- Page 1 ® Superabrasive Owner’s manual original language – Lavina V20GE 02/2022 LAVINA V20GE USER MANUAL ® Tech Support Line: 800-987-8403 | www.superabrasive.com | info@superabrasive.us...
- Page 2 ® Superabrasive Owner’s manual original language – Lavina V20GE 02/2022...
-
Page 3: Table Of Contents
® Superabrasive Owner’s manual original language – Lavina V20GE 02/2022 Contents 1. WARRANTY AND RETURNS ........................5 1.1 WARRANTY POLICY FOR LAVINA® V20GE ..................5 1.2 RETURN POLICY FOR LAVINA® VACUUMS ..................6 2. GENERAL INFORMATION ........................7 2.1 MANUFACTURER ........................... 7 2.2 GENERAL DESCRIPTION ......................... - Page 4 ® Superabrasive Owner’s manual original language – Lavina V20GE 02/2022 8. MAINTENANCE AND INSPECTION ..................... 23 8.1 CHECK DAILY ..........................24 8.2 CHECK AND REPLACE AFTER THE FIRST 8 WORKING HOURS ............24 8.3 CHECK AND REPLACE EVERY 50 WORKING HOURS ..............24 8.4 RECOMMENDED OIL CHANGE INTERVALS ..................
-
Page 5: Warranty And Returns
Superabrasive offers a guarantee on LAVINA® vacuums, covering manufacturing and material defects, for a period of 24 months from the date of purchase, as invoiced by Superabrasive. The following conditions pertain to this warranty: •... -
Page 6: Return Policy For Lavina® Vacuums
Vacuums returned without prior authorization will remain property of the sender and Superabrasive Inc. will not be responsible for these. • No vacuums will be credited after 90 days from the date of Superabrasive’s invoice. • All returns must be shipped freight prepaid. -
Page 7: General Information
2.1 MANUFACTURER Superabrasive was founded in 1987, as a manufacturer of high quality diamond tools for the stone and concrete industry. Today, Superabrasive is one of the world’s leading companies in the production of diamond tools and floor grinding machinery. At Superabrasive, we strive to deliver the very best solutions to our customers, and enable them to work more efficiently. -
Page 8: Main Components And Controls
® Superabrasive Owner’s manual original language – Lavina V20GE 02/2022 3. MAIN COMPONENTS AND CONTROLS Figure 3.1 1. Fixed wheel ( 2 total ); 12. Intermediate 3”” hose; 2. Caster locking wheel; 13. Valve ( 2 total – one for jet pulse filter 3. -
Page 9: Technical Data
Owner’s manual original language – Lavina V20GE 02/2022 Customer Service - For customer assistance and technical support call your local distributor or call Superabrasive Inc. at 1-800-987-8403 or visit us at www.superabrasive.com , where you can download a copy of this manual. -
Page 10: Preparation For Work
® Superabrasive Owner’s manual original language – Lavina V20GE 02/2022 • For collecting non-suitable materials (asbestos or other toxic materials) ; • In environments which (1) Possess the risk of explosion, (2) Possess high concentration of powders or oil substances in the air, (3) Possess the risk of fire, (4) Feature inclement conditions, (5) Possess electromagnetic radiation;... -
Page 11: The Work Area
® Superabrasive Owner’s manual original language – Lavina V20GE 02/2022 5.9 THE WORK AREA Ensure that the area is free of unauthorized people or vehicles, hoses, and always check the floor for debris. 5.10 PERSONAL PROTECTIVE EQUIPMENT (PPE) When operating the machine, always wear safety shoes, ear protectors, safety gloves (especially when changing tools), and suitable clothing. -
Page 12: Propane Safety
® Superabrasive Owner’s manual original language – Lavina V20GE 02/2022 • When storing the vacuum, the filter should be removed and cleaned, and the waste container should be emptied of debris. Store the vacuum in temperatures between 32°F and 104°F (0°C and 40°C). -
