eInfochips iMX8XML User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Version
Status
Date
Confidentiality Notice
Copyright (c) 2019 eInfochips. - All rights reserved
This document is authored by eInfochips and is eInfochips intellectual property, including the copyrights in all
countries in the world. This document is provided under a license to use only with all other rights, including ownership
rights, being retained by eInfochips. This file may not be distributed, copied, or reproduced in any manner, electronic
or otherwise, without the express written consent of eInfochips
ML Demos User Manual
iMX8XML Reference Design
0.2
Draft
14-Oct-2019

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the iMX8XML and is the answer not in the manual?

Questions and answers

Related Manuals for eInfochips iMX8XML

Summary of Contents for eInfochips iMX8XML

  • Page 1 This document is provided under a license to use only with all other rights, including ownership rights, being retained by eInfochips. This file may not be distributed, copied, or reproduced in any manner, electronic or otherwise, without the express written consent of eInfochips...

  • Page 2: Table Of Contents

    HDMI ..............................51 Camera ............................. 51 ML Demos references ..........................53 Figures Figure 1: iMX8XML RD ..........................5 Figure 2: Hardware Setup.......................... 6 Figure 3: SD card partitions overview after flashing firmware ............. 8 Figure 4: Create New EXT4 partition ....................... 9 Figure 5: SD card partition after creating new one ................
  • Page 3 Figure 9: Run Object Detection Demo ....................17 Figure 10: Setup for object detection ..................... 19 Figure 11: Sample Input Image for Object Detection ................20 Figure 12: Sample Object detection output ..................20 Figure 13: Face Recognition Demo Testing ..................22 Figure 14: Face Recognition Output ......................

  • Page 4: Document Details

    DOCUMENT DETAILS Document History Author Reviewer Approver Date Date Date Version Name (DD-MM- Name (DD-MM- Name (DD-MM- YYYY) YYYY) YYYY) Anil Patel 19-Apr-2019 Prajose 19-Apr- Bhavin 19-Apr- John 2019 Patel 2019 Anil Patel 15-Oct-2019 Prajose 15-Oct- Bhavin 15-Oct- John 2019 Patel 2019 Version...

  • Page 5: Introduction

    Demos to run on iMX8ML_RD AIML firmware. About the System • This system contains iMX8X reference design with multiple interfaces. This is used for Machine learning experience. Figure 1: iMX8XML RD Pre-requisite • x86 host system having Linux Ubuntu 16.04 LTS installed •...

  • Page 6: Figure 2: Hardware Setup

    Figure 2: Hardware Setup...

  • Page 7: Ml Demos Background

    ML DEMOS BACKGROUND To demonstrate board’s capabilities for Machine Learning demos, we implemented few Audio and video related ML demos. These demos mainly depend on OpenCV, Tensorflow, Caffe, ARM NN and some python packages. All video ML demos required video source (webcam or D3 Mezzanine based OV5640 camera) to capture live stream and perform some action on it.

  • Page 8: Figure 3: Sd Card Partitions Overview After Flashing Firmware

    Figure 3: SD card partitions overview after flashing firmware • As shown in above figure, in SD card partitions, we can see unused partition (10 GB) at last. We can utilized it. • Now Click on “+” sign to create new partition. •...

  • Page 9: Figure 4: Create New Ext4 Partition

    Figure 4: Create New EXT4 partition • It will take few times and create partition and we can able to mount that partition. (See beow Figure for reference.)

  • Page 10: Figure 5: Sd Card Partition After Creating New One

    Figure 5: SD card partition after creating new one • Copy ARROW DEMOS on this partition. If you are unable to do that then kindly unmount and mount again. • After successful copy, boot our AIML board with this sdcard. •...

  • Page 11: Run Setup

    Run Setup All required Python packages for ML demos are already installed in AIML firmware image. Our demos run using Python3 so we have added package for Python3 and not for python. We have also provide support for Python and Python3 PIP Package. Through which we can add or remove any python package and remove dependencies for rebuilding firmware image each times.

