IPS CR 25 A Operating Instructions Manual

Hand tool for steel strapping

Hide thumbs

Table Of Contents

Table of Contents

Quick Links

Download this manual

DEUTSCH

ENGLISH

FRANÇAIS

ITALIANO

Ab Serie-Nr. 2500

From serie no 2500

A partir du no de série 2500

A partire dal no. di serie 2500

01.05/WE

BETRIEBSANLEITUNG UND SICHERHEITSVORSCHRIFTEN

OPERA

OPERATING

OPERA

TING

TING AND SAFETY INSTR

AND SAFETY INSTR

AND SAFETY INSTRUCTIONS

AND SAFETY INSTR

MODE D'EMPLOI ET DE SÉCURITÉ

ISTRUZIONI PER L'USO E DI SICUREZZA

CR 25 A

Handgerät zum Umreifen mit Stahlband

Hand tool for steel strapping

Appareil pour le cerclage par feuillard d'acier

Apparecchio per reggiare con reggetta d'acciaio

UCTIONS

ORGAPACK

Table of Contents

Need help?

Do you have a question about the CR 25 A and is the answer not in the manual?

Questions and answers

Summary of Contents for IPS CR 25 A

Page 1 ISTRUZIONI PER L‘USO E DI SICUREZZA ISTRUZIONI PER L‘USO E DI SICUREZZA ISTRUZIONI PER L‘USO E DI SICUREZZA ISTRUZIONI PER L‘USO E DI SICUREZZA ITALIANO CR 25 A Handgerät zum Umreifen mit Stahlband Ab Serie-Nr. 2500 Hand tool for steel strapping From serie no 2500 Appareil pour le cerclage par feuillard d'acier A partir du no de série 2500...
Page 2: Table Of Contents
CSP 611 DECLARATION OF AGREEMENT We take sole responsibility for declaring that the CH-8953 Dietikon, February 2002 tool CR 25 A, to which this declaration refers, is in full compliance with the current requirements of the Manager Manager guidelines laid down by the council on 22th June Sales &...
Page 3: General Information
ORGAPACK CR 25 A GENERAL INFORMATION These operating instructions are intended to simplify familiarisation with the strapping tool and the possibili- CAUTION! ties of application for the intended purpose. The oper- ating instructions contain important information con- Used where there is cerning the safe, proper and efficient use of the strap- danger to life and health.
Page 4: Safety Instructions
ORGAPACK CR 25 A SAFETY INSTRUCTIONS Do not use a bottled Inform yourself! Read the operating air or gas source! instructions carefully. Do not operate tis tool by jklsfjklsdj lksdfjkl jkljsdllkjjkljsd fkljjklkjkljsdafj usining a bottled air or asdfjklkjjkljklj ksldafkjkljkl jkljklkljsdafjlkj...
Page 5: Description
ORGAPACK CR 25 A DESCRIPTION 4.1 DESIGN 1 Compressed air connection 2 Yellow button (Sealing) 3 Green button (Tensioning) 4 Handle 5 Pressure reduzing valve 6 Compressed air motor 7 Tension wheel and tension plug 8 Base plate 9 Sealing jaws...
Page 6: Initial Operation
The oil mist lubricator should supply sufficient oil. The length of the hose between the CR 25 A and the main- tenance unit should not exceed 5 m (15 ft). The internal diameter of the pipe should be at least 10 mm “).
Page 7: Operating Instructions
ORGAPACK CR 25 A OPERATING INSTUCTIONS 6.1 OPERATING THE TOOL – Draw the strap from the dispenser, slide the strap through the seal (4/1) and wind strap around the package. – Push the strap start a second time through the seal.
Page 8 ORGAPACK CR 25 A Tensioning – Press the green button completely down with the thumb of the right hand. Release green button. The strap is tensioned until the air motor stops. The tensioning force can be infinitely adjusted (see chapter 7.1).
Page 9: Preventive And Corrective Maintenance
ORGAPACK CR 25 A PREVENTIVE AND CORRECTIVE MAINTENANCE 7.1 ADJUSTING TENSIONING FORCE/ TENSIONING SPEED – Set air pressure at pressure reducing valve of maintenance unit to 4–6 bar. – With a screwdriver adjust pressure reducing valve (9/1) of air motor, so that the motor stops when the required tension is reached.
Page 10: Replacing Cutting Knife
ORGAPACK CR 25 A 7.4 REPLACING CUTTING KNIFE Removal – Remove tension wheel (see chapter 7.3). – Remove gear housing (12/9) including air motor and shaft. – With screwdriver loosen special screw (12/1). – Remove shaft (12/2) and compression spring (12/3).
Page 11: Parts List
ORGAPACK CR 25 A PARTS LIST 1174.200.100/11 When ordering please indicate part number and quantity Explosion drawing see page 28 Recommended spare parts Pos. Part no Part name Quantity Pos. Part no Part name Quantity 1 1174.200.115 Cylinder 46 1820.030.415 Bolt 47 1820.030.414...
Page 12 ORGAPACK CR 25 A Pos. Part no Pos. Part no Part name Part name Quantity Quantity Pos. Part no Part name Quantity 87 1933.815.120 Needle bushing, ø 15/21 x 12 88 1928.615.213 Gasket, ø 15/21 x 3 89 1820.030.411 Tension shaft 90 1173.200.063...
Page 14: Parts List Compressed Air Motor
ORGAPACK CR 25 A PARTS LIST COMPRESSED AIR MOTOR 1894.332.000/2 When ordering please indicate part number and quantity Explosion drawing see page 30 Pos. Part no Part name Quantity 1 1894.332.011 End plate 2 1894.332.010 Gear housing (Rear side) 3 1894.332.013 Silencer 4 1894.332.033...
