. Add ⁄ ˝ to this measurement and remove the nipple.
- Page 3 If there is no travel, damage may occur to enclosure remains oriented away from the conduit entry as PIBV2A actuating arm. Some slight alteration of the valve screws are tightened.) stop setting may be necessary to ensure that no damage 3.
- Page 4 SAFE SIGNAL for inspection. Upon a determination by SAFE SIGNAL defective manufacture, labeling, or packaging. that a product is not as warranted, SAFE SIGNAL shall, at its exclusive option, replace or repair said defective product or parts thereof at its own expense except that Purchaser shall pay all...
