XTCERA X-MILL 500 User Manual

Five-axis dental milling machine
Hide thumbs

Advertisement

Table of Contents

X-MILL 500
X-MILL 500 Five-Axis Dental Milling machine
Shenzhen XTcera Medical Technology Co.,Ltd
Address: 4th Floor,1st Building,2nd Area,Honghualing Industrial
Park,Nanshan District, 518055, Shenzhen,China
Tel: 0086 755 8600 1804
Fax: 0086 755 8600 1486
E-mail: xtcera@xianton.com
Web: en.xtcera.com
500
User Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the X-MILL 500 and is the answer not in the manual?

Questions and answers

Summary of Contents for XTCERA X-MILL 500

  • Page 1 X-MILL 500 X-MILL 500 Five-Axis Dental Milling machine User Manual Shenzhen XTcera Medical Technology Co.,Ltd Address: 4th Floor,1st Building,2nd Area,Honghualing Industrial Park,Nanshan District, 518055, Shenzhen,China Tel: 0086 755 8600 1804 Fax: 0086 755 8600 1486 E-mail: xtcera@xianton.com Web: en.xtcera.com...

  • Page 2: Table Of Contents

    2-2 Equipment Commissioning misuse. Chapter 3: Pilot Run and Processing X-mill 500 five-axis dental milling machine is made of high-quality components, 3-1 Pilot Run materials, and specially developed motion control technology. The machine adopts 3-2 Processing Run...

  • Page 3: Chapter 1: Introduction To X-Mill 500 Five-Axis Dental Milling Machine

    MILLING MACHINE 1-1 PRODUCT INTRODUCTION 1-2 SHAPE STRUCTURE X-mill 500 is the five-axis dental milling machine developed by Shenzhen Xiang- tong Medical Technology Co., Ltd. It adopts the horizontal integrated design. Key machinery and control components are high-quality imported components. The...

  • Page 4: Technical Parameters

    1-3 TECHNICAL PARAMETERS 1-4 Use Environment and Requirements External dimension: 720x850x860 mm 1.Power supply should be grounding in accordance with the third method described in Weight: 225 kg the Electrical Engineering Rules, to prevent damage to the human body caused by elec- Power supply voltage: Single phase AC 220V 50 Hz tricity leakage.

  • Page 5: Equipment Commissioning

    2. Count the accessories according to the packing list. 3. Install the equipment body on the horizontal and firm workbench, and remove the transportation fasteners. 4. Connect the power cable, air supply system, cooling water system and vacuum system according to the instructions. 5.

  • Page 6: Chapter 3 Pilot Run And Processing

    If the NO is 1, then click “T2” on the manual interface and machine will put T1 bur into the tool station. After, you can put T2 bur into spindle. Then check tool NO. on the screen and click “T3”. Machine will put T2 bur into tool station and you can put T3 bur into the collet manually.
  • Page 7 2. Click “load” button and select the test processing file for pilot run. Load the file 5. Click “START” button again to start the auto processing. If you click “pause” button after confirmation. The relevant information of the processing file will be displayed after during the processing, the milling process will stop at the current point, the system will successful loading, such as the file name, material type, processing grade.
  • Page 8 5. If power outage occurs during the processing, start the software after the system is powered on again. The system will automatically load the processing file loaded before the power outage and recover the saved information of the interrupted line. You can click “START”...

  • Page 9: Troubleshooting

    4. When tightening the clamp, be sure to evenly tightening each screw. Do not fully tighten a screw and then tighten other screws. It will cause uneven force to break the material or cause internal stress which results in breakage during the processing. 3-5 Trouble shooting 6.

  • Page 10: Chapter 4 Maintenance And Precautions

    4-2 SPECIAL NOTES: CHAPTER 4 MAINTENANCE AND PRECAUTIONS 1. If you use our equipment to process products other than the above-mentioned mate- 4-1 INSTRUCTIONS FOR MAINTENANCE: rials, please make evaluation according to the equipment parameters. You shall be fully 1. Clean the dust in the equipment processing chamber every day, and ensure that liable for any accident caused by processing products of other materials.
  • Page 11 No force shall be applied to any part of the enclosure. Otherwise, enclosure deformation or even equipment dropping will be caused, resulting in severe accident. 8. If there is any abnormal noise or abnormal action during the use, please record the relevant exception message and contact us.
  • Page 12 APPENDIX I: OVERALL OPERATION FLOW APPENDIX II REFERENCE TABLE FOR PROCESSING CHART OF THE EQUIPMENT FILE INFORMATION Information Module name Module meaning Connect power cable Customized processing mode, where the Custom rate can be adjusted and vacuum can be manually started and shut down Wax, high-efficiency processing mode, Turn on power switch and power on the system where the rate cannot be adjusted, and...
