- Page 1 AVD0001C01 STAND-ALONE 1 LOOP-THROUGH INPUT TO 8 OUTPUTS WIDEBAND ANALOG VIDEO (HD AND SD) DISTRIBUTOR AND EQUALIZER Version 1.0 Albalá Ingenieros, S.A. 22 May 2015 - © Albalá Ingenieros S.A. - All rights reserved Medea, 4 - 28037 Madrid - Spain...
- Page 2 AVD0001C01...
-
Page 3: Table Of Contents
STAND-ALONE 1 LOOP-THROUGH INPUT TO 8 OUTPUTS WIDEBAND ANALOG VIDEO (HD AND SD) DISTRIBUTOR AND EQUALIZER Version 1.0 1. DESCRIPTION ........................5 1.1. The AVD0001C01 ........................... 5 1.2. Features ............................. 6 1.3. Block diagram ..........................7 2. SPECIFICATIONS ......................... 9 3. - Page 4 AVD0001C01...
-
Page 5: Description
DC restorer with two operating mode (fast and slow) and an equalizer capable of compensating up to 300 meters of Belden 1694A controlled by two potentiometers on the side of the unit. The AVD0001C01 also allows the input to be terminated by 75 Ω when a loop-through connection is not required. -
Page 6: Features
Albalá Ingenieros | Manual AVD0001C01 1.2. Features • Analog video distributor for standard definition and high definition signals. • Provides one loop-through input and four outputs. • Loop-through input can be configured to be internally loaded. • Designed for distribution of both standard definition (black burst) and high definition (tri-level sync) synchronization signals. -
Page 7: Block Diagram
Albalá Ingenieros | Manual AVD0001C01 1.3. Block diagram... - Page 8 Albalá Ingenieros | Manual AVD0001C01 AVD0001C01...
-
Page 9: Specifications
Albalá Ingenieros | Manual AVD0001C01 2. SPECIFICATIONS Analog video signal input Connector Impedance 75 Ω or Hiz Return loss >40 dB up to 10 MHz Return loss >30 dB up to 30 MHz Type Passive Loop-Through Signal format According to ITU-R BT.470-6, ITU-R BT.709-7, ITU-R BT.1847,... - Page 10 Albalá Ingenieros | Manual AVD0001C01 Differential gain 0.1 % Differential phase 0.1 ° Tilt <0.2 % Chrominance to luminance delay <1 ns S/N ratio unweigthed with ref=0.7 V >70 dB RMS from 40 Hz to 6 MHz Hum rejection >20 dB...
-
Page 11: Installation
3.1. Initial inspection The AVD0001C01 is a desktop unit and does not require installation in a rack or similar housing. However, it has threaded fasteners for M4 screws at its base for attachment to a panel or other surfaces if necessary. -
Page 12: Attachment
The power supply's negative output is connected to the metal case. • The AVD0001C01 is designed to be operated indoors and should not be used outside. It should also not be used in explosive, corrosive or radioactive environments or in applications that could endanger the lives of people or animals. -
Page 13: Environmental Considerations
The equipment is supplied with a suitable wall power supply. This power supply can provide power to a single AVD0001C01. It is possible to connect several devices to the same power supply as long as it is able to supply the necessary current. Read the following information carefully before connecting the AVD0001C01 to a power supply other than the one delivered with the equipment. - Page 14 The AVD0001C01 provides a switch that connects a termination to the input without requiring a load to be connected to the loop-through output. The switch should be set to the position labeled 75 ohm.
-
Page 15: Operation
Upper panel of the AVD0001C01 The upper panel contains two LEDs. POWER ON: Green. This LED lights up when the AVD0001C01 is connected to electrical power. 3G. White. This LED indicates that the detected format of the analog video... -
Page 16: Functional Description
LED lights up the the distributor can function even though it is not indicating the specific signal format. 4.2. Functional description The AVD0001C01 is composed of three blocks: a DC restorer, an equalizer and the output amplifiers that distribute the signal. The first two blocks are described in more detail in the following. -
Page 17: Dc Restorer
The equalizer is in charge of modifying the frequency response of the distributor to compensate for the attenuation incurred as the video signal is transported over coaxial cable to the input of the AVD0001C01. This is done only once, as the module has a single input. -
Page 18: Module Remote Control And Supervision
0 dB. Under normal conditions when the signal has not been attenuated by the cable the gain does not require adjustment as the equalizer operates at both low and high frequencies. 4.3. Module remote control and supervision The AVD0001C01 CANNOT be remotely controlled or supervised. -
Page 19: Glossary
Albalá Ingenieros | Manual AVD0001C01 5. GLOSSARY Bayonet Neill-Concelman connector. An abbreviation for SDTV (Standard Definition Television). Serial Digital Interface. A standard used for the transmission of uncompressed video signals that can also include audio and time code signals. Trilevel sync... - Page 20 Albalá Ingenieros | Manual AVD0001C01 AVD0001C01...
-
Page 21: Regulations
Albalá Ingenieros | Manual AVD0001C01 6. REGULATIONS EN 60950-1 (2003) Information Technology Equipment - Safety- Part 1: General Requirements See also: EN 60950-1 A11, EN 60950-1 Corrigendum ITU-R BT.1847 (2009) 1280 x 720, 16:9 progressively-captured image format for production and international programme exchange in the 50 Hz environment. - Page 22 Albalá Ingenieros | Manual AVD0001C01 AVD0001C01...
-
Page 23: Versions
Albalá Ingenieros | Manual AVD0001C01 7. VERSIONS Ver. Date Description 20-01-2015 Preliminary Version 22-05-2015 First version... - Page 24 Albalá Ingenieros, S.A. Medea, 4 - 28037 Madrid Spain +34 913274453 www.albalaing.com info@albalaing.com...
