Summary of Contents for Fred's Royal WEEDER STJ-150A/10.8
- Page 1 Retired organic gardener and inventor of the Royal Weeder. Fred Happy Gardening, U S E R G U I D E For questions or comments, please call 541-708-6606...
-
Page 2: Letter From The Inventor
Fellow Gardeners, Thank you for purchasing Fred’s Royal Weeder, the lightest electric tiller on the gardening market. A bit of background on the creation of Fred’s Royal Weeder might inter- est you. Once upon a time, my wife, Ilona, and I had a farm in Northern California where we grew organic asparagus. -
Page 3: Table Of Contents
Package Contents ......4 Charging the Battery ......14 Parts & intended Use ......5 Troubleshooting ......15 Safety Information ......6-7 Warranty ..........15 PRODUCT SPECIFICATIONS MODEL STJ-150A/10.8 Battery voltage 10.8 V Blade speed 200 rpm/Minimum Blade size 6 inches / 150 mm Net weight 3.2 Lbs... -
Page 4: Package Contents
10.8 V cordless WEEDER/TILLER MODEL STJ-150A/10.8 Rechargeable battery Main handle On-off switch Switch lock Adjustable handle Adjustable handle lock Upper telescope shaft Height adjustment knob Lower telescope shaft 10. Telescope tube plug 11. Motor cover 12. Shield /Guard 13. Tiller blade... -
Page 5: Parts & Intended Use
Parts and Intended Use 1 Adjustable Auxilary Handle 6 Washer 2 Unit with Motor 7 M8 nut 3 Plastic shield /guard 8 Wrench 4 2-ST3.5x13 screws 9 Rechargeable battery 5 Tiller blade 10 Battery charger/ charger pedestal INTENDED USE • The Royal Weeder is designed for weeding, loosening soil in garden and blending ®... -
Page 6: Safety Information
Safety Information SYMBOLS Warning of risk of personal injury or damage to the weeder Read this instruction manual Always wear safety goggles while using the weeder Wear boots and gloves when using the weeder Risk of electrical shock IMPORTANT INFORMATION AND WARNINGS •... - Page 7 Safety Information SAFETY FOR HANDS AND FEET • Always operate the weeder using both hands. • Wear gloves and boots when using this tool. SAFETY FOR EYES • Always wear safety glasses when operating the weeder. • The operation of any power tool can result in foreign objects being thrown into your eyes which can result in severe eye damage.
- Page 8 Safety Information POWER TOOL USE AND CARE • Do not force the power tool. Use the correct power tool for your application.The correct power tool will do the job better and safer at the rate for which it was designed. •...
-
Page 9: Assembly Instructions
Assembly Instructions IMPORTANT - READ INSTRUCTIONS BEFORE ASSEMBLING • Read this instruction manual and carefully follow instructions for assembling or adjusting the weeder. • Remove the battery while assembling the weeder. • Read and understand the battery charging instructions on page 13. •... - Page 10 Assembly Instructions 2. MOUNT THE SHIELD/GUARD • Mount the clear plastic guard to the weeder (fig.2-a). • Fasten the guard with two ST3.5*13 screws using a phillips screwdriver (fig.2-b). Note: Put a small amount of oil on the screws before screwing in. figure 2-a figure 2-b 3.
- Page 11 Assembly Instructions 4. MOUNT THE ADJUSTABLE HANDLE Press the lock button on aluminum shaft (1) on opposing sides, and at the same time insert the handle (2) fitting one side first, then allowing the other side of the handle to snap into place.(fig.4-a) figure 4-a When handle is in position, the lock button will lock the handle in place automatically.
- Page 12 Assembly Instructions 5. ADJUST THE LENGTH OF THE WEEDER (fig.5-a) • Loosen the lower half of the knob located in the middle of aluminum shaft by turning it clockwise. • Pull the lower shaft up or down to adjust to desired height. •...
-
Page 13: Care & Maintenence
Care and Maintenence WARNING Remove the battery before performing maintenance to the weeder • Keep the weeder battery and handle away from dirt and water. • Clean after use with a wet cloth. • Do not use harsh detergents or other solvents on plastic parts. •... -
Page 14: Charging The Battery
Charging the Battery 6. CHARGING THE BATTERY • The charger includes two parts: the adapter (a) and the charger pedestal (c). • Do NOT use any other type of charger. This charger is only for use for this type of battery. •... -
Page 15: Troubleshooting
Troubleshooting & Warranties If you still have questions or an unresolved issue after going through this troubleshooting guide, or if you’d like to speak to our customer service, please email: fred@royalweeder.com or call 541-708-6606. Problem Possible Cause Corrective Action Weeder runs at a Battery is not fully Remove battery and place in sluggish speed... - Page 16 Purchase date ____________________ Purchased from___________________ Attach receipt here Questions, problems, missing parts? Email our Customer Service Department at: 541-708-6606 or email fred@royalweeder.com The Royal Weeder ® Royal Weeder, Inc. 415 Williamson Way #7 Ashland, OR 97520 USA www.royalweeder.com...
