Operating Instructions
& Safety Manual
Permanent
Magnet Lifter
Manual
Plate Capacities
0.1 through to 6 tonnes
Note: Operator must read and fully
understand the operating instructions
before using this product.
www.gtlifting.co.uk
George Taylor & Company Lifting Gear (Midlands) Ltd.
Unit 4, Fryers Road, Walsall WS2 7LZ UK
T
+44 (0)1922 490220
F
+44 (0)1922 490229
E
office@gtlifting.co.uk
Advertisement
Table of Contents
Related Manuals for GT PML-1
Summary of Contents for GT PML-1
- Page 1 Operating Instructions & Safety Manual Permanent Magnet Lifter Manual Plate Capacities 0.1 through to 6 tonnes Note: Operator must read and fully understand the operating instructions before using this product. www.gtlifting.co.uk George Taylor & Company Lifting Gear (Midlands) Ltd. Unit 4, Fryers Road, Walsall WS2 7LZ UK +44 (0)1922 490220 +44 (0)1922 490229 office@gtlifting.co.uk...
-
Page 2: General Information
General Information APPLICATION & FEATURE CAUTION Model PML (Permanent Magnetic Lifter) is mainly used to fasten or hold steel/iron workpieces during lifting or Indicates a potentially hazardous situation that, if not handling operations. It is capable of holding steel/iron avoided, may result in minor or moderate injury. It may plate and cylindrical steel. -
Page 3: Safety Information
Safety Information OPERATION MAIN FACTORS FOR SAFE USE WARNING WARNING Before any use or operation, you should clean the surface THE THICKNESS AND SURFACE OF THE WORKPIECE IS of the workpiece being lifted and ensure that the bottom of CRITICAL the lifting magnet is free of any dirt or debris;... - Page 4 SAFETY CAPACITY CURVE Effective percentage of rated capacity Thickness PML-60 PML-15 PML-6 PML-2 (mm) PML-30 PML-20 PML-3 PML-50 PML-10 PML-5 PML-1 100% 100% 100% 100% 100% 100% 100% Safety Capacity Data for Thickness (Reference)
-
Page 5: Maintenance And Specifications
If its main body shows any visible signs of damage or any of the moving parts are damaged in any way, then the unit should be removed from service and destroyed to avoid any possibility of future use. Part No. Plate Cylindrical Tear-off Weight Capacity Capacity Force kgs PML-1 PML-3 1,050 PML-6 2,100 PML-10 1,000 3,500 PML-20 2,000... - Page 6 Spare Parts Diagram & List...