  • Page 12: Running Ml Demos

    RUNNING ML DEMOS To run ML Demos we have created run_ml_demo.sh shell script. This script ask for user preferences like demo type, camera types, camera node entry, desired MIC etc and based on that run ML demos. In this section, we discuss how to run each demo. Details description of Demo is in next section. 1.
  • Page 13 Run /run/media/mmcblk1p3/ARROW_DEMOS/run_ml_demos.sh script and select option 1. See below full log to run demo, where user input is in BOLD RED fonts. # sh /run/media/mmcblk1p3/ARROW_DEMOS/run_ml_demos.sh ######## Welcome to ML Demos [AI Corowd Count/Object detection/Face Recognition/Speech Recognition/Arm NN] ########## Prerequisite: Have you run <setup_ml_demo.sh>? Press: (y/n) ****** Script Started ******* Setup is already completed.
  • Page 14 D3 Mazzanine Camera is used for demo [ 130.962684] random: crng init done [ 130.966100] random: 7 urandom warning(s) missed due to ratelimiting ImportError: No module named 'numpy.core._multiarray_umath' ImportError: No module named 'numpy.core._multiarray_umath' NN> using tensorflow version: 1.3999999999999999 NN> using CPU-only (NO CUDA) with tensorflow ##### LOADING TENSORFLOW GRAPH ##### 160x120 used for live mode as these typically are close ##### 640x480 used for pre-captured large images of crowd as these are far...

  • Page 15: Figure 7: Crowd Count Pre-Captured Mode

    Figure 7: Crowd Count Pre-Captured Mode Figure 8: Crowd Count Live Mode...

  • Page 16: Object Detection Demo

    2. Object Detection Demo In this Demo, we detect few objects like aeroplane, bicycle, bus, car, cat, cow, dog, horse, motorbike, person, sheep, train (objects necessary for self-driving cars.) Here we have two version of Object detection. Both demo use same caffe based object detection model so accuracy remain same for both the demos.

  • Page 17: Figure 9: Run Object Detection Demo

    Figure 9: Run Object Detection Demo See below full log to run demo, where user input is in BOLD RED fonts. # sh /run/media/mmcblk1p3/ARROW_DEMOS/run_ml_demos.sh ######## Welcome to ML Demos [AI Corowd Count/Object detection/Face Recognition/Speech Recognition/Arm NN] ######### Prerequisite: Have you run <setup_ml_demo.sh>? Press: (y/n) Choose the option from following Press 1: AI Crowd Count...
  • Page 18 Welcome to object Detection This model detect aeroplane, bicycle, bus, car, cat, cow, dog, horse, motorbike, person, sheep, train (objects necess ary for self-driving) Please choose type of camera used in demo Press 1: For USB Web Cam Press 2: For D3 Mazzanine Camera USB Web Camera is used for demo Enter Camera device node entry e.g.

  • Page 19: Figure 10: Setup For Object Detection

    Using Wayland-EGL Using the 'xdg-shell-v6' shell integration Total Elapsed time: 15.52 Approx. FPS: 0.90 Exiting Demo... Now in this demo, we need to provide object in front of camera to detect it. Person is the best real-time object for detection. Most of the object is easily available outside environment. However, to test model we don’t need actual object.

  • Page 20: Figure 11: Sample Input Image For Object Detection

    Figure 11: Sample Input Image for Object Detection Figure 12: Sample Object detection output As shown in above figure, in output image, dog is not detected, as it is not in good angle and exposure. Due to that model detect that with very low percentage and we ignore that due to low confidence.

  • Page 21: Face Recognition Demo

    3. Face Recognition Demo In face recognition demo, we first detect face from given image or video frame. After detecting face, we apply our pre-trained model on it and try to recognize face. In this demo, we have used few ML techniques and OpenCV face recognition models. We also used “face recognition”...