Page 13: Propane Cylinders
® Superabrasive Owner’s manual original language – Lavina V20GE 02/2022 With regard to operation of propane powered floor care equipment, even though NFPA #58 8-4.5 says “these machines shall be permitted to be used in buildings frequented by the public, including the times when such buildings are occupied by the public,”... -
Page 14: Refuelling Cylinders
® Superabrasive Owner’s manual original language – Lavina V20GE 02/2022 The vapor draw cylinder is used on small machines like the propane powered floor care machines. The vacuum generated by the engine draws up the Propane gas vapor through the fuel system. -
Page 15: Unpacking, Handling, Transportation And Storage
® Superabrasive Owner’s manual original language – Lavina V20GE 02/2022 6. UNPACKING, HANDLING, TRANSPORTATION AND STORAGE When unpacking the machine, please check that the following accessories are included: -The hose end fitting; -Steel wand; -Floor brush; -Main vacuum hose with cuff to connect to the machine;... -
Page 16: Operating With The Vacuum
® Superabrasive Owner’s manual original language – Lavina V20GE 02/2022 7. OPERATING WITH THE VACUUM IMPORTANT: Before starting the machine, check the service table for daily maintenance. Make sure that the flexible vacuum hose is securely attached to the vacuum pipe union and vacuum cleaner inlet. -
Page 17: Main Filter Cleaning
7.2 MAIN FILTER CLEANING Figure 7.2 The Lavina V20GE uses jet pulse manual filter cleaning. One cycle of filter cleaning takes 10 to 20 seconds, depending on the vacuum’s operator. The filter must be cleaned as the vacuum gauge goes to red or if there’s low suction. If the suction performance is still not improved after a cleaning cycle is applied, the filter must be replaced with new one. -
Page 18: Main Filter Change
® Superabrasive Owner’s manual original language – Lavina V20GE 02/2022 7.3 MAIN FILTER CHANGE Figure 7.3 WARNING: 1. Turn off the engine and wait for the fan impeller to completely stop before opening the machine to change filters. Do not touch the exhaust! It will get very hot even when running the engine for a short time. -
Page 19: Hepa Filter Change
® Superabrasive Owner’s manual original language – Lavina V20GE 02/2022 7.4 HEPA FILTER CHANGE Figure 7.4.1 Figure 7.4.2 Figure 7.4.3 Figure 7.4.4 Figure 7.4... - Page 20 ® Superabrasive Owner’s manual original language – Lavina V20GE 02/2022 WARNING: 1. Turn off the engine and wait for the fan impeller to completely stop before opening the machine to change filters. 2. Do not touch the exhaust as it will get very hot even after running the engine for a short period of time.
-
Page 21: Longopack ® Bag Replacement (Changing Bags)
® Superabrasive Owner’s manual original language – Lavina V20GE 02/2022 7.5 LONGOPACK ® BAG REPLACEMENT (CHANGING BAGS) Figure 7.5.1 Figure 7.5.2 Figure 7.5 The Lavina® V20GE has a LONGOPAC waste system for effective dust storage. This is a 20m long plastic tube that will be divided into plastic bags using the zip ties attached to the machine. -
Page 22: Installing Longopac® Refill Packs
® Superabrasive Owner’s manual original language – Lavina V20GE 02/2022 7.6 INSTALLING LONGOPAC® REFILL PACKS Figure 7.6 When the plastic bag cartridge has reached the end, the plastic bag refill may be installed using the following procedures: 1. At fig. 7.6 pos. 1, you can see the locked position of the LONGOPACK® plastic bag holder and to take it off you should: Lift the holder upwards about 10-15mm to unlock it fig. -
Page 23: Maintenance And Inspection
