Portable Ventilators for
Hazardous Locations
The Portable Ventilators described herein are intended
for use in Explosive Atmospheres in accordance
responsibility to determine the suitability of equipment
TECHNICAL INFORMATION AND ORIGINAL INSTALLATION
Euramco Group | 2746 Via Orange Way, Spring Valley CA 91978 USA
II 2 G Ex db eb IIC T6 Gb
II 2 G Ex h IIB T6 Gb
0539 Demko 09 ATEX 0926969X
IECEx UL 13.0062X
with the limitations of the rating. It is the user's
for the intended purpose.
INSTRUCTIONS
Ph: +1-619-670-9590 | www.euramco.com
SM-EFATEX Rev F1 - Page 1 of 16
FlowPath
™
Control
Applicable Models:
UB20xx EFi120xx
EFi75xx EFi150xx
0539
SM-EFATEX REV F2
Advertisement
Table of Contents
Related Manuals for Euramco RAMFAN FlowPath UB20 Series
Summary of Contents for Euramco RAMFAN FlowPath UB20 Series
- Page 1 TECHNICAL INFORMATION AND ORIGINAL INSTALLATION INSTRUCTIONS Euramco Group | 2746 Via Orange Way, Spring Valley CA 91978 USA Ph: +1-619-670-9590 | www.euramco.com SM-EFATEX REV F2 SM-EFATEX Rev F1 - Page 1 of 16...
- Page 2 II 2 G Ex h IIB T6 Gb manufacturers instructions. Color code for flying lead power cables is brown “hot”, blue Euramco Safety hereby declares that the equipment listed in this manual conforms to the “neutral”, & yellow/green “ground” for plug connections.
- Page 3 Description of Apparatus Motor connections are made through a non-detachable cable, secured to the motor with The Portable Ventilator assemblies represented herein consist of an Approved Explosion an approved Flame Proof cable gland from the company Hawke, model 501/421/0/M20 Proof Electric Motor Rated: Ex d IIB as listed below. and complies with International Standards EN 60079-0, EN 60079-1, and EN 60079-7.
-
Page 4: Operation
OPERATION Always ensure the switch is in the “Down/OFF” position prior to connecting the ventilator to a power source. Completely uncoil fan power cable to the AC power source. Route fan power cable to avoid contact with heavy machinery that could possible damage cable or possible be a trip hazard for workers. -
Page 5: Warranty
CAUTIONS Do not move ventilator while fan is in operation. Use good lifting practices when moving ventilator to prevent bodily injury. Blower should be operated and repaired by trained personnel only. Do not operate if there is any physical damage to cord, plug or receptacle. Keep fingers and hands clear of fan blade. -
Page 6: Accessories List
Fan Performance Characteristic for Fans Running on 50Hz AC power FOR ATEX, IECEx AND INMETRO HAZARDOUS LOCATION FANS Euramco Group has several optional antistatic / conductive airflow duct accessories designed explicitly for use with our Hazardous Location Fans to support various end user applications as identified in the list below. - Page 7 TYPICAL VENTILATOR EXPLODED VIEW TYPICAL VENTILATOR EXPLODED VIEW UB20XX EF7002 / EF8002 EFi75XX EB7201XX / EB7201XX-230 1. E7205K – DUCT ADAPTER KIT 7. EZ-080305003CE – JUNCTION BOX 1. E7205K – DUCT ADAPTER KIT 7. EZ-14/3E – POWER CABLE • EB5006 - Alternative Duct Adapter, 12” 2.
- Page 8 TYPICAL VENTILATOR EXPLODED VIEW TYPICAL VENTILATOR EXPLODED VIEW EFi120XX EA8120XX / EA8120XX-110 EFi150XX EG8200XX/ EG8200XX-230 1. EA7116 - 16”/40 cm DUCT ASSY (INLET) 7. EZ-312-RWB - CORD STRAP 1. EA7116 - 16”/40 cm DUCT ASSY (INLET) 7. EZ-312-RWB - CORD STRAP 2.
-
Page 9: Wiring Diagram