  • Page 22: Figure 13: Face Recognition Demo Testing

    If user want to re-train model again without capturing new training data, then we must not provide label and simply run training process. Pre-requisite: • Webcam or D3 Mezzanine camera • USB Mouse • USB Keyboard • Use USB Hub (if have USB webcam) because we have only two USB ports •...
  • Page 23 ****** Script Started ******* Setup is already completed. No need to do anything. Exiting... Choose the option from following Press 1: AI Crowd Count Press 2: Object Detection Press 3: Face Recognition Select: (1/2/3/4/5) Welcome to Face Recognition Demo This is a demo application using Python modules to be run on embedded devices for recognition of faces.
  • Page 24 Because we randomly sample only few frames from camera and applied same face recognition on the rest of frames. As we only sample few frames, here output is slow. You can get correct result around after 2- 3 sec. Press 2: For Slow Face Recognition. Here we applied face recognition on each camera frame and display output.

  • Page 25: Figure 14: Face Recognition Output

    Figure 14: Face Recognition Output If user want to re-train model with new person/label then he/she need to select train model with label as shown in below logs: Please choose mode of operation for demo Press 1: Test Model Press 2: Train Model Face recognition Training ...
  • Page 26 (python3:3993): GStreamer-CRITICAL **: gst_element_get_state: assertion 'GST_IS_ELEMENT (element)' failed Using Wayland-EGL Using the 'xdg-shell-v6' shell integration detected faces - 0 detected faces - 0 detected faces - 0 [(125, 440, 254, 311)] detected faces - 1 new training image anil_0_20190409-143240.png saved! detected faces - 0 detected faces - 0 [(36, 366, 222, 180)]...
  • Page 27 detected faces - 0 detected faces - 0 pressed, Exiting... <---User Press “q” here from keyboard attached to board Total Elapsed time: 31.82 sec Directory anil removed Quantifying faces from training dataset... Processing Image : training_data/unknown/00000022.JPG Processing Image : training_data/unknown/00000034.JPG Processing Image : training_data/unknown/ellie_sattler.jpg Processing Image : training_data/unknown/00000009.jpg Processing Image : training_data/unknown/00000004.jpg...