® Superabrasive Owner’s manual original language – Lavina V20GE 02/2022 1. Place the LONGOPAC® bag refill into the support ring. Ensure that the 2 ends of the refill are directed in an upwards position. Pull the inner end of bag refill down over the inside surface of the bag support ring by making sure that the hook of the holder sticks out from the bag (Fig 7.6.1 and 7.6.2). -
Page 24: Check Daily
Check the flexible vacuum hose and accessories for significant wear or damage. If holes are present, the dust collector’s efficiency will be reduced, and debris will leak into the work environment. IMPORTANT: All major repair work should be performed by Superabrasive or an authorized repair facility. Check the turbine belt tension. -
Page 25: Recommended Oil Change Intervals
® Superabrasive Owner’s manual original language – Lavina V20GE 02/2022 8.4 RECOMMENDED OIL CHANGE INTERVALS Do not exceed the 50-hour oil change interval. Oil changes more frequent than 25 hours will give even longer engine life. In any case, always use 30HD or 10W30 engine oil with all of the following ratings: SF, SG, and CC. -
Page 26: Lavina® V20Ge Electric Circuit Diagram
® Superabrasive Owner’s manual original language – Lavina V20GE 02/2022 8.5 LAVINA® V20GE ELECTRIC CIRCUIT DIAGRAM Figure 8.5... -
Page 27: Filter Chamber Flap Replacement
® Superabrasive Owner’s manual original language – Lavina V20GE 02/2022 8.6 FILTER CHAMBER FLAP REPLACEMENT Figure 8.6 To change the flap follow those 3 steps (fig. 8.6): Unscrew the nuts pos.1; Remove the limiting plate pos.2; Remove the flap pos.3;... -
Page 28: Tensioning And Replacing The Belts
® Superabrasive Owner’s manual original language – Lavina V20GE 02/2022 8.7 TENSIONING AND REPLACING THE BELTS Figure 8.7 Lavina® V20GE has two belts. Changing or tensioning them happens by the following steps: Unscrew the seven bolts that are holding the rear protective cover of the vacuum (fig. 8.7 pos. -
Page 29: Dismounting/Mounting The Engine
® Superabrasive Owner’s manual original language – Lavina V20GE 02/2022 8.8 DISMOUNTING/MOUNTING THE ENGINE To mount or dismount the engine those steps must be done: 1. Remove the rear protective cover, loosen the engine’s base plate and and take off the belts (point 8.7). -
Page 30: Troubleshooting
® Superabrasive Owner’s manual original language – Lavina V20GE 02/2022 9. TROUBLESHOOTING Index of Problems and Solutions Engine When troubles occur, be sure to check the simple causes which at first, may seem too obvious to be considered. For example, a starting problem could be caused by fuel starvation due to an empty propane cylinder or an unopened service valve. -
Page 31: Lavina® Vacuum Adapters And Connections
® Superabrasive Owner’s manual original language – Lavina V20GE 02/2022 10. LAVINA® VACUUM ADAPTERS AND CONNECTIONS... -
Page 32: Lavina® V20Ge Spare Parts
® Superabrasive Owner’s manual original language – Lavina V20GE 02/2022 11. LAVINA® V20GE SPARE PARTS 11.1 GENERAL PARTS Figure 11.1 The strap pos.16 L25GS-25.00.00-1, replaces the old one L25GS-25.00.00. - Page 33 ® Superabrasive Owner’s manual original language – Lavina V20GE 02/2022 LAVINA® V20GE GENERAL PARTS Item No. Description Pcs. Item No. Description Pcs. V25GE30.00.00 Head cover assembly 30301210051 Bolt M6x16 DIN 6921 V20E10.00.00 Filter chamber V20GE02.10.00 HEPA chamber base 30301210072 Bolt M8x16 DIN 6921...
-
Page 34: Vacuum Head Cover
® Superabrasive Owner’s manual original language – Lavina V20GE 02/2022 11.2 VACUUM HEAD COVER Figure 11.2... - Page 35 ® Superabrasive Owner’s manual original language – Lavina V20GE 02/2022 LAVINA® V20GE VACUUM HEAD COVER - V25GE30.00.00 Item No. Description Pcs. Item No. Description Pcs. V25GE33.00.00 Vacuum head body V25GE30.00.02 Top cover 30301240114 Nut M4 DIN 985 30301240095 Nut M8 DIN 6923...
