Robberechts XTS3-desk Manual

User information:

Brand: Robberechts
Type: XTS3-desk (sit-stand desk)
This desk is height adjustable from 65-130 cm with electronic motor, for improved ergonomics in
the workplace. Alternating sitting and standing, your body stays in motion, which is beneficial
for your concentration.
Area of use: office environment
Publication date: January 2020

Specifications:

Length: 1200mm - 2000mm (steps of 200mm)
Depth: 800mm and 900 mm
Height: adjustable from 650mm to 1300mm
Speed: 38mm/s
Maximal load: 80 kg (desktop inclusive)
Power consumption operating: 132W
Power consumption stand by: 0.3W
Noise level: <50 dB
Operation: 2 minutes on / 18minutes off

Use:

The XTS3-desk is height adjustable with a control unit.
The unit is mounted under the top on the right-hand side.
Choice of control unit
Simple J05: Up/Down with display
Advanced J02: Up/Down with display with memory function

Installation:

Structure:
manual T-frame: G006297
manual H-frame: G006298
Manuals included by the fittings.

Options:

Profile for cabling: screwed under the top. Is hinged on both sides for better accessibility.
CPU-holder: screwed under the top.
Cable channel: screwed under the top, flexible, moves up and down with the desk.
Contact your dealer for more options and further information.
