Summary of Contents for Sky Elevator SKY 200-2
- Page 1 INSTRUCTION, USE AND MAINTENANCE MANUAL FOR SKY 200-2 OVERSPEED GOVERNOR TYPE SKY 200-2 10KG TENSION WEIGHT WITH HORIZONTAL COUNTERWEIGHT TYPE SKY-281...
-
Page 2: Table Of Contents
Ma ntenance and control Execut on of repa rs TECHNICAL DATA Overspeed governor type SKY 200-2 Tens on we ght w th counterwe ght * SKY 200-2 = B d rect onal ntervent on SKY 281 Down d rect on ntervent on... -
Page 3: General Information Before Beginning The Assembly
GENERAL INFORMATION BEFORE BEGINNING THE ASSEMBLY DESCRIPTION, OPERATION MODE The overspeed governor s a safety dev ce wh ch turns on when the allowed speed of the elevator car s excee- ded. If the elevator car, dur ng ts upward/downward run, exceeds ts nom nal perm ss ble speed, (unt l the tr pp ng speed s reached), the overspeed governor turns on and, n turn, releases –... - Page 4 The overspeed governor can be suppl ed for the assembly n the eng ne room. DISPOSITION IN THE ENGINE ROOM Overspeed governor Control dev ce Governor rope Safety gears Rope anchor...
- Page 5 For the assembly on the top of the elevator shaft, the overspeed governor must be eas ly access ble from the outs de (e.g. through a ma ntenance door). DISPOSITION ON THE TOP OF THE ELEVATOR SHAFT Ma ntenance door Overspeed governor Governor console Control dev ce...
-
Page 6: Respons B L Ty And Guarantee
1.2 RESPONSIBILITY AND GUARANTEE These operat ng nstruct ons are addressed to persons, who are well acqua nted w th the assembly of eleva- tors. Thorough knowledge of the elevator construct on and ma ntenance are necessary. The firm P.F.B. decl nes any respons b l ty for damages, der v ng from not workmanl ke or s m lar act ons, that have not been carr ed out accord ng to the follow ng operat ng nstruct ons and that therefore may damage the character st cs of the product. -
Page 7: Operat Ons Schedul Ng
The data conta ned n the type-plate have to be compared w th the order. 1.6 TYPE-PLATE, TEST MARK, IDENTIFICATION The type-plate of the OVERSPEED GOVERNOR s attached to the structure on the s de. The reta ler of the plant s respons ble for t be ng leg ble. Sky Elevator 2021... -
Page 8: Const Tut On Of Supply
1.7 CONSTITUTION OF SUPPLY F g. 1 Overspeed governor Type SKY 200-2 Abb. 1 F g. 2 Tens on we ght w th hor zontal counterwe ght for the gu de and tens on of the rope (opt onal w th safety sw tch for the vers on n conform ty to EN 81). -
Page 9: Assembly
ASSEMBLY For all the assembly works n the eng ne room or n the elevator shaft, t should be made clear that: The entrance nto the assembly area, resp. the execut on of all works can be carr ed out only by sk l- led workers. -
Page 10: 2.1.2 Assembly On The Top Of The Elevator Shaft
ASSEMBLY STEPS • If a support s used, first of all screw t on together w th the over- speed governor (fig. 1). • Place the overspeed governor on the pass ng open ng of the ro- pe and al gn t w th the plumb l ne to the brake dev ce, .e. the sa- fety gear (fig. -
Page 11: Assembly Of The Rope Of The Overspeed Governor/Tens On We Ght W Th Counterwe Ght
ASSEMBLY OF THE ROPE OF THE OVERSPEED GOVERNOR/TENSION WEIGHT WITH HORIZONTAL AND VERTICAL COUNTERWEIGHT A techn cally perfect operat on of the overspeed governor s only poss ble w th a correct assembly of the go- vernor rope tself and of the tens on we ght w th counterwe ght. Wh le determ n ng at wh ch he ght the tens on we ght w th counterwe ght has to be mounted, t must be made clear that: - n no case, the counterwe ght must touch the floor (fig. - Page 12 TENSION PULLEY WITH HORIZONTAL COUNTERWEIGHT • Mount the mount ng support at about 450 mm (ap- prox. value, fig. 3) on the bottom of the shaft. • Hold the counterwe ght, unt l t s n an obl que pos - t on (fig.
-
Page 13: Electr C Nstallat On Of The Safety Sw Tches
The safety sw tches d sconnect the safety c rcu t of the elevator plant. The follow ng safety sw tches must be connected: F g. 1 Overspeed governor type SKY 200-2 - SKY 281 Safety sw tch Safety sw tch F g. -
Page 14: Setting Up Operations
SETTING UP OPERATIONS OVERSPEED GOVERNOR The safety sw tch of the overspeed governor has already been set n the factory. Its pos t on s fixed w th sea- l ng-wax and t cannot be mod fied. The sett ng up of the safety sw tch on the overspeed governor s not necessary. TENSION WEIGHT WITH COUNTERWEIGHT (EN 81 and TRA) Only n plants n conform ty to EN 81: a) w th tens on pulley w th hor zontal counterwe ght:... -
Page 15: Operation Testing
OPERATION TESTING Although qual ty and operat on of each component are controlled by the factory at the del very, before sale, eventually, before the final test of the plant, an operat on test ng should be carr ed out. TEST RUN AFTER THE ASSEMBLY Clean the gu des before the first test run takes place. -
Page 16: Maintenance, Control, Repair
MAINTENANCE, CONTROL AND REPAIR MAINTENANCE AND CONTROL Generally, the overspeed governor and respect ve tens on we ght w th counterwe ght do not need any ma nte- nance. The whole plant has been conce ved n such a way that, w th proper use w thout damages, there s no need for mportant ma ntenance ntervent ons. -
Page 17: Technical Data
Pay attent on to the m n mum d stance between the shaft bottom and the counterwe ght (s. PAR. 2.2). TECHNICAL DATA OVERSPEED GOVERNOR TYPE SKY 200-2 - SKY 281 Ingrand mento “A” “A” nset Agrand ssement “A”... - Page 18 TENSION WEIGHT WITH HORIZONTAL/VERTICAL COUNTERWEIGHT 10KG...
- Page 19 TENSION WEIGHT WITH HORIZONTAL/VERTICAL COUNTERWEIGHT Component meccan c per ascensor - Mechan cal l ft components SKY ELEVATOR http://www.skyelevator.de E-ma l: sky@skyelevator.de http://www.sky-elevator. t E-ma l: sky@sky-elevator. t http://www.sky-elevator.bg E-ma l: sky@sky-elevator.bg http://www.sky-elevator.com - E-ma l: sky@sky-elevator.com...
- Page 20 Manufacured Date: 2021 Serial Number :...