-
Page 36: Main Filter Chamber
® Superabrasive Owner’s manual original language – Lavina V20GE 02/2022 11.3 MAIN FILTER CHAMBER Figure 11.3... -
Page 37: Inlet Valve
® Superabrasive Owner’s manual original language – Lavina V20GE 02/2022 LAVINA® V20GE FILTER CHAMBER - V20E10.00.00 Item No. Description Pcs. Item No. Description Pcs. 30301240103 Nut M6 DIN 985 V25GE11.00.00 Inlet valve assembly V25GE10.00.02 Flap restrictive plate 30301240110 Nut M5 DIN 982 V25GE14.00.00... -
Page 38: Carriage
® Superabrasive Owner’s manual original language – Lavina V20GE 02/2022 11.5 CARRIAGE Figure 11.5 LAVINA® V20GE CARRIAGE - V20GE20.00.00-K Item No. Description Pcs. Item No. Description Pcs. 30301210058 Bolt M8x12 DIN 6921 40401000112 Plastic cap Circlip B25x1.5 A2 30301230209 Screw M8x16 ISO 7380F... -
Page 39: Vacuum Gauge Assembly
® Superabrasive Owner’s manual original language – Lavina V20GE 02/2022 11.6 VACUUM GAUGE ASSEMBLY Figure 11.6 LAVINA® V20GE VACUUM GAUGE ASSEMBLY Item No. Description Pcs. 30313000187 Vacuum gauge 30302000131 Sealing Vacuum gauge base V25GE50.10.00 plate... -
Page 40: Power Unit
® Superabrasive Owner’s manual original language – Lavina V20GE 02/2022 11.7 POWER UNIT Figure 11.7... - Page 41 ® Superabrasive Owner’s manual original language – Lavina V20GE 02/2022 LAVINA® V25GE POWER UNIT Item No. Description Pcs. Item No. Description Pcs. 30310000004 Buffer V20GE42.00.00 Motor base plate V20GE40.00.01 Blower base plate 30301230027 Screw M8x25 DIN 7991 30301240095 Nut M8 DIN 6923...
-
Page 42: Accessories
® Superabrasive Owner’s manual original language – Lavina V20GE 02/2022 12. ACCESSORIES Figure 12.1 Figure 12.2 Figure 12.3 Figure 12.4 Figure 12.6 Figure 12.5 ACCESSORIES Item No. Description Pcs. Fig. 30310000104 Floor Brush combo 18 in L-FB-50 12.1 30316000062 Steel wand L-A-50 12.2... -
Page 43: Disposal
Superabrasive or a local distributor, where a professional disposal complying with the environment laws and directives is guaranteed. 14. MANUFACTURER’S CONTACTRS If you need to contact Superabrasive Inc. with technical support questions, below is the contact information. Address: 9411 Jackson Trail Road, Hoshton GA 30548, USA Email: info@superabrasive.us... -
Page 44: Emmision Control Warranty Statement
As the SORE owner you should however be aware that Superabrasive Inc. may deny your warranty if your SORE or its part has failed due to abuse, neglect, improper maintenance or unapproved modification. - Page 45 If the part fails during the period of warranty coverage, the part will be repaired or replaced by Superabrasive Inc. according to subsection (4) below. Any such part repaired or replaced under warranty will be warranted for the remainder of the period.
- Page 46 The repair or replacement of any warranted part otherwise eligible for warranty coverage may be excluded from such warranty coverage if Superabrasive Inc. demonstrates that the SORE has been abused, neglected, or improperly maintained, and that such abuse, neglect, or improper maintenance was the direct cause of the need for repair or replacement of the part.
