NIJEL v1.1
by neutral labs
Manual
Hello, owner.
Nijel is a distortion module that lets you change its sonic character
by
plugging
in
components
like
diodes,
capacitors
or
resistors
directly to the front panel. You can also use separately available
preset cards that are compatible with other Neutral Labs products.
Advertisement
Table of Contents
Related Manuals for neutral labs NIJEL
Summary of Contents for neutral labs NIJEL
- Page 1 NIJEL v1.1 by neutral labs Manual Hello, owner. Nijel is a distortion module that lets you change its sonic character plugging components like diodes, capacitors resistors directly to the front panel. You can also use separately available preset cards that are compatible with other Neutral Labs products.
- Page 2 Module Function NIJEL is a diode distortion module that has drive control via a knob and/or incoming control voltage (CV). The user can optionally modify the distortion character by plugging...
- Page 3 Controls Control Function DRIVE This knob adjusts the intensity of the distortion. When fully counterclockwise, there minimal amount distortion applied incoming audio. When fully clockwise, the applied distortion is at its maximum. More is not always better: Sweet spots are often found around the midpoint or slightly above, depending on the source material.
- Page 4 Modifier Ports The ports at the top of the module labeled P|S|G|S|P support the plugging in of pre-assembled cards available from Neutral Labs, as well as individual passive components like resistors, capacitors or diodes. LEDs and LDRs (light-dependent resistors) can be used as well, even in combination.
- Page 5 Serial (S) This is used for putting two components in series, the combination of which will then be in parallel to the feedback circuit. Put the first of the two components from P to S and the other one from the other S to the other P. Both of the S ports on either row are interconnected, so a series connection will be made between the components.