  • Page 28: Speech Recognition Demo

    4. Speech Recognition Demo This audio demo is use case of on-board DMIC. Here we have two demos for testing MIC. In First Demo, we use our custom trained model for few selected keywords like “yes no up down left right on off stop go”. In this demo we got around 80-85% accuracy as it is bit hard for audio to identify correct keyword compare to image where we easily get accuracy more than 90% by CNN (convolutional neural network).
  • Page 29 Press 2: Object Detection Press 3: Face Recognition Press 4: Speech Recognition Press 5: ARM NN Demo Select: (1/2/3/4/5) Welcome to Speech Recognition Demo This is a demo application using Python modules and Tensorflow to be run on embedded devices for recognition of spoken words.
  • Page 30 ALSA lib ../../alsa-lib-1.1.5/src/confmisc.c:1281:(snd_func_refer) Unable to find definition 'cards.imx- spdif.pcm.front.0:CARD=0' ALSA lib ../../alsa-lib-1.1.5/src/conf.c:4554:(_snd_config_evaluate) function snd_func_refer returned error: No such file or directory ALSA lib ../../alsa-lib-1.1.5/src/conf.c:5033:(snd_config_expand) Evaluate error: No such file or directory ALSA lib ../../../alsa-lib-1.1.5/src/pcm/pcm.c:2552:(snd_pcm_open_noupdate) Unknown PCM front ALSA lib ../../../alsa-lib-1.1.5/src/pcm/pcm.c:2552:(snd_pcm_open_noupdate) Unknown PCM cards.pcm.rear ALSA lib ../../../alsa-lib-1.1.5/src/pcm/pcm.c:2552:(snd_pcm_open_noupdate) Unknown PCM cards.pcm.center_lfe...
  • Page 31 ALSA lib ../../../alsa-lib-1.1.5/src/pcm/pcm.c:2552:(snd_pcm_open_noupdate) Unknown PCM surround40 ALSA lib ../../alsa-lib-1.1.5/src/confmisc.c:1281:(snd_func_refer) Unable to find definition 'cards.imx- spdif.pcm.surround51.0:CARD=0' ALSA lib ../../alsa-lib-1.1.5/src/conf.c:4554:(_snd_config_evaluate) function snd_func_refer returned error: No such file or directory ALSA lib ../../alsa-lib-1.1.5/src/conf.c:5033:(snd_config_expand) Evaluate error: No such file or directory ALSA lib ../../../alsa-lib-1.1.5/src/pcm/pcm.c:2552:(snd_pcm_open_noupdate) Unknown PCM surround41 ALSA lib ../../alsa-lib-1.1.5/src/confmisc.c:1281:(snd_func_refer) Unable to find definition 'cards.imx- spdif.pcm.surround51.0:CARD=0'...
  • Page 32 ALSA lib ../../alsa-lib-1.1.5/src/confmisc.c:1281:(snd_func_refer) Unable to find definition 'cards.imx- spdif.pcm.iec958.0:CARD=0,AES0=4,AES1=130,AES2=0,AES3=2' ALSA lib ../../alsa-lib-1.1.5/src/conf.c:4554:(_snd_config_evaluate) function snd_func_refer returned error: No such file or directory ALSA lib ../../alsa-lib-1.1.5/src/conf.c:5033:(snd_config_expand) Evaluate error: No such file or directory ALSA lib ../../../alsa-lib-1.1.5/src/pcm/pcm.c:2552:(snd_pcm_open_noupdate) Unknown PCM iec958 ALSA lib ../../alsa-lib-1.1.5/src/confmisc.c:1281:(snd_func_refer) Unable to find definition 'cards.imx- spdif.pcm.iec958.0:CARD=0,AES0=4,AES1=130,AES2=0,AES3=2' ALSA lib ../../alsa-lib-1.1.5/src/conf.c:4554:(_snd_config_evaluate) function snd_func_refer returned error: No such file or directory...
  • Page 33 ALSA lib ../../alsa-lib-1.1.5/src/conf.c:4554:(_snd_config_evaluate) function snd_func_refer returned error: No such file or directory ALSA lib ../../alsa-lib-1.1.5/src/conf.c:5022:(snd_config_expand) Args evaluate error: No such file or directory ALSA lib ../../../alsa-lib-1.1.5/src/pcm/pcm.c:2552:(snd_pcm_open_noupdate) Unknown PCM bluealsa ALSA lib ../../alsa-lib-1.1.5/src/confmisc.c:1281:(snd_func_refer) Unable to find definition 'defaults.bluealsa.device' ALSA lib ../../alsa-lib-1.1.5/src/conf.c:4554:(_snd_config_evaluate) function snd_func_refer returned error: No such file or directory ALSA lib ../../alsa-lib-1.1.5/src/conf.c:5022:(snd_config_expand) Args evaluate error: No such file or directory...
  • Page 34 ALSA lib ../../../alsa-lib-1.1.5/src/pcm/pcm_dsnoop.c:575:(snd_pcm_dsnoop_open) The dsnoop plugin supports only capture stream ALSA lib ../../../alsa-lib-1.1.5/src/pcm/pcm_dsnoop.c:575:(snd_pcm_dsnoop_open) The dsnoop plugin supports only capture stream [16848.392805] fsl-esai-dai 59010000.esai: ASoC: can't set 59010000.esai hw params: -22 ALSA lib ../../../alsa-lib-1.1.5/src/pcm/pcm_direct.c:1271:(snd1_pcm_direct_initialize_slave) unable to inst[a1l6l8 4 8w. 4p0a9r9a0m1s] fAsLlS-Ae slaiib- d.a.i/ .5.9/.01.0/0a0l0s.ae-slaiib:- 1t.1h.e 5r/astrico/ picsm /opuctm_ dofs nroaonpg.ec :(614 9~:_(s16n)d pcm_dsnoop_open) unable to initialize slave ALSA lib ../../../alsa-lib-1.1.5/src/pcm/pcm_dsnoop.c:575:(snd_pcm_dsnoop_open) The dsnoop...
  • Page 35 dmix_48000 : 4 dmix_44100 : 5 dmix_32000 : 6 dmix_16000 : 7 dmix_8000 : 8 dsnoop_48000 : 9 dsnoop_32000 : 10 dsnoop_16000 : 11 asymed : 12 dsp0 : 13 dmix : 14 default : 15 Which input (audio) device you want? Please provide index value (in number) : You selected audio device : Expression 'alsa_snd_pcm_hw_params_set_buffer_size_near( pcm, hwParams, &alsaBufferFrames )' failed in '../portaudio/src/hostapi/alsa/pa_linux_alsa.c', line: 922...
  • Page 36 stop (prediction score = 22.94) go (prediction score = 48.45) left (prediction score = 44.40) yes (prediction score = 26.72) right (prediction score = 97.46) down (prediction score = 27.49) stop (prediction score = 20.01) yes (prediction score = 93.53) no (prediction score = 50.74) go (prediction score = 51.61) up (prediction score = 51.55)
  • Page 37 ^CExiting Demo... Exiting Demo... root@imx8qxpaiml:~# Here As we seen in above output, we got lots of error and warning regarding ALSA Lib. This is because ALSA lib try to configure capture only device to playback and vice versa. This errors want affect our actual behavior so kindly ignore that. Also, we need to select Audio device 1 which is “imx-audio-sph0645: - (hw:1,0)”...
  • Page 38 Speech Recognition thinks you said : Anil open Wikipedia Main Keyword detected... Opening WikiPedia in browser... Speech Recognition thinks you said : Anil Main Keyword detected... Speech Recognition thinks you said : Anil open YouTube Main Keyword detected... Opening YouTube in browser... Speech Recognition thinks you said : Anil open YouTube search latest song Main Keyword detected...

