Summary of Contents for inDESIGN iD-HC Series
-
Page 2: Table Of Contents
CONTENTS INTRODUCTION INTRODUCTION Thank you for choosing inDESIGN iD-HC power amplifiers for your application. Please spare some time to read the contents of this IMPORTANT SAFETY manual, so you can obtain the best possible performance and INSTRUCTIONS longevity of the product/s. -
Page 3: Important Safety Instructions
They can take this product for environmental-safe recycling. WARNING: There are no user serviceable parts inside. Refer all servicing to qualified service personnel. iD-HC SERIES: INSTALLATION & OPERATION MANUAL PAGE 3... -
Page 4: Front Panel
Illuminates when each channel is in normal operation. CH1-CH2: Level Control potentiometer for each channel. Stereo and Input Link Modes: Both CH1 and CH2 controls are active. Bridge Mode: Only CH1 level control is active. PAGE 4 iD-HC SERIES: INSTALLATION & OPERATION MANUAL... -
Page 5: Rear Panel
Channel 1 level control potentiometer will be active. Both channel 2’s input and level control potentiometer are inactive in BRIDGE MODE. The NL4 wiring must be configured as PIN 1+ and 2+ in BRIDGE MODE. Speakon (NL4) iD-HC SERIES: INSTALLATION & OPERATION MANUAL PAGE 5... -
Page 6: Maintenance
To clean the dust filters: 1. Remove the 6 front panel screws shown in the figure above. 2. Used compressed air, a vacuum or brush to clean the dust from filters. 3. Re-assemble the front panel. PAGE 6 iD-HC SERIES: INSTALLATION & OPERATION MANUAL... -
Page 7: Amplifier Cooling
Please observe the following figures below for venting recomendations. UNENCLOSED OR OPEN RACK INSTALLATION ENCLOSED RACK INSTALLATION Expel hot air from enclosure with evacuation fans. Ensure vented hot air does not re-circulate into front cooling vents. iD-HC SERIES: INSTALLATION & OPERATION MANUAL PAGE 7... -
Page 8: Specifications
Product Dimensions (2RU) WxDxH 483 x 456 x 88 mm Product Weight 18.6kg 21.6kg 25.6kg Carton Dimensions WxDxH 570 x 560 x 145 mm Gross Weight 19kg 24kg 28kg * Disclaimer: Instructions and specifications are correct at time of printing. Information within may be subject to change without notice. PAGE 8 iD-HC SERIES: INSTALLATION & OPERATION MANUAL... - Page 9 NOTES iD-HC SERIES: INSTALLATION & OPERATION MANUAL PAGE 9...
- Page 10 NOTES PAGE 10 iD-HC SERIES: INSTALLATION & OPERATION MANUAL...
-
Page 11: Warranty Info
The Warranty offered by NAS is not transferable. The Warranty will only apply if your NAS product has been installed and used in accordance with NAS’s recommendations as noted in the operating instructions. iD-HC SERIES: INSTALLATION & OPERATION MANUAL PAGE 11... - Page 12 The Warranty excludes accessories and consumable goods which have ceased working through normal wear and tear such as, but not limited to, batteries, lamps and other parts classifiable as a consumable part. This includes the CD mechanism and laser fitted to the inDESIGN iDCDP-110. These parts carry a 3 month warranty.
