CONTACT US FIRST
CONTACT US FIRST
sauder.com
sauder.com
sauder.com
BEFORE MAKING ANY RETURNS TO THE STORE.
BEFORE MAKING ANY RETURNS TO THE RETAILER.
sauder.com/service
Visit
Prefer the phone? Give us a ring at
Customer Service is available Monday-Friday - 9 a.m. to 5:30 p.m. EST (except holidays)
Storage Cabinet
Model 433242
Sauder.com
Share your journey!
to order replacement parts, view video assembly tips, or chat with a live rep.
1-800-445-1527
.
Store behind
closed doors.
NOTE: THIS INSTRUCTION
BOOKLET CONTAINS IMPORTANT
SAFETY INFORMATION.
PLEASE READ AND KEEP FOR
FUTURE REFERENCE.
English pg 1-18
Français pg 19-21
Español pg 22-24
Lot # 578195
Purchased: __________________
02/18/22
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Sauder 433242
Summary of Contents for Sauder 433242
- Page 1 Customer Service is available Monday-Friday - 9 a.m. to 5:30 p.m. EST (except holidays) Store behind closed doors. Storage Cabinet NOTE: THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION. Model 433242 PLEASE READ AND KEEP FOR FUTURE REFERENCE. Sauder.com English pg 1-18 Français pg 19-21 Español pg 22-24...
- Page 2 No. 2 Phillips Screwdriver Hardware Identification Tip Shown Actual Size Hardware Usage Guide Assembly Steps 6-18 Hammer Not actual size Français 19-21 Español 22-24 Pencil Safety 25-26 Electric drill with 1/8" or 3/8" bit (ONLY in indicated step) Warranty Page 2 www.sauder.com/service 433242...
- Page 3 Use this part identification to help identify similar parts. LEFT END (1) RIGHT END (1) TOP (1) BOTTOM (1) SHELF (1) ADJUSTABLE SHELF (2) LEFT DOOR (1) RIGHT DOOR (1) BACK (1) 433242 www.sauder.com/service Page 3...
- Page 4 NAIL - 30 HINGE - 6 FURNITURE TIPPING APPLIQUE CARD - 1 BUMPER CARD - 1 RESTRAINT KIT - 1 2" FLAT HEAD SCREW - 4 5/8" MACHINE SCREW - 4 1/2" FLAT HEAD SCREW - 12 Page 4 www.sauder.com/service 433242...
- Page 5 The arrow in the HIDDEN CAM must point Arrow toward the hole in the edge of the board. Hidden Cam Hole Insert the CAM SCREW or CAM DOWEL into the HIDDEN CAM. Tighten the HIDDEN CAM. 433242 www.sauder.com/service Page 5...
- Page 6 Step 1 Look for this icon. It means a video assembly tip is available at www.sauder.com/service/tips Find the numbered video or scan the QR code. å Assemble your unit on a carpeted floor or on the empty carton to avoid scratching your unit or the floor.
- Page 7 Unfinished edge i t h f a c S u r D E N H I D Unfinished edge i t h f a c S u r D E N H I D 433242 www.sauder.com/service Page 7...
- Page 8 Fasten the RIGHT END (B) to the BOTTOM (D) and SHELF (E). Tighten four HIDDEN CAMS. å NOTE: Be sure the WOOD DOWELS in the END insert into the BOTTOM and SHELF. These holes must be here. Page 8 www.sauder.com/service 433242...
- Page 9 SAFETY STRAP 2" FLAT HEAD SCREW (4 used in this step) The SAFETY STRAP should be closer to this edge. i t h f a c S u r o l e r e h 433242 www.sauder.com/service Page 9...
- Page 10 Fasten the BACK (J) to your unit using the NAILS (6). å NOTE: Be sure to tap NAILS into the holes that line up over the SHELF (E). NAIL (30 used in this step) These holes must line up over the SHELF (E). Page 10 www.sauder.com/service 433242...
- Page 11 - Fasten the unit to the wall. Use the LONG SCREW through the other end of the SAFETY STRAP and into the 1/8" hole. Electric drill with 1/8" bit Mark and drill a 1/8" hole into the wall stud. 433242 www.sauder.com/service Page 11...
- Page 12 å NOTE: You will need to turn the LONG SCREW multiple turns to completely tighten and secure your unit to the wall. Mark and drill a 3/8" hole Electric drill with 3/8" bit into the wall. Page 12 www.sauder.com/service 433242...
- Page 13 Step 8 å Insert the SHELF PINS (5) into the hole locations of your choice in the ENDS (A and B). Set the ADJUSTABLE SHELVES (F) onto the SHELF PINS. (8 used) 433242 www.sauder.com/service Page 13...
