CMD Cableway Installation, Use And Care Manual

Cableway
Cableway shown fully assembled for illustration purposes. Cableway is supplied without
fixings. Ensure to use fixings suitable for the intended furniture. Consult with your furniture
supplier if necessary.

Installing the top fixing bracket

Use the top fixing Use 2x suitable screws
bracket to mark the to secure the top fixing
location of the fixing bracket to the underside
holes. of the desk.

Installing the base plate

Use a tape measure or Fix the base plate to the
similar to align the base floor with 2x suitable
plate with the top fixing screws if required.
bracket.
Part No: 134281 Issue No: 001
Ensure the bracket
is secure but do not
overtighten.
Ensure the base plate
is secure in place but
do not overtighten the
fixings.
Installation, user and care guide
Contents
x1 x1

Installing the connecting blocks

Measure the distance between the top fixing bracket and the base plate. Note
the Cableway is suitable for a maximum desk height of 745mm.
Adjust the length of the Offer up the top end of
connecting blocks to the connecting blocks to
suit the desk height by the top fixing bracket as
adding/removing blocks. shown.
'CLICK'
Offer up the bottom Fully push the block
end of the connecting onto the base plate
blocks to the base plate until it clicks into place.
as shown. Check it is secure.
x1
'CLICK'
Push the block into the
top fixing bracket until it
clicks into place. Check
it is secure.
The Cableway is now
installed and ready to
accept cables.
