Summary of Contents for Shengmilo NOKEE-U

  • Page 1 KING-METER LCD Display Users Manual...

  • Page 2: Table Of Contents

    Content Product Name and Model........................3 Appearance and Size...........................3 Function Summary..........................4 ◆Function Summary..........................4 ◆Button Definition..........................4 ◆Functional Area Distribution......................5 General Operation..........................6 ◆Switching the E-bike System On/Off....................6 ◆Display Interface..........................6 ◆Switching Push-assistance Mode On/Off..................7 ◆Turn on/off headlights........................7 ◆Battery Indicator..........................8 ◆Error Code Indication........................8 General Settings..........................9 ◆Trip Distance Clearance........................

  • Page 3: Product Name And Model

    Product Name and Model Intelligent LCD display for E-bike; model: NOKEE-U. Appearance and Size Display appearance and dimension figure (unit: mm)

  • Page 4: Function Summary

    Most of the buttons are made of PC material, the button part is made of soft silicone material, and the whole body is black. There are three buttons on the NOKEE-U button. Including the power button, "plus" button, and "minus" button. In the following instructions, the button is replaced by the text [MODE];...

  • Page 5: Functional Area Distribution

    ◆ Functional Area Distribution Battery Indicator Error Code Indication Function List Speed Indicator Speed Unit Push-assistance Level Indication Area The Lighting Indication Range/Time Unit Text Indication Function List...

  • Page 6: General Operation

    General Operation ◆Switching the E-bike System On/Off Briefly press the [MODE] button to switch on the E-bike system, To hold the power button for 2 s again, the E-bike system will be switched off. When switching off the E-bike system, the leakage current is less than 1 uA. ■When parking the E-bike for more than 10 minutes, the E-bike system switches off automatically.

  • Page 7: Switching Push-Assistance Mode On/Off

    ◆Switching Push-assistance Mode On/Off To activate the push-assistance function, hold the [DOWN] button always. The E-bike’s drive is activated at a uniform speed of 6 Km/h. And “WALK” shows on the screen. The push-assistance function is switched off as soon as you release the [DOWN] button on the operating unit.

  • Page 8: Battery Indicator

    ◆Battery indicator There are 5 long battery bars from left to right, representing the capacity of the battery. Each grid symbol of the battery pack has 2 short battery bars equivalent to approximately 20% capacity. When the battery is low, the battery box will blink at 1 Hz to indicate that the battery needs to be charged immediately.

  • Page 9: General Settings

    General Settings To access the general settings menu, hold both the [UP] button and the [DOWN] button for 2 s. ■All the Settings are operated in the case of parking the E-bike. ◆Trip Distance Clearance represents the trip distance clearance setting. TRIP A/ TRIP B To clear the trip distance, press the [MODE] button or the [DOWN] button until the single trip distance is zero.

  • Page 10: General Parameter Settings

    General Parameter Settings access the general parameter Settings interface, hold both the [UP] and the [DOWN] button for 2 s and then hold both the [DOWN] and the [MODE] button for 2 s again. ◆Wheel Diameter Settings Wheel diameter settings electable values include 16, 18, 20, 22, 24, 26, 700C, and 28. To change basic settings, press the [UP] or the [DOWN] button to increase or decrease until the desired value is displayed.

  • Page 11: Personalized Parameter Settings

    Personalized Parameter Settings Personalized Parameter Settings can match a variety of requirements in use. There are 8 settings items, such as Battery Power Bar Settings, Power Assistant Level Settings, Over current Cut Settings, Power Assistant Sensor Settings, Speed Sensor Settings, Throttle Function Settings, System Settings, and Power-on Password Settings.

  • Page 12: Assistance Level Settings (Optional)

    ◆Assistance Level Settings (optional) Assistance Level Option In assistance level settings, there are 8 modes to select：0-3, 1-3, 0-5, 1-5, 0-7, 1-7, 0-9, and 1-9. The default value is 0-5. To change the mode of assistance level, press the [UP] or the [DOWN] button to choose the desired mode, and then press the [MODE] button to confirm, then access the PAS ratio settings page automatically.

  • Page 13: Controller Over-Current Cut Settings (Optional)

    ◆Controller Over-current Cut Settings (optional) CUR represents controller over-current cut settings. CUR value can be changed from 7.0A to 18.0A. The default value is 15A. To change basic settings, press the [UP] or the [DOWN] button to increase or decrease the value of the current.

  • Page 14: The Sensitivity Of Pas Settings

    The Sensitivity of PAS Settings SCN represents the sensitivity of PAS settings. The sensitivity value is “2” to “9”. “2” is the strongest, and “9” is the weakest. The default value is “2”. To change the sensitivity of PAS settings, press the [UP] or the [DOWN] button to select the sensitivity value.

  • Page 15: Speed Sensor (Optional)

    ◆Speed Sensor (optional) SPS represents speed sensor settings. The default value is 1 To change speed sensor settings, press the [UP] or the [DOWN] button to select the quantity of magnet head on the wheel spoke (the range is from 1 to 9). To store a changed setting, hold the [MODE] button and then return to the previous menu.

  • Page 16: Throttle Pas Enable/Disable

    Throttle -PAS Enable/Disable HF represents the "throttle-PAS" setting. HF-y means throttle speed is limited by current assist level while HF-n means throttle speed is not limited by current pedal assist level. The default value is "n". If you choose "y", the maximum speed can only be the highest speed powered by current pedal assist level when you twist the throttle.

  • Page 17: Button Push-Assistance Enable/Disable

    ◆Button Push-assistance Enable/Disable PUS represents button push-assistance settings. Y represents button push is enabled, and N represents button push is disabled. The default value is Y. To change button push-assistance settings, press the [UP] or the [DOWN] button to choose Y or To store a changed setting, press the [MODE] button and then access PAS speed settings.

  • Page 18: Slowly Start Up Settings

    ◆Slowly Start-Up Settings SSP represents a slow start-up. The range is “1-4”, and “4” is the slowest. The default value is “1”. To slowly start up settings, press the [UP] or the [DOWN] button to select the desired value. To return to the previous menu, hold the [MODE] button for 2 s. Interface of Slowly Settings Up ◆Power-on Password Settings “P3”...

  • Page 19: Operation Cautions

    Operation Cautions Be careful of safe use. Don’t attempt to release the connector when the battery is on power. ● Try to avoid hitting. ● Do not modify system parameters to avoid parameters disorder. ● Make the display repaired when an error code appears. Attached list 1：Error code definition Error Code Definition...