  • Page 39: Basler Camera Demo

    5. Basler Camera Demo In latest release, we provided support for basler USB camera. We have tested with DAA2500-14UM (CS- MOUNT) - BASLER DART camera. Link: https://www.baslerweb.com/en/products/cameras/area-scan-cameras/dart/daa2500-14um-cs- mount/#tab=specs However, this demo app can be run with any Basler camera. Here we configure pylon5 software for our board.

  • Page 40: Figure 17: Basler Pylon Viewer App

    Figure 17: Basler Pylon Viewer App Note: If We run App in maximize mode, then on left side we observed background display overlay. This is pylon app issue and it is observed on Linux as well as on board preview.

  • Page 41: Figure 18: Pylon Viewer App Display Issue

    Figure 18: Pylon Viewer App display issue...

  • Page 42: Face Recognition Using Tensorflow Lite Demo

    6. Face Recognition using Tensorflow Lite demo This application demo uses Haar Feature-based Cascade Classifiers for real time face detection. The pre-trained Haar Feature-based Cascade Classifiers for face, named as XML. TensorFlow Lite implementation for MobileFaceNets. The MobileFaceNets is re-trained with a smaller batch size and input size to get a higher performance on a host PC.

  • Page 43: Figure 20: Tensorflow Based Face Recognition Demo Output Screen

    Press 5 : ARM NN Demo Press 6 : Basler Camera demo Press 7 : Face Recognition using TensorFlow Lite demo Press 8 : Object Recognition using Arm NN demo Select: (1/2/3/4/5/6/7/8) Welcome to Face Recognition using TensorFlow Lite demo Detecting Biggest Face in Real-Time Pleae provide Camera Node Entry Node entry e.g.
  • Page 44 When the demo is running, it will detect one biggest face at real time. Once the face is detected, you can click keyboards on the right of GUI to input the new person's name. Then, click 'Add new person' to add the face to data set. In brief, 1.

