McCall LTA-20-FRE Specifications

STA-20-FRE
STA-30-FRE
McCall Refrigeration specification sheets are available
online @ www.mccallrefrigeration.com
Cabinet - Stainless steel front, door(s) and exterior ends.
All metal, welded construction. All joints and seams
closed and sealed. Zinc coated steel exterior bottom and
rear with coved, sanitary aluminum interior (S/S interior
available if specified).
Doors - Self-closing with full face S/S exterior and
aluminum inner pan standard, stainless steel optional.
Door insulated with one-shot, polyurethane and one
piece vinyl, self-adjusting magnetic gasket keyed into a
thermal-breaker retainer frame. Gaskets are removable
without tools for cleaning. All door openings have full
perimeter minimum-wattage anti-condensate heaters
behind the S/S facia to retard condensation. One piece
Phone (731) 847-5570 / Fax (731) 847-9012 / 1-888-REACH-IN (1-888-732-2446) / www.mccallrefrigeration.com
F
W
Models: Aluminum Interior
STSA-20-FRE, STSA-30-FRE
Stainless steel top and back splash
STA-20-FRE, STA-30-FRE

Stainless steel top

LTA-20-FRE, LTA-30-FRE
Unfinished for undercounter or field installed top.
Models: Stainless Steel Interior
STSS-20-FRE, STSS-30-FRE
Stainless steel top and back splash
STS-20-FRE, STS-30-FRE
Stainless steel top
LTS-20-FRE, LTS-30-FRE
Unfinished for undercounter or field installed top.
Standard Features
CLASSIFIED TO
NSF (STD-7-1999)
SPECIFICATIONS
door pull with concealed self-closing hinge mechanism,
safety stops and stay open feature.
Insulation - Entire cabinet and door insulated with
special, extra rigid one-shot, high pressure, foamed-in-
place, closed cell polyurethane, average thickness 2".
Interior Shelves - Two heavy-duty, adjustable,
removable epoxy coated shelves are furnished for
each door section.
Refrigeration evaporator - includes a high efficiency,
space saver diffuser with fin coil for extra long life.
Liquid line solenoid valve and thermostatic expansion
McCall Refrigeration / 81 West Holly Street / Parsons, TN 38363
January 2007 / Printed in U.S.A.
ITEM #
MODEL #
PROJECT NAME
REEZER
T
ORK ABLES
• "One-shot" high pressure foamed-in-place
polyurethane insulation
• Stainless steel fronts, doors and exterior ends
• Self-closing doors with safety stops and stay open features
• One-piece removable magnetic door gaskets
• Automatic thermostat and timer
• High-efficiency, space-saver diffuser with fin coil
• Time-initiated defrost system
Approval :
SIS #
-R
EMOTE
valve(s) and thermostat control provided. The refrigerant
(R 404A) furnished by others. A condensate drain or
evaporator must be provided.
Tops - All freezer models are available with full size
S/S counter tops and matching integral S/S back
splash. All freezer models are available with S/S flat
tops. The sub-top is available for undercounter and
built-in applications.
Condensing unit is not provided.
AIA #