- Page 14 Step 9 å Fasten the HINGES (7) to the DOORS (G and H). Use twelve 1/2" FLAT HEAD SCREWS (12). 1/2" FLAT HEAD SCREW (12 used in this step) Page 14 www.sauder.com/service 433242...
- Page 15 Fasten one PULL (4) to the LEFT DOOR (G). Use two 5/8" MACHINE SCREWS (11). å Repeat this step for the RIGHT DOOR (H). å See the next step for DOOR adjustments. 5/8" MACHINE SCREW (4 used for the PULLS) 433242 www.sauder.com/service Page 15...
- Page 16 To adjust the DOOR in or out (depth), loosen the mounting screw one turn and move the DOOR in or out, as needed. Tighten the mounting screw after making adjustments. Mounting screw (depth) Adjusting screw (horizontal) (vertical adjustment) Page 16 www.sauder.com/service 433242...
- Page 17 Almost time to å Peel BUMPERS from the BUMPER CARD (9) and stick them celebrate! With a nap. onto the bottom corner of each DOOR (G and H) where the DOOR comes into contact with the BOTTOM (D). 433242 www.sauder.com/service Page 17...
- Page 18 NOTE: Please read the back pages of the instruction booklet for important safety information. å This completes assembly. Clean with a damp cloth. Wipe dry. And to celebrate, why not share your success story at sauder.com or Page 18 www.sauder.com/service...
- Page 19 Modèle 433242 Meuble de rangement Utilisez les instructions d’ a ssemblage en français avec les NOUS CONTACTER EN PREMIER schémas étape par étape du manuel d’instruction en anglais. AVANT D'EFFECTUER TOUT RETOUR AU MAGASIN. Chaque étape en français correspond à la même étape en Nous faisons de notre mieux pour nous assurer que votre meuble anglais.
- Page 20 DROITE (B). Fixer l'EXTRÉMITÉ GAUCHE (B) au DESSOUS (D) et à la TABLETTE (E). Serrer quatre EXCENTRIQUES ESCAMOTABLES. REMARQUE : S’ a ssurer d’insérer les CHEVILLES EN BOIS d’EXTRÉMITÉ dans le DESSOUS et la TABLETTE. Page 20 www.sauder.com/service 433242...
- Page 21 à chaque VIS avant de les serrer toutes à bloc. Fixer une POIGNÉE (4) à la PORTE GAUCHE (G). Utiliser deux VIS À MÉTAUX 16 mm (11). Répéter cette étape pour la PORTE DROITE (H). Voir l'étape suivante pour réglages des PORTES. 433242 www.sauder.com/service Page 21...
- Page 22 EXTREMO IZQUIERDO ..........1 EXCÉNTRICO ESCONDIDO .......8 su referencia futura. Si necesita ponerse en EXTREMO DERECHO ..........1 BIELA DE EXCÉNTRICO ........8 contacto con Sauder en PANEL SUPERIOR ............1 PASADOR DE MADERA ........12 cuanto a esta unidad, FONDO .................1 TIRADOR ................2 refiérase al número de lote y al número de...
- Page 23 Fije el EXTREMO DERECHO (B) al FONDO (D) y al ESTANTE (E). Apriete cuatro EXCÉNTRICOS ESCONDIDOS. NOTA: Asegúrese de que los PASADORES DE MADERA en el EXTREMO se inserten en el FONDO y en el ESTANTE. 433242 www.sauder.com/service Page 23...
- Page 24 Fije un TIRADOR (4) a la PUERTA IZQUIERDA (G). Utilice dos TORNILLOS PARA METAL de 16 mm (11). Repita este paso para la PUERTA DERECHA (H). Consulte el próximo paso para ajustar la PUERTA. Page 24 www.sauder.com/service 433242...
- Page 25 TOUJOURS décharger les tablettes et les tiroirs, en commençant par les surface supérieures, avant de déplacer le meuble. NE JAMAIS pousser ou tirer un meuble sur de la moquette. Demander à une autre personne de le soulever correctement pour le déplacer et/ou le repositionner. 433242 www.sauder.com/service Page 25...
- Page 26 SIEMPRE descargue los estantes y cajones, empezando con las superficies superiores, antes de moverlo. NUNCA empuje ni tire de los muebles sobre una alfombra. Obtenga que un amigo le ayude a levantarlo correctamente para moverlo y/o reposicionarlo. Page 26 www.sauder.com/service 433242...
- Page 27 à compter de la date d'achat la première fois et qui sont signalés à Sauder dans les limites de couverture de la contre tout défaut de matériaux ou de fabrication des composantes de mobilier Sauder.
- Page 28 BEFORE MAKING ANY RETURNS TO THE RETAILER. So, how did it go? Dear Valued Customer: Thanks so much for choosing Sauder® furniture. I hope the Set a world record for speed? purchase and assembly process was a positive experience Feeling good about yourself? and you feel good about the furniture you just built.