  • Page 45: Object Recognition Using Arm Nn Demo

    7. Object Recognition using Arm NN Demo In latest release, we have added support for ARM NN SDK and ARM Compute Library. This Demo run ARM NN example to test performance of ARM NN on our board. This demo contains samples for running inference and predicting different objects. It also includes an extension that can recognize any given camera input/object.
  • Page 46 Press 5 : ARM NN Demo Press 6 : Basler Camera demo Press 7 : Face Recognition using TensorFlow Lite demo Press 8 : Object Recognition using Arm NN demo Select: (1/2/3/4/5/6/7/8) Welcome to Object Recognition using Arm NN demo This is a demo to show how much accuracy in detecting an Object like Cat, Dog, Shark This will pick the image from data folder and provides the accuracy of respective image with this identity No.

  • Page 47: Figure 22: Arm Nn Object Recognition Output Screen

    Top(5) prediction is 23 with confidence: 0.0152533% = Prediction values for test #1 Top(1) prediction is 282 with confidence: 58.5935% Top(2) prediction is 200 with confidence: 0.0584546% Top(3) prediction is 139 with confidence: 0.0434935% Top(4) prediction is 134 with confidence: 0.0408567% Top(5) prediction is 133 with confidence: 0.0339192% Prediction for test case 1 (282) is incorrect (should be 283) = Prediction values for test #2...

  • Page 48: Figure 23: Arm Nn Object Recognition Using Mipi Camera Run Screen

    This is a demo output shows how much accuracy in detecting an Object like Cat, Dog, Shark. This will pick the image from data folder and provides the accuracy of respective image with this identity Steps to run MIPI_Camera Demo: Run /run/media/mmcblk1p3/ARROW_DEMOS/run_ml_demos.sh script and select option 8 ,then select option 2.
  • Page 49 Press 8 : Object Recognition using Arm NN demo Select: (1/2/3/4/5/6/7/8) Welcome to Object Recognition using Arm NN demo This is a demo to show how much accuracy in detecting an Object like Cat, Dog, Shark This will pick the image from data folder and provides the accuracy of respective image with this identity No.

  • Page 50: Figure 24: Arm Nn Object Recognition Using Mipi Camera Output Screen

    Using Wayland-EGL Using the 'xdg-shell-v6' shell integration Figure 24: Arm NN Object Recognition using MIPI camera output screen This runs the TfInceptionV3-Armnn test and parses the inference results to return any recognized object, not only the three expected types of animals. Show the provided flash cards to the camera and wait for the detection message: Image captured, wait.

  • Page 51: Troubleshooting

    TROUBLESHOOTING HDMI • Although we have provided HDMI hot plug detection feature, we must connect HDMI before we boot up the board. Because we observed that if we do not connect HDMI before board boot up, hot plug feature not working and even after connecting HDMI we don’t see any output on HDMI.

  • Page 52: Figure 26: No Camera Connected Error

    Figure 26: No Camera connected error...

  • Page 53: Ml Demos References

    ML DEMOS REFERENCES • https://github.com/ageitgey/face_recognition • https://github.com/davisking/dlib • https://cmusatyalab.github.io/openface/ • https://opencv-python- tutroals.readthedocs.io/en/latest/py_tutorials/py_objdetect/py_face_detection/py_face_detect ion.html#face-detection • https://github.com/tensorflow/models/tree/master/research/object_detection • https://www.tensorflow.org/tutorials/sequences/audio_recognition • https://github.com/tensorflow/models • https://github.com/tensorflow/models/blob/master/research/object_detection/g3doc/detectio n_model_zoo.md • https://github.com/jrosebr1/imutils • https://www.pyimagesearch.com/2018/06/18/face-recognition-with-opencv-python-and-deep- learning/ • https://github.com/chuanqi305/MobileNet-SSD • https://github.com/Uberi/speech_recognition#readme • https://medium.com/@ageitgey/quick-tip-speed-up-your-python-data-processing-scripts-with- process-pools-cf275350163a • https://github.com/spmallick/learnopencv • https://github.com/ARM-software/armnn • https://www.pyimagesearch.com/2017/09/18/real-time-object-detection-with-deep-learning- and-opencv/ •...
