P r e f a c e
This manual describes how to install and use the Signamax Gigabit
Ethernet Adapter, a high-performance network interface card for 32 and
64 bit PCI buses. Delivering a fully scalable solution, this adapter fully
complies with IEEE 802.3u 10/100BaseT/TX and IEEE 802.3ab
1000BaseT standards, and auto-negotiates duplex modes as well as
speeds of 10/100/1000 Mbps. In addition, it supports auto MDIX
configuration for uplink purposes. There are more enhanced features
added to this adapter, and it certainly satisfies the demands of today's
high-end servers and workstations.
To get the most out of this manual, you should have an understanding of
Ethernet networking concepts.
In this manual, you will find:
• Introduction on this Gigabit Adapter
• Product features
• LEDs functions
• Installation instructions
• Specifications
User's Manual
檔名: SNMX-098-2000T manual- RT's revision 4-22-2001
原作者:
列印時間: 2003/1/24 下午 06:17
Signamax Gigabit Ethernet Adapter
1
Advertisement
Table of Contents
Summary of Contents for Jotec SignaMax SNMX-098-2000T
-
Page 1: Preface
Signamax Gigabit Ethernet Adapter P r e f a c e This manual describes how to install and use the Signamax Gigabit Ethernet Adapter, a high-performance network interface card for 32 and 64 bit PCI buses. Delivering a fully scalable solution, this adapter fully complies with IEEE 802.3u 10/100BaseT/TX and IEEE 802.3ab 1000BaseT standards, and auto-negotiates duplex modes as well as speeds of 10/100/1000 Mbps. -
Page 2: Table Of Contents
Signamax Gigabit Ethernet Adapter T a b l e o f C o n t e n t s ................1 REFACE ............2 ABLE OF ONTENTS ............3 RODUCT VERVIEW ........... 3 IGABIT THERNET DAPTER .............. 3 ACKAGE ONTENTS ............... 4 RODUCT EATURES Enhanced Features..................4 Driver Support....................4... -
Page 3: Product Overview
Signamax Gigabit Ethernet Adapter P r o d u c t O v e r v i e w Signamax Gigabit Ethernet Adapter Figure 1: Gigabit Adapter with RJ-45 connector, featuring two LEDs Package Contents When you unpack the product package, you shall find the items listed below. -
Page 4: Product Features
Signamax Gigabit Ethernet Adapter Product Features • Provides one RJ-45 port and supports auto MDIX. • Provides status LEDs. • Supports half-duplex or full-duplex operation for up to a 2 Gbps data transfer rate. • Supports PCI bus clock speeds up to 66MHz. •... -
Page 5: Leds
Signamax Gigabit Ethernet Adapter LED Status Indicators • ACT (Activity) This LED flashes when the port is transmitting or receiving data. ‚ LNK (Link) This LED comes on when a network connection is established successfully. LEDs Status Indication Transmitting or receiving data. Flashing ACT stands for ACTIVITY. -
Page 6: Installation
Signamax Gigabit Ethernet Adapter I n s t a l l a t i o n Installing Adapter into PCI slot Step 1: Turn off the power to the PC. Step 2: Remove any metal decorations from your hands and wrists. Step 3: Remove the cover from your PC. - Page 7 Signamax Gigabit Ethernet Adapter Insert the adapter into PCI slot and screw it onto backplate Figure 2: Installing the adapter into a suitable PCI slot Always ensure the power is turned off before any installation to avoid electric shock and possible damage to the equipment. User’s Manual 檔名: SNMX-098-2000T manual- RT's revision 4-22-2001 原作者:...
-
Page 8: Connecting To Your Network
Signamax Gigabit Ethernet Adapter Connecting to Your Network This section describes how to connect the adapter to a copper wire-based Signamax Gigabit Ethernet network, which contributes to its optimal performance. You must connect the adapter to the network before installing the network driver. -
Page 9: Loading Network Drivers
Signamax Gigabit Ethernet Adapter Loading Network Drivers The adapter supports a wide range of drivers for commonly used network operating systems. The following drivers are provided in the diskette enclosed in the product package. • NDIS drivers for Microsoft Windows 95/98, Windows NT4.0, 2000 or later •... -
Page 10: Specifications
Signamax Gigabit Ethernet Adapter S p e c i f i c a t i o n s Applicable Standards IEEE 802.3u 10/100BaseT/TX IEEE 802.3ab 1000BaseT IEEE 802.3x Flow Control IEEE 802.1p Quality of Service IEEE 802.1Q Tagged VLAN PCI Specifications Revision 2.2 Speed 20 Mbps full-duplex;... - Page 11 Signamax Gigabit Ethernet Adapter LED Indicators LNK (Link) /ACT (Activity) Dimensions 162 mm × 90 mm Net Weight 80g approx. Power Consumption 5VDC, 900mA, 5W max. Operating Temperature 0°C to 40° C (32°F to 104°F) Storage Temperature -25°C to 70°C (-13°F to 158°F) Humidity 10%-90% non-condensing Emissions...
-
Page 12: Appendix A: Contact Information
Fax:+46-(0)-293-228 89 Kircheim b. München, Germany Phone:+49-81-35-9303-0 Phone:+49-89-901-097-0 Http:\\www.aesp.se Fax:+49-89-901-097-22 E-mail: info@aesp.se E-mail: aesp.info@t-online.de JOTEC AESP AS. (NORWAY) Telefon 23 14 17 00 Ordrefax 23 14 17 10 Karihaugveien 102 Postboks 50 Ellingsrudasen 1006 Oslo, Norway Phone:+47-23-14-1700 Fax:+47-23-14-1710 Http:\\www.jotec.no E-mail: jotec@jotec.no... - Page 13 Signamax Gigabit Ethernet Adapter User’s Manual 檔名: SNMX-098-2000T manual- RT's revision 4-22-2001 原作者: 列印時間: 2003/1/24 下午 06:17...
