Summary of Contents for LJ Star LumiStar 3000 LED
- Page 1 LumiStar 3000 ® Installation and Operating Instructions P.O. Box 1116 Twinsburg, OH 44087 Phone: 330/405-3040 • Fax: 330/405-3070 E-mail: view@ljstar.com • Web Site: www.ljstar.com...
- Page 2 Table of Contents 1.00 Warranty ........................2 1.10 Exceptions 1.20 Provisions 2.00 Introduction ........................2 2.10 Important Note on Application 2.20 General Operating Conditions 3.00 Mechanical Installation .....................3 3.10 Sight Glass Types and Sizes Suitable for Mounting 3.20 Mechanical Installation – USL16 3.21 Mounting using Hinged Bracket 3.22 Mounting using Flange Adapter 3.30 Mechanical Installation –...
- Page 3 1.00 Warranty L. J. Star warrants its LumiStar3000 LED Luminaires against defects in material and workmanship for a period of eighteen months from the date of shipment. L. J. Star will, at its option, repair or replace those products that fail to perform as specified with the following exceptions.
- Page 4 3.00 Mechanical Installation 3.10 Sight Glass Types and Sizes Suitable for Mounting - Circular weld-on sight glass fitting to DIN 28120: size DN 50 (3” view diameter) and larger - Circular ANSI bolt-on sight window: size 2” and larger - Visual flow indicators: size 2” and larger - Circular weld-neck sight glass fitting series MV: size DN 50 and larger Smaller sizes require flange adapter - Sanitary clamp connection series MetaClamp: size 1”...
- Page 5 4.00 Electrical Installation 4.10 Supply Requirements - Low Voltage: 24V (AC or DC) - High Voltage: 110-240V AC - Power: 40W Recommended - Electrical Isolation - Connect supply to separate branch circuit to avoid potential interference from adjacent equipment. 4.20 Electrical Connection WARNING ELECTRICAL CONNECTIONS MUST BE MADE WITH NO POWER...
- Page 6 5.00 Operation 5.10 Direct Operation The below instructions apply to LED luminaires that are not directly coupled to a switch. - The LED luminaire will turn on and remain on while power is supplied. - When power is removed, the LED luminaire will turn off and remain off. - Control power supplied to light using an external switch WARNING LIGHT IS NOT INTENDED FOR UNINTERRUPTED USE.
- Page 7 7.00 Maintenance - Keep luminaire clean and free of dust. - Inspect luminaire for damage to glass. - Inspect luminaire for inadequate sealing, shown by moisture buildup on the interior of the lens. - Allow luminaire to cool prior to performing washdown procedures. Failure to do so presents a risk of water intrusion due to induced vacuum from sudden cooling of the interior of the luminaire.
