Monnal T75 user manual
Patient category
Infant
≥ 3kg
Note: The patient category can only be changed in Stand-by Mode.
Note: Administrator Configuration (see Administrator configuration on page 75) can be
used to configure the set-points.

4.5 Ventilator configuration

Users may access the configurations at any time by pressing the [Menu] and [Ventilator Configura-
tion] keys.
The following parameters can be accessed:

4.5.1 Language

Monnal T75 offers several languages.
To change the language, press the [Language] keys.
Press the key for the desired language, then press [Back] twice, and [Exit].

4.5.2 Date and time

To change the date or time:
• Click on the display key: use the control wheel to increment or decrement a value.
• Press the control wheel to validate the number and go on to the next parameter.
30
VT range (mL)
20-75
Internal diameter of tubes in patient cir-
cuit (mm)
12 mm
