COBRA
pH pen
MANUAL

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the COBRA pH pen and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for BREWFERM COBRA pH pen

Summary of Contents for BREWFERM COBRA pH pen

  • Page 1 COBRA pH pen MANUAL...

  • Page 2: Material Supplied

    INTRODUCTION Congratulations on your purchase of the Cobra. Please read the manual completely before first use. Keep the manual for fu- ture reference. It is recommended to soak the electrode for at least 30 minutes be- fore use to make the electrode wet. Features: •...
  • Page 3 To install the batteries: 1. Turn off the meter. 2. Losen the battery cover in clockwise di- rection with a coin (DON’T discard the black washer!). 3. Replace the old batteries with 2 new button cells CR2032. 4. Make sure the batteries are in place and the polarity is correct.

  • Page 4: Lcd Display

    IV. LCD DISPLAY • The 1st display shows the measured pH reading. • The 2nd display shows the temp. • Cal = Calibration mode • ATC = Auto Temp. Compensation • = Data hold KEYPAD VI. HOW TO OPERATE 1. Remove the probe storage bottle from meter to expose the electrode.
  • Page 5 Electrode Rotate the storage bottle in counter-clockwise direction and pull out the bottle completely to expose the electrode. 2. Dip the electrode into the test solution. Press “ ⌽ ” to switch on the meter and stir it to get a stable reading. 3.
  • Page 6 5. Turn off the meter by pressing “ ⌽ ” button. 6. Once you have finished the measure- ment, clean the electrode, put back the bottle and store the meter below 50°C. 7. Please see page 9 for the calibration procedures.
  • Page 7 VIII. AUTOMATIC TEMPERATURE COM- PENSATION (ATC) & TEMP. UNIT SET- TING The Cobra is capable of measuring with Automatic Temperature Compensation. “ATC” will show in the middle top of the LCD. Temp. Unit Setting of the Cobra: To select the temp. unit (°C or °F), turn off the meter first.
  • Page 8 The Cobra Calibration: 1. Switch on the meter. 2. Place the electrode into a 7pH buffer solution (afterwards place the elec- trode into a 4pH or a 10pH buffer solu- tion for better accuracy). 3. Press “ ” to enter pH calibration mode.
  • Page 9 buffer, the buffer pH value (4, 7 or 10) will appear on the display in 2 seconds. CAL ATC If the calibration buffer is not 4,7 or 10, but another value, such as 7.01, just press “ ” to change the value. HOLD 6.

  • Page 10: Maintenance

    MAINTENANCE • Always keep the pH glass bulb wet by using the storage bottle to protect and store the electrode. • Always rinse the pH electrode in de-ion- ised water or rinse solution (e.g. tap water) before the next use. •...

  • Page 11: Specifications

    • LCD display “ - - - ” Out of pH range, too acidic/or too alkaline. • “ H ” or “ L ” Out of temp. range, too cold or too hot. • pH value fluctuate quickly This is normal when the electrode is not immersed in water, but exposed to air.

  • Page 12: Warranty

    • Standard USA buffers • Standard NIST buffers • Standard DIN buffers • Battery Life: >100 hrs continuous use XIII. WARRANTY The meter is warranted to be free from defects in material and workmanship for a period of one year from the date of pur- chase.
