Powerful 110 Litres Per Minute Free Air Delivery
(29 Gallons Per Minute / 6,700 Cubic Inches Per Minute)
55 Minute Duty Cycle @ 40 PSI (276 kPa)
Thermal Cut Out and Auto Reset Circuit Protection
0.65HP (0.48kW) Permanent Magnet Motor
45mm (1.8") Diameter Cylinder
Built-in Air Filter
5m (16.5') Rubber Air Hose with Quick Connectors
Dual Control - Wireless (via Remote) and Manual
Powerful 180 Litres Per Minute Free Air Delivery
(47.5 Gallons Per Minute /11,000 Cubic Inches Per Minute)
45 Minute Duty Cycle @ 40 PSI (276 kPa)
Thermal Cut Out and Circuit Breaker Protection
0.73HP (0.54kW) Permanent Magnet Motor
60mm (2.4") Diameter Cylinder
Built-in Air Filter
5m (16.5') Rubber Air Hose with Quick Connectors
Dual Control - Wireless (via Remote) and Manual
SAVE THIS MANUAL: Keep this manual in a safe place for future reference. This manual
contains useful information relating to the safe use of an air compressor.
PART No.
MMACM3
MMACA4
Advertisement
Table of Contents
Summary of Contents for MEAN MOTHER MAXI 4X4 III
- Page 1 PART No. MMACM3 MMACA4 Powerful 110 Litres Per Minute Free Air Delivery (29 Gallons Per Minute / 6,700 Cubic Inches Per Minute) 55 Minute Duty Cycle @ 40 PSI (276 kPa) Thermal Cut Out and Auto Reset Circuit Protection 0.65HP (0.48kW) Permanent Magnet Motor 45mm (1.8”) Diameter Cylinder Built-in Air Filter 5m (16.5’) Rubber Air Hose with Quick Connectors...
-
Page 2: Compressor Features
WARNING! TO PREVENT SERIOUS INJURY, PLEASE READ AND UNDERSTAND ALL WARNINGS AND INSTRUCTIONS BEFORE USE. Due to continuing improvements, actual product may differ slightly from the product described. Items described such as tools and hardware within this operation manual may not be included. Images and drawing are for illustrational purposes only. - Page 3 General Information Maximum Air Flow 110 Litres Per Minute (29 Gallons Per Minute / 6,700 Cubic Inches Per Minute) Voltage 12 Volt DC Duty Cycle 55 Minutes at 40 PSI (276 kPa) Motor Output Power 0.65HP (0.48kW) Maximum Current 40 Amp Maximum Pressure 150 PSI (1,034 kPa) Cylinder Diameter...
- Page 4 General Information Maximum Air Flow 180 Litres Per Minute (47.5 Gallons Per Minute / 11,000 Cubic Inches Per Minute) Voltage 12 Volt DC Duty Cycle 45 Minutes at 40 PSI (276 kPa) Motor Output Power 0.73HP (0.54kW) Maximum Current 45 Amp Maximum Pressure 150 PSI (1,034 kPa) Cylinder Diameter...
-
Page 5: Power Consumption
4WD’s tyre traction. and Cubic Inches Per Minute capability. By travelling with a Mean Mother Air Compressor Mean Mother Air Compressors F.A.D. (Free Air you will have the ability to adjust the tyre pressure Delivery) have been rated at 0 PSI. -
Page 6: Safe Handling
The WARNING compressor protection circuit will automatically reset when the temperature returns to a safe opera- Mean Mother Air Compressors generate a ting level. lot of heat so wear appropriate gloves to protect your hands. DO NOT touch the unit... -
Page 7: Operating Your Air Compressor
stressed or WHEN UNDER THE INFLUENCE OF air. This air compressor is NOT designed for use as a DRUGS, ALCOHOL OR MEDICATION........source of breathable air. FREE AIR FLOW: REPLACEMENT PARTS & ACCESSORIES: This air compressor is designed for continuous air The air compressor is permanently lubricated during flow. - Page 8 STEP 3: Choose whether you wish to use the screw type connector or the thumb lock adaptor. The screw type connector will give you the best results......................a) The screw type connector is already attached to the 0.5 metre adaptor hose (with gauge) and is ready for use.
- Page 9 STEP 7: Allow your compressor to cool before stowing away. Place cooled compressor neatly into the bag supplied and close ready for the next use. Store the compressor in a dry location........COMPRESSOR OPERATING TIPS TIP 1: It is always good practice to confirm the tyre pressure with a separate gauge. TIP 2: Use the “deflation button”...
-
Page 10: Troubleshooting
TROUBLESHOOTING This should be used as a guide only; we recommend you seek professional advice should you experience any technical issues....................................... Compressor does not operate under normal conditions: – Vehicle battery or power source should be in good working order and fully charged. –... -
Page 11: Warranty
Mean the Product has been repaired, altered or modified Mother Adventurer IV and Maxi 4X4 III Air Compressors. The by someone other than Haigh Australia or an autho- benefits of this warranty are in addition to any rights and rised repair agent;... - Page 12 FCC ID: 2AKJ8-MMACRC Wireless Remote Red LED Control ON/OFF Indicator Button 1 x 12V 23A Size Magnet L1028 Alkaline Battery User Manual Antenna Frequency Range: 2.4GHz Antenna Type: PCB Antenna Antenna Gain: +1.6dBi Transmission Power: < -1dBm Remote Control Distance: >...
