McCall H5-5001 Specifications

H5-5001
McCall Refrigeration specification sheets are available
online @ www.mccallrefrigeration.com
Cabinet - Cabinets are all metal, inside and out.
The top, back, and bottom are made of galvanized
steel. In addition, all seams are closed and
sealed, with metal edges turned away from the
exposed surface. The result is an integrated
structural frame. Internal corners are coved to
conform to NSF standards. Automatic interior
lighting is controlled by a light switch concealed
in the door hinge.
Doors - Constructed of metal, refrigerator doors
are self-closing and fully insulated. Their cam-lift
hinges are chrome-plated and self-lubricating.
Hinges also have a safety stop that holds the door
open, preventing overswing. Chrome-plated pull
handles have built-in cylinder locks. The full-
Phone (731) 847-5570 / Fax (731) 847-9012 / 1-888-REACH-IN (1-888-732-2446) / www.mccallrefrigeration.com
CLASSIFIED TO
NSF (STD-7-1999)
SPECIFICATIONS
perimeter, magnetic vinyl gaskets are removable
without the use of tools. The bottoms of all door
openings are supplied with full-width sweeper
gaskets. Doors easily lift off, and door perimeters
have a built-in, low wattage, and anti-condensate
heater. Door openings are protected by an
impact-resistant, nonconductive PVC breaker strip
with no exposed screws or fasteners. (Except
bottom of door opening.)
Insulation - Cabinet body, doors, and evaporator
coil housings are filled with pressure-injected
polyurethane foam.
Self-Contained Refrigeration - The complete
refrigeration assembly is mounted on top of the
McCall Refrigeration / 81 West Holly Street / Parsons, TN 38363
January 2007 / Printed in U.S.A.
ITEM #
MODEL #
PROJECT NAME
B R
AKERY
(1 S
ECTION
Model: H5-5001
Cabinet Interior / Exterior Specifications
5000 Series - Stainless interior and exterior.

Standard Features

• Top mounted compressor
• Expansion valve
• Cord and plug (115 Volt Only)
• R-134a refrigerant
• Exterior digital thermometer (1000 series)
dial thermometer (2000-4000 series)
• Self-closing cam-lift hinges
• Chrome-plated door handles with security locks
• Magnetic door gaskets
• Removable stainless steel ramp, each door opening
• Windrunner gradient air displacement process
Approval :
cabinet behind a removable hatch cover, except
three door has interior mounted coil. Refrigeration
components include a hermetically sealed
compressor, the thermostatic expansion valve,
thermostatic temperature control, high-humidity
evaporator coil and hot gas condensate
evaporator. The refrigerator system is balanced to
maintain 38°F average internal air temperature.
Windrunner gradient air displacement process in
the refrigerator model provides even air flow and
temperature control throughout the cabinet. All
components are factory installed and tested, and
supplied with a master power switch, and exterior
digital thermometer (1000 series) dial
thermometer (2000-4000 series).
SIS #
ETARDERS
)
AIA #
