Summary of Contents for Whyte WPSU-SAP1
- Page 1 Smart Apartment PSU INSTRUCTION MANUAL WPSU-SAP1 | WPSU-SAP2 www.whytetechnologies.com In the interest of continuous improvement, all specifications of products within this brochure are subject to change without notice.
-
Page 2: Table Of Contents
CONTENTS Safety Precautions Guarantee General Description Product Description Technical Description Installation Instructions Example Configuration Specifications... -
Page 3: Safety
Do not over tighten the F connectors (finger tight only). GUARANTEE All Whyte products are guaranteed for a period of 4 years from the date of purchase against defects. Within this period, Whyte Technologies will repair or replace the faulty product. In the unlikely event, please return any faulty products to your dealer. -
Page 4: General Description
GENERAL DESCRIPTION The WPSU-SAP1 and WPSU-SAP2 are the world’s first Smart Apt PSU’s. Customer support is reduced, and customer satisfaction is increased as the IRS system will function correctly irrespective of building occupancy or type of Set-top box (if any) is used by the resident. -
Page 5: Product Description
PRODUCT DESCRIPTION WPSU-SAP2 Smart Apartment PSU – Dual Channel Multi- Multi- Switch 2 TV 2 Switch 1 TV 1 Transformer Housing AC In Power Cord LED Power Indicator UK Mains Plug STB TV Connector Corner Brackets Multiswitch Connector WPSU-SAP 2 model shown for illustrative purpose only... -
Page 6: Technical Description
1.57A (22W). INSTALLATION INSTRUCTIONS Select a suitable location to install the Whyte Smart Apartment PSU. Do not install the power supply in damp, humid, hot, or dusty areas. Using the screw slots on the Corner Brackets, secure the power supply using the appropriate fixing screws and wall plugs to suit the relevant wall surface or cabinet. - Page 7 POWER INDICATOR When AC is applied the LED(s) will be lit green indicating that the power supply is active. (Green) LED Indicator WPSU-SAP1 Smart Apartment PSU – Single Channel Multi- Switch 1 TV 1 WPSU-SAP1...
-
Page 8: Example Configuration
Consumption Min / Max @ 18V -10dB Compatibility Sky UK- EN50607 - EN50494 -20dB SCR Mode Flashing Green LED Status Legacy Mode Solid Green Power TERR DC Block Terminators Apartment WPSU-SAP1 SKY Q / Legacy STB TERR TV Diagram 1 RADIO... - Page 9 Sky UK- EN50607 - EN50494 -20dB SCR Mode Flashing Green LED Status Legacy Mode Solid Green Power TERR WM508 APARTMENT 1 WPSU-SAP1 RADIO SKY Q SKY+ HD TERR TV (SCR MODE) FREE SAT WPSU-SAP2 APARTMENT 2 SKY Q SKY + HD...
- Page 10 Flashing Green LED Status Legacy Mode Solid Green Power TERR APARTMENT 1 DC Block Terminators WPSU-SAP2 SKY Q SKY + HD SKY HD TERR TV FREE SAT WPSU-SAP1 APARTMENT 2 SKY Q SKY+ HD (SCR MODE) TERR TV FREE SAT RADIO...
-
Page 11: Specifications
SPECIFICATIONS: WPSU-SAP1 | WPSU-SAP2 4 Years Warranty Comes in 1 Feed or 2 Feed versions The World’s First Smart Apartment PSU Compatible with all Legacy and dSCR STB’s Provides 22W Power @ 14/18V Per Channel Can be installed as a set back Apartment PSU or in the Electrical Cupboard... - Page 12 Unit 1, Watermill Business Centre. Edison Road, Enfield. EN3 7XF Tel: 0330 999 1980 | info@whytetechnologies.com | www.whytetechnologies.com Copyright © Whyte Technologies. November 2022 - v1...
